1838 X of ST(R) exceeds moveable range. data. 1839 Y of ST(R) exceeds moveable range. Check Y offset in pickup data and Y offset in Feeder data. 1712 Model data is displayed. Acquired model image is displayed. 1713 Resol…
1709 Specified illumination level is set.
1710 Model data is acquired. Model data is stored in file.
1711 Model centering Center of F mark is detected, where camera moves.
1622 PCB through ends.
1623 Run ends.
1624 starts.
1625 ends.
1626 ended without completing the job.
1627 MMI MSG
1628 MMI MSG
1629 Job run ended without completing the job.
1630 Job run ended without completing the job.
1631 Start warm-up
1632 End warm-up
1633 Start warm-up for the specified item.
1634 End warm-up for the specified item.
1635 Producible PCB count has reached the alarm setting. Replenish components.
1636
1637 Pause the current job and enter Edit&Teach mode.
(clear signal tower of 1635)
1638 Exit Edit&Teach mode and resume the current job.
Contact failure of CPU and CPU controller board.
1639 Failed to load the controller program. [%d1]
Check the contact of each board.
1640
1641
execute ends.
Instantaneous power failure is detected.
1642 Pause (Cancel or start possible)
The UPS does not operate normally. Contact i-
1643 The control board is not adapted to the system.
PULSE local distributor.
1644 Feeders setup are verified.
1650 Operational switch is pressed.
1651 System condition changes.
1656 System condition changes.
1659 Prearrange process starts.
1660 MX Info. starts.
1661 Nozzle ID recognition starts.
1662 Nozzle change starts.
1663 Prearrange process ends.
1664 MX Info. ends.
1665 Nozzle ID recognition ends.
1666 Nozzle change ends.
1667 Nozzle ID manual setting ends.
1668 Nozzle ID recognition ends without completing the
1669 Nozzle change ends without completing the job.
1670
1671
%c1 MMI MSG
%c1 MMI MSG
1672 Fiducial mark coordinates have been obtained.
Coordinates have been obtained without fiducial
1673
correction.
1680 User parameter is saved. Data is saved on file. Use to prevent mis-saving.
1681 System parameter is saved. Data is saved on file. Use to prevent mis-saving.
1682 Component library is saved. Data is saved on file. Use to prevent mis-saving.
1683 Image library is saved. Data is saved on file. Use to prevent mis-saving.
1684 Feeder library is saved. Data is saved on file. Use to prevent mis-saving.
1685 Pallet library is saved. Data is saved on file. Use to prevent mis-saving.
1686 Packaging library is saved. Data is saved on file. Use to prevent mis-saving.
1687 Tray library is saved. Data is saved on file. Use to prevent mis-saving.
1688 Nozzle library is saved. Data is saved on file. Use to prevent mis-saving.
1689 Dispense library is saved. Data is saved on file. Use to prevent mis-saving.
1690 Syringe library is saved. Data is saved on file. Use to prevent mis-saving.
1691 Dispense Nozzle library is saved. Data is saved on file. Use to prevent mis-saving.
1692 Production plan is updated. Data is saved on file. Use to prevent mis-saving.
1701 Camera change
1702 Image mode change
1703 Image test is performed. Image test is performed. Warning; any axis may move.
1704 Guide frame display command
1705
1706
Camera center cross line
ADA is performed. ADA(Automatic Data Acquisition) is performed.
1707 Multi-view image test result is displayed.
Component (except chip) size is automatically
1708 ADA is performed.
measured.
1838 X of ST(R) exceeds moveable range.
data.
1839 Y of ST(R) exceeds moveable range.
Check Y offset in pickup data and Y offset in Feeder
data.
1712 Model data is displayed. Acquired model image is displayed.
1713 Resolution is measured.
1714 Camera brightness is measured.
1715 Camera tilt is measured.
1716 T-axis center is measured.
1717 Focus is taken.
1718 VCS is requested.
1719 Version No. is acquired.
1720 Packet loop back is requested.
1721 Communication speed changes.
1722 All device & model data are deleted.
1723 Specified device data is deleted.
1724 Specified model data is deleted.
1725 Specified resolution data is deleted.
1726 All device data is sent.
1727 Device data is sent.
1728 Model data is sent.
1729 Gain/offset of camera is sent.
1730 Model data is received.
1731
1732
Detailed result of Image processing is sent.
Resolution data is backed up.
1733 Resolution data is restored.
System automatically resets vision system to cancel
1734 Reset is required.
error.
1735 Cancel is required.
1736 Head offset (S axis) is sent.
1737 Image test is completed.
1738 ADA is completed.
1800 No header file is found. Save data in Data Edit window.
1801 No board data is found. Save data in Data Edit window.
1802 No placement data is found. Save data in Data Edit window.
1803 No pickup data is found. Save data in Data Edit window.
1804 Header file is abnormal. Save data in Data Edit window.
1805 Board data file is abnormal. Save data in Data Edit window.
1806 Placement data file is abnormal. Save data in Data Edit window.
1807 Pickup data file is abnormal. Save data in Data Edit window.
1808 No component file is found. Save data in Component Library window.
1809 No feeder library is found. Save data in Feeder Library window.
1810 No packaging library is found. Save data in Packaging Library window.
1811 No nozzle ID is found. Perform automatic nozzle ID recognition.
1812 No pallet library is found. Save data in Pallet Library window.
1813 No tray library is found. Save data in Tray Library window.
1814 Component library is abnormal. Save data in Component Library window.
1815 Feeder library file is abnormal. Save data in Feeder Library window.
1816 Packaging library is abnormal. Save data in Packaging Library window.
1817 Nozzle library file is abnormal. Save data in Nozzle Library window.
1818
1819
Pallet library file is abnormal.
Tray library file is abnormal.
Save data in Pallet Library window.
Save data in Tray Library window.
1820 Image library file is abnormal. Save data in Image Library window.
Check task setting of Start block placement and End
1829 Task setting for repeat program is wrong.
block placement.
Check task setting og Multiple pickup and End
1830 Multiple pickup assignment is wrong.
multiple pickup.
The same head cannot be specified in a multiple
1831 Head specification is wrong in multiple pickup.
pickup block.
1832
Multiple pickup steps in a cycle exceeds the number
of heads.
Check the number of steps in the multiple pickup
cycle.
1833 Theta of ST(F) exceeds +/-180.00 deg. Theta must be within +/-180.00 deg.
Check X offset in pickup data and X offset in Tape
1834 X of ST(F) exceeds moveable range.
feeder data.
Check Y offset in pickup data and Y offset in Tape
1835 Y of ST(F) exceeds moveable range.
feeder data.
1836 Z of ST(F) exceeds moveable range.
Check Z offset in pickup data and Thickness in
Component data.
1837 Theta of ST(R) exceeds +/-180.00 deg. Theta must be within +/-180.00 deg.
Check X offset in pickup data and X offset in Feeder
1887 Y of reject location exceeds moveable range. Y of reject location must not exceed moveable range.
1888 Z of reject location exceeds moveable range. Z of reject location must not exceed moveable range.
1889 Theta of reject location exceeds +/-180.00 deg. Theta must be within +/-180.00 deg.
Check Z offset in pickup data and Thickness in
1840 Z of ST(R) exceeds moveable range.
Component data.
Use code of placement data in component code
1841 Component is not specified in Pickup Data.
pickup data.
1842 Component is not specified in Component data. Use component code of pickup data in Component
1843 Component name is abnormal. Code contains characters not to be used.
1844 Head number is abnormal. Enter correct head No.
1845 Fiducial group No. is wrong. Available group Nos. of fiducial are 0-249.
1846 Task setting is abnormal. Select correct item for Task in Placement data.
1847 Type setting is abnormal. Select correct item for Type in Placement data.
1848 X exceeds placement range of board. X of placement data must not exceed placeable area.
1849 Y exceeds placement range of board. Y of placement data must not exceed placeable area.
1850 Z exceeds placement range of board. Z of placement data must not exceed placeable area.
1851 X exceeds moveable range. X of placement data must not exceed moveable area.
1852 Y exceeds moveable range. Y of placement data must not exceed moveable area.
1853
1854
Z exceeds moveable range.
X exceeds board size.
Z of placement data must not exceed moveable area.
X of placement data must not exceed X of board data.
1855 Y exceeds board size. Y of placement data must not exceed X of board data.
X of head parking of board data must not exceed
1856 X of head parking exceeds moveable range
moveable range.
Y of head parking of board data must not exceed
1857 Y of head parking exceeds moveable range.
moveable range.
Z of head of parking of board data must not exceed
1858 Z of head parking exceeds moveable range.
moveable range.
1859
1860
Theta of head parking exceeds +/-180.00 deg.
Board length exceeds specified range.
Theta must be within +/-180.00 deg.
X of board data must not exceed moveable range.
1861 Board width exceeds specified range. Y of board data must not exceed moveable range.
Check X/Y/Z offset in pickup data and X/Y offset in
1862 Pickup position exceeds range.
Feeder data.
1863
1864
Feed style of pickup data is wrong.
No component code is found in Pickup Data.
Enter correct feed style for pickup data.
Enter correct component code for pickup data.
1865 ST No. exceeds range. Enter correct ST No. for pickup data.
Enter code of Feeder/Pallet data into Feeder/Pallet
1866 No feeder/pallet name is found in Pickup Data.
of pickup data.
1867
1868
No packaging/tray name is found in Pickup Data.
Pickup skip is wrong in Pickup Data.
Enter code of Packaging/Tray data into
Packaging/Tray of pickup data.
Enter correct data into Skip of Pickup data.
1869
Max. pre-processed component height exceeds range
Max. preprocessed component height must be within
0mm (0mil) to the Max. Component Height" in system
in Board Data.
parameter."
Max.component height must be within 0mm (0mil) to
1870 Max.component height exceeds range in Board Data.
the Max. Component Height" in system parameter."
Enter code of Feeder/Pallet data into Feeder/Pallet
1871
1872
No data is found in Feeder and Pallet Data.
No data is found in Packaging and Tray Data.
of pickup data.
Enter code of Packaging/Tray data into
Packaging/Tray of pickup data.
1873
The component height exceeds the Max. Component
Thickness" in Component Data ranges from 0.01mm
(0.04mil) to the "Max. Component Height" in system
Height.
parameter."
1874 Five or more continuous F mark lines are specified.
Five or more continuous F mark lines must not be
specified.
1875 No image data of F mark is found. Enter code of fiducial data into code of placement
1876 Fiducial group No. is specified prior to F. mark rows.
To use the same fiducial group, create fiducial rows
prior to placement rows.
1877 No model data for fiducial mark is found.
PackagingData>Angle must be either 0, 90, 180, or -
Acquire the model image.
PackagingData>Angle must be either 0, 90, 180, or -
1878
90 degrees. 90 degrees.
Nozzle No. registered in Component Data is not found
1879
in Nozzle information.
Perform automatic nozzle ID recognition.
1880 Nozzle pressure (Hg) exceeds range. Nozzle pressure (Hg) must be within between 1 -660.
1881 No image data is found. Enter image data into image code of Component data.
1882 Z slowdown ratio is wrong. Z slowdown ratio must be within between 1 -1000.
1883 No image data is found. Enter image code registered into Component data.
1884 Camera No. is wrong. Enter correct centering into Component data.
1885 Reject No. in Packaging Data exceeds range. Reject No. must be within 1 to 10.
1886 X of reject location exceeds moveable range.
X of reject location must not exceed moveable range.
