3118 The conveyor width was changed after Push up pins were located. Located %v1mm, Current %v2mm, Tolerance +/-%v3mm Collect the Pushup Pins manually. 3119 Push-up pin location is the same as the last time. The process …
3107 Failed to image the pickup point. Row:%d1 Offset:%d2
image data.
3108
Extra time was needed to start stable Laser check.
%d1msec
3109
IC component feeding device is out of components or
a malfunction occurred in the device.
Please check IC component feeding device.
3077
Head will start traveling after completion of CTF/FTF
tray setup
3078
The component cannot be put back to the tray for
reuse because %s is in Nonstop tray setup mode. To
Press Setup switch to allow CTF/FTF to supply
components.
3079
cancel the mode, press Setup switch.
Laser calibration is interrupted.
3080
3081
Laser calibration error occurred.
Laser tool horizontal error
Tool is not horizontally assembled. Check the
3082 Laser height scale error
assembled condition.
Re-adjust the laser head assembling. Then re-
3083 Laser height check range error
execute auto calibration.
Re-adjust the laser head assembling. Then re-
3084 Laser Z offset check error
execute auto calibration.
Re-adjust the laser head assembling. Then re-
3085
3086
Laser XY offset check error
Laser immeasurable check error
execute auto calibration.
Re-execute provisional adjustment of XY offset. Then
execute auto calibration.
Make sure no dirt or obstacles are at laser transmit
part. Then re-execute auto calibration.
3087
Cannot set the feeder at the pickup station because
the feeder pickup point height exceeds the height of
limit range. %s-%d1 %m %v2mm < %v3mm
To set the feeder at a feeder station, 'ST-F1 to 13 on
M10', or 'ST-FR24 to 36 or ST-FL1 to 13 on M20',
feeder pickup point height, sum of Pickup 'Z offset' +
Feeder 'Feed height' + Package 'Height'" must be
5mm or less. (Minus Z offset is not added.)"
To set the feeder at a pickup station, 'ST-F1 to 13 on
Cannot set the feeder because Device Max Height of
M10', or 'ST-FR24 to 36 or ST-FL1 to 13 on M20',
3088 the feeder exceeds the height of limit range. %s-%d1
sum of the device max height and the feeder height
3089
%m %v2mm < %v4mm
%s communication error
must be 5mm or less.
3090
3091
%s servo error
READY %s X,%d1,Y,%d2,Z,%d3,%d4,%d5,%d6,%d7,%d8
3092 READY %s R,%d3,%d4,%d5,%d6,%d7,%d8
Angle of Dispense nozzle exceeds tolerance. Head%d1
3093
Shift: %v2 Tolerance: %v3
Refix the Dispense nozzle.
Never set a feeder during production to prevent a
3094 A feeder is set at %s-%d1 during production.
head crash.
A feeder is removed from %s-%d1 during production. Never remove a feeder during production to prevent a
3095
(The feed button of F1 or F2 feeder was pressed.) head crash.
Comp Pitch of Feeder %m at %s-%d1 is changed from
3096
%d2mm to Default.
Comp Pitch of Feeder %m at %s-%d1 is changed from
3097
3098
Default to %d3mm.
Comp Pitch of Feeder %m at %s-%d1 is selected to
Default.
Comp Pitch of Feeder %m at %s-%d1 is selected to
3099
%d2mm.
Image process is resulted in NG because failed to
3100 acquire the acceleration and/or the speed of image
capture. %m Head%c1
3101 Failed to check Dispense nozzle length. Head%d1
The offset value in the dispense data exceeds
Check that Dispense nozzle is attached properly.
Correct the offset value in Dispense Data to be within
3102
DotStation area.
Component is placed out of PCB %m Head%c1
DotStation area.
Check PCB size, placement point, component data,
3103
Row:%d5 Offset:%d6
Placement error reaches limit count. %m Head%c1
selected nozzle, and image data.
Check PCB size, placement point, component data,
3104
Row:%d5 Offset:%d6 selected nozzle, and image data.
Shortage of disk space or cannot connect a network
3105 Cannot save a log file.
drive.
Cannot drive because version of the right and the left
3106
servo amplifiers differ. Y1-AMP:%X1 Y2-AMP:%X2
Use X and Y Servo amplifiers of version E4.001.
Check the Pickup point status and the Component
3118
The conveyor width was changed after Push up pins
were located. Located %v1mm, Current %v2mm,
Tolerance +/-%v3mm
Collect the Pushup Pins manually.
3119
Push-up pin location is the same as the last time.
The process has been skipped.
Diameter of each dispensing point of multi-nozzles
cannot be compensated to the target diameter. One
3110 dispensing diameter exceeds the maximum acceptable
diameter and another dispensing diameter falls the
Please check the target diameter of each dispensing
point.
3111
minimum acceptable diameter.
Height Check NG %m %d2th row Result:%v3
Tolerance:%v4 Head%c1 Row No.:%d5 Repeat
Check the component configuration and position.
3112
Height Check NG reached retry limit %m Head%c1
Row No.:%d5 Repeat Offset:%d6
Check the component configuration and position.
3113
The PCB on the conveyor may not be reloaded.
At the start of production, the PCB was detected at
an improper position to reload. Remove the PCB and
Remove the PCB.
Adjusted offset values of Dispense Nozzle Head:%c1
Restart the production.
3114
Angle:%d2 X:%d3 Y:%d4 T:%d5
Height of the Quick Clamp is not proper. Checked %v1 Check the Quick Clamp motion. Check that no
3115
3116
Set Height %v2
Differences of check results of Laser1 and Laser2
exceed the tolerance. 1st:%v1 2nd:%v2 Tolerance:%v3
obstacles between the Quick Clamp and the
Check the lasers installation status.
3117
The Reject Conveyor %c2-%d3 in Pickup Data No. %d6
is full or not installed.
Remove components and press the RESET button. Or
install the Reject Conveyor at the proper station.
Chapter 16 Dispenser
16-1
Chapter 16
Dispenser
Creating programs and data
Checking the dispenser
Nozzle offsets
Cleaning the screw type dispense head
