A-88 A24-2 【 RX-7R 】デュアル搬送レーン 3 【 RX-7R 】 Dual Conveyor lane - 3 ３６ ３９ ３９ ３６ ６３ ６３ ６３ ６３ ３５ ３４ ３３ ３３ ２７ ２７ ２３ １０ ６ ２３ ２３ ２３ ２３ ２３ ２３ ２３ ２３ ６１ ６１ ６１ ６１ ２５ ２５ ６２ ６２ ２０ １９ １８ １７ １７ １７ １５ １４ １４ １４ １４ １３ １３ １３ １３ １１ １１ １０ ９ ８…
A-87
A24-1
【RX-7】搬送レーン 3
【RX-7】Conveyor lane - 3
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ4-454-297-02 PLATE (L2), RAIL ﾚ-ﾙ ﾌﾟﾚ-ﾄ (L2) 1
2 EZ4-454-322-01 RETAINER (SLIDE LOWER L) ｷﾊﾞﾝ ｵｻｴ (ｽﾗｲﾄﾞ ｼﾀ L) 1
3 EZ4-454-519-01 SOLENOID (SBP5), BALL ﾎﾞ-ﾙ ﾌﾟﾗﾝｼﾞﾔ (SBP5) 2
4 EZ4-454-323-01 RETAINER (SLIDE UPPER L),BOARD ｷﾊﾞﾝ ｵｻｴ (ｽﾗｲﾄﾞ ｳｴ L) 1
5 EZ4-454-319-01 PIN, STEP ﾀﾞﾝﾂｷ ﾋﾟﾝ 6
6 EZ4-454-322-11 RETAINER (SLIDE LOWER R) ｷﾊﾞﾝ ｵｻｴ (ｽﾗｲﾄﾞ ｼﾀ R) 1
7 EZ4-454-519-01 SOLENOID (SBP5), BALL ﾎﾞ-ﾙ ﾌﾟﾗﾝｼﾞﾔ (SBP5) 2
8 EZ4-454-323-11 RETAINER (SLIDE UPPER R),BOARD ｷﾊﾞﾝ ｵｻｴ (ｽﾗｲﾄﾞ ｳｴ R) 1
9 EZ4-454-319-01 PIN, STEP ﾀﾞﾝﾂｷ ﾋﾟﾝ 6
10 EZ4-454-325-01 BRACKET (LR), SENSOR ｾﾝｻ ﾌﾞﾗｹﾂﾄ (LR) 2
11 EZ4-454-326-01 BRACKET (C), SENSOR ｾﾝｻ ﾌﾞﾗｹﾂﾄ (C) 1
12 EZ3-282-481-31 BOLT (CBSA3-6) ｺﾞｸ ﾃｲﾄｳ ﾎﾞﾙﾄ (CBSA3-6) 6
13 EZ1-492-207-11 SENSOR, FIBER (FT-AL05) ﾌｱｲﾊﾞ ｾﾝｻ (FT-AL05) 3
14 EZ4-454-511-01 PULLEY (P30-2GT) (A) ﾌﾟ-ﾘ (P30-2GT) A 6
15 EZ4-453-832-01 BEARING (6804ZZ) ﾍﾞｱﾘﾝｸﾞ (6804ZZ) 2
16 EZ4-454-363-02 BRACKET (3R), REINFORCEMENT ﾎｷﾖｳ ﾌﾞﾗｹﾂﾄ (3R) 1
17 EZ4-453-825-01 PULLEY (P1110-012-1) (D) ﾀｲﾐﾝｸﾞ ﾌﾟ-ﾘ (P1110-012-1) D 2
18 EZ2-679-468-01 BOLT (CBSTS3-10) ｺﾞｸ ﾃｲﾄｳ ﾎﾞﾙﾄ (CBSTS3-10) 8
19 EZ4-454-327-01 HOUSING, NUT ﾅﾂﾄ ﾊｳｼﾞﾝｸﾞ 2
20 EZ2-022-680-11 RING, C TYPE RETAINING (STWS*) C ｶﾞﾀ ﾄﾒﾜ (STWS20) 2
21 EZ4-454-505-01 IDLER (AS-5A40) (B) ｱｲﾄﾞﾗ- (AS-5A40) B 2
22 EZ4-718-724-05 NUT(1TYPE),HEXAGON(M4X0.7 SUS) ﾛﾂｶｸ ﾅﾂﾄ (1 ｼﾕ) (M4X0.7 SUS) 4
23 EZ4-454-512-01 PULLEY (P30-2GTX2) (B) ﾌﾟ-ﾘ (P30-2GTX2) B 2
24 EZ4-454-500-01 CYLINDER (CDUJB8-11-DCP6468P) ｼﾘﾝﾀﾞ (CDUJB8-11-DCP6468P) 4
25 EZ4-447-052-11 UNION (KQ2H02-M3G), HALF ﾊ-ﾌ ﾕﾆｵﾝ (KQ2H02-M3G) 8
26 EZ4-454-324-01 JOINT, CYLINDER ｼﾘﾝﾀﾞ ｼﾞﾖｲﾝﾄ 4
27 EZ4-454-328-01 STOPPER, CLAMP ｸﾗﾝﾌﾟ ｽﾄﾂﾊﾟ 4
28 EZ4-453-829-01 BELT (162-2GT-3), TIMING ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ (162-2GT-3) 2
29 EZ4-454-501-01 GUIDE (LWLG9C1R52BS1EB09) ｶﾞｲﾄﾞ (LWLG9C1R52BS1EB09) 4
30 EZ4-455-706-01 COVER HARNESS ｶﾊﾞ-ﾊ-ﾈｽ 2
31 EZ4-454-504-01 IDLER (AS-5A39A) (A) ｱｲﾄﾞﾗ- (AS-5A39A) A 4
32 EZ4-454-360-01 PLATE (0.5), CLAMP ｸﾗﾝﾌﾟ ﾌﾟﾚ-ﾄ (0.5) 2
33 EZ4-454-361-01 JOINT (L), CLAMP ｸﾗﾝﾌﾟ ｼﾞﾖｲﾝﾄ (L) 2
34 EZ4-454-361-11 JOINT (R), CLAMP ｸﾗﾝﾌﾟ ｼﾞﾖｲﾝﾄ (R) 2
35 EZ4-701-529-01 TIE MOUNT (MB1) ﾀｲﾏｳﾝﾄ (MB1) 8
36 EZ7-683-402-04 BOLT,HEXAGON SOCKET 3X5 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X5 28
37 EZ7-683-403-04 BOLT,HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 16
38 EZ7-683-404-04 BOLT,HEXAGON SOCKET 3X8 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X8 8
39 EZ7-682-248-09 SCREW +K 3X8 +K 3X8 8
40 EZ7-683-421-04 BOLT HEXAGON SOCKET 4X12 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ(C4X12) 16
41 EZ4-706-151-11 CLAMP (KR5G5) ﾊｲｾﾝﾄﾞﾒ (KR5G5) 1
42 EZ4-702-261-02 BOLT, HEXAGON SOCKET (M3X6) ﾛﾂｶｸ ｱﾅﾂｷ ｻﾗ ﾎﾞﾙﾄ (M3X6) 6
43 EZ2-595-270-01 HOLDER WIRE ﾎﾙﾀﾞｰﾜｲﾔｰ 6
44 EZ7-682-247-09 SCREW +K 3X6 SCREW +K 3X6 6
45 EZ4-454-762-01 KEY (K03008), PARALLEL ﾍｲｺｳ ｷ- (K03008) 2
46 EZ4-459-595-01 BELT (1110-2GT-2), TIMING ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ (1110-2GT-2) 2
47 EZ1-492-216-32 SENSOR ASSY ｾﾝｻ ASSY (ｸﾗﾝﾌﾟ 3) 1
48 EZ1-492-216-42 SENSOR ASSY ｾﾝｻ ASSY (ｸﾗﾝﾌﾟ 4) 1
49 EZ2-595-270-01 HOLDER WIRE ﾎﾙﾀﾞｰﾜｲﾔｰ 4
50 EZ7-682-247-09 SCREW +K 3X6 SCREW +K 3X6 4
A-88
A24-2
【RX-7R】デュアル搬送レーン 3
【RX-7R】Dual Conveyor lane - 3
３６
３９
３９
３６
６３
６３
６３
６３
３５
３４
３３
３３
２７
２７
２３
１０
６
２３
２３
２３
２３
２３
２３
２３
２３
６１
６１
６１
６１
２５
２５
６２
６２
２０
１９１８
１７
１７
１７
１５
１４
１４
１４
１４
１３
１３
１３
１３
１１
１１
１０
９
８
７
１２
１２
１２
６
１２
５
５
４
３
３
３
３
３
３
１
１
１
３７
３８
３８
３７
３８
３７
３８
３７
３８
３７
４０
４０
４０
４０
４０
４０
４０
４４
４４
４４
６
１０
２３
３６
３９
４０
３９
３６
４０
４５
４６
４６
４７
４７
１６
５０
２６
２６
２２
２２
２２
２２
Ａ
Ａ
３８
３７
４０
４４
Ｂ
Ｂ
３
３
６
１０
２３
５０
３２
３２
２
２
４２
４１
４３
３０
２９
３０
２８
３１
３２
２９
３０
３２
３０
３１
２８
５５
３７
５４
５４
３７
５５
４１
４３
４２
５８
５１
４８
４９
Ｃ
Ｃ
５６ ５７
４５
６５
６４
A-89
A24-2
【RX-7R】デュアル搬送レーン 3
【RX-7R】Dual Conveyor lane - 3
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ1-492-207-11 SENSOR FIBER (FT-AL05) ﾌｱｲﾊﾞ ｾﾝｻ (FT-AL05) 3
2 EZ1-492-250-12 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾞﾂｸ ｱﾂﾌﾟ ﾋﾟﾝ 3) 1
3 EZ4-447-052-11 UNION (KQ2H02-M3G) HALF ﾊ-ﾌ ﾕﾆｵﾝ (KQ2H02-M3G) 8
4 402-01172 CONVEYOR RAIL_LANE3_4 ｺﾝﾍﾞｱｰﾚｰﾙ(ﾚｰﾝ 3_4) 1
5 402-00610 COLLAR(M3)_STEP ﾀﾞﾝﾂｷｶﾗｰ(M3) 8
6 402-00912 JOINT(A)CYLINDER
ｼﾘﾝﾀﾞｰｼﾞｮｲﾝﾄ(A)
4
7 402-00985 SENSOR BRACKET(1) ｾﾝｻｰﾌﾞﾗｹｯﾄ(1) 1
8 402-00986 SENSOR BRACKET(2) ｾﾝｻｰﾌﾞﾗｹｯﾄ(2) 1
9 402-03788 SENSOR BRACKET(C2) ｾﾝｻｰﾌﾞﾗｹｯﾄ(C2) 1
10 EZ4-454-328-01 STOPPER CLAMP ｸﾗﾝﾌﾟ ｽﾄﾂﾊﾟ 4
11 402-00911 CLAMP BRACKET ｸﾗﾝﾌﾟﾌﾞﾗｹｯﾄ 2
12 EZ4-454-500-01 CYLINDER (CDUJB8-11-DCP6468P)
ｼﾘﾝﾀﾞ (CDUJB8-11-DCP6468P)
4
13 EZ4-454-501-01 GUIDE (LWLG9C1R52BS1EB09) ｶﾞｲﾄﾞ (LWLG9C1R52BS1EB09) 4
14 EZ4-454-519-01 SOLENOID (SBP5) BALL ﾎﾞ-ﾙ ﾌﾟﾗﾝｼﾞﾔ (SBP5) 4
15 EZ4-455-733-01 WYE (KJU02-00) UNION ﾕﾆｵﾝ ﾜｲ (KJU02-00) 4
16 EZ4-701-529-01 TIE MOUNT (MB1) ﾀｲﾏｳﾝﾄ (MB1) 14
17 EZ4-702-261-02 BOLT HEXAGON SOCKET (M3X6) ﾛﾂｶｸ ｱﾅﾂｷ ｻﾗ ﾎﾞﾙﾄ (M3X6) 6
18 EZ4-716-434-11 TIE INSULOCK(AB100 BLACK)
ｲﾝｼﾕﾛﾂｸ ﾀｲ(AB100 ｸﾛ)
14
19 EZ4-722-956-01 LABEL(SILVER) BLANK ﾌﾞﾗﾝｸ ﾗﾍﾞﾙ ｷﾞﾝ(TTC82YS-10) 2
20 EZ7-630-003-55 TUBE (TU0212B-20) 2MMX20M BLK ﾁﾕｰﾌﾞ(TU0212B-20) 2MMX20M BLK 9.24
21 EZ7-682-247-09 SCREW +K 3X6 SCREW +K 3X6 14
22 EZ7-683-401-04 BOLT HEXAGON SOCKET 3X4 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X4 16
23 EZ7-683-403-04 BOLT HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 34
24 EZ7-683-404-04 BOLT HEXAGON SOCKET 3X8
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X8
8
25 402-00906 GUIDE RAIL_PC BOARD ｷﾊﾞﾝｶﾞｲﾄﾞﾚｰﾙ 2
26 SM-6040602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ 8
27 400-00863 CONVEYOR_BELT_S ｺﾝﾍﾞｱﾍﾞﾙﾄ S 2
28 400-00840 DRIVE_PULLEY_R ﾄﾞﾗｲﾌﾞﾌﾟｰﾘ R 2
29 E2160-721-000 PULLEY FLANGE ﾌﾟｰﾘﾌﾗﾝｼﾞ 2
30 E3931-750-000 PULLEY WASHER
ﾌﾟｰﾘ ｽﾗｽﾄ ﾜｯｼｬ
4
31 401-92967 PULLEY FLANGE(2) ﾌﾟｰﾘｰﾌﾗﾝｼﾞ(2) 2
32 SL-6030892-TN SCREW M3 L=8 座金付き六角穴ﾎﾞﾙﾄ M3 L=8 12
33 402-00989 PLATE_BELT SUPPORT ﾍﾞﾙﾄｻﾎﾟｰﾄﾌﾟﾚｰﾄ 2
34 402-00990 PLATE_PC BOARD GUIDE(1) ｷﾊﾞﾝｶﾞｲﾄﾞﾌﾟﾚｰﾄ(1) 1
35 402-00991 PLATE_PC BOARD GUIDE(2) ｷﾊﾞﾝｶﾞｲﾄﾞﾌﾟﾚｰﾄ(2) 1
36 E2111-715-0A0 CONVEYOR PULLEY ASM.
ﾊﾝｿｳﾌﾟｰﾘ(ｸﾐ)
4
37 E2089-721-0A0 CONVEYOR PULLEY B ASM. ﾊﾝｿｳﾌﾟｰﾘ B ｸﾐ 8
38 402-00909 COLLAR(1)PULLEY ﾌﾟｰﾘｰｶﾗｰ(1) 6
39 402-00910 COLLAR(2)PULLEY ﾌﾟｰﾘｰｶﾗｰ(2) 4
40 SM-4041601-SC SCREW M4X0.7 L=16 ﾅﾍﾞｺﾈｼﾞ M4X0.7 L=16 10
41 NM-6040001-SC NUT M4X0.7 TYPE1 六角 ﾅｯﾄ M4X×0.7 1 種 2
42 WP-0430801-SC WASHER M4
ﾋﾗｻﾞｶﾞﾈ M4
2
43 WS-0410002-KN SPRING WASHER M4 ﾊﾞﾈｻﾞｶﾞﾈ M4 2
44 402-02038 SPACER GUIDE ｶﾞｲﾄﾞｽﾍﾟｰｻｰ 4
45 402-02219 WASHER_PC BOARD GUIDE ｷﾊﾞﾝｶﾞｲﾄﾞﾖｳﾜｯｼｬｰ 8
46 402-00992 SUPPORT_PC BOARD GUIDE ｷﾊﾞﾝｶﾞｲﾄﾞｻﾎﾟｰﾄ 2
47 SM-1030552-TN PLATE SCREW M3 L=5 ｻﾗﾈｼﾞ M3 L=5 8
48 402-09121 CENTER SUPPORT(3)
ｾﾝﾀｰｻﾎﾟｰﾄ(3)
1
49 402-09253 REINFORCING PLATE ﾎｷｮｳﾌﾟﾚｰﾄ 1
50 402-08796 RETAINER(2)_PC BOARD(SLIDE) ｷﾊﾞﾝｵｻｴ 2(ｽﾗｲﾄﾞ) 2
