A-94
A25-2
【RX-7R】デュアル搬送レーン-4
【RX-7R】Dual Conveyor lane - 4
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ4-447-052-11 UNION (KQ2H02-M3G) HALF ﾊ-ﾌ ﾕﾆｵﾝ (KQ2H02-M3G) 8
2 402-01172 CONVEYOR RAIL_LANE3_4 ｺﾝﾍﾞｱｰﾚｰﾙ(ﾚｰﾝ 3_4) 1
3 402-00912 JOINT(A)CYLINDER ｼﾘﾝﾀﾞｰｼﾞｮｲﾝﾄ(A) 4
4 402-00985 SENSOR BRACKET(1) ｾﾝｻｰﾌﾞﾗｹｯﾄ(1) 1
5 402-00986 SENSOR BRACKET(2) ｾﾝｻｰﾌﾞﾗｹｯﾄ(2) 1
6 EZ4-454-328-01 STOPPER CLAMP ｸﾗﾝﾌﾟ ｽﾄﾂﾊﾟ 4
7 402-00911 CLAMP BRACKET ｸﾗﾝﾌﾟﾌﾞﾗｹｯﾄ 2
8 EZ4-454-500-01 CYLINDER (CDUJB8-11-DCP6468P) ｼﾘﾝﾀﾞ (CDUJB8-11-DCP6468P) 4
9 EZ4-454-501-01 GUIDE (LWLG9C1R52BS1EB09) ｶﾞｲﾄﾞ (LWLG9C1R52BS1EB09) 4
10 EZ4-455-733-01 WYE (KJU02-00) UNION ﾕﾆｵﾝ ﾜｲ (KJU02-00) 4
11 EZ4-701-529-01 TIE MOUNT (MB1) ﾀｲﾏｳﾝﾄ (MB1) 14
12 EZ4-702-261-02 BOLT HEXAGON SOCKET (M3X6) ﾛﾂｶｸ ｱﾅﾂｷ ｻﾗ ﾎﾞﾙﾄ (M3X6) 6
13 EZ4-716-434-11 TIE INSULOCK(AB100 BLACK) ｲﾝｼﾕﾛﾂｸ ﾀｲ(AB100 ｸﾛ) 14
14 EZ7-630-003-55 TUBE (TU0212B-20) 2MMX20M BLK TUBE (TU0212B-20) 2MMX20M BLK 11.52
15 EZ7-682-247-09 SCREW +K 3X6 SCREW +K 3X6 14
16 EZ7-683-401-04 BOLT HEXAGON SOCKET 3X4 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X4 16
17 EZ7-683-403-04 BOLT HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 34
18 EZ7-683-404-04 BOLT HEXAGON SOCKET 3X8 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X8 8
19 400-00863 CONVEYOR_BELT_S ｺﾝﾍﾞｱﾍﾞﾙﾄ S 2
20 402-00987 SENSOR BRACKET(3) ｾﾝｻｰﾌﾞﾗｹｯﾄ(3) 1
21 400-00840 DRIVE_PULLEY_R ﾄﾞﾗｲﾌﾞﾌﾟｰﾘ R 2
22 E2160-721-000 PULLEY FLANGE
ﾌﾟｰﾘﾌﾗﾝｼﾞ
2
23 E3931-750-000 PULLEY WASHER ﾌﾟｰﾘ ｽﾗｽﾄ ﾜｯｼｬ 4
24 401-92967 PULLEY FLANGE(2) ﾌﾟｰﾘｰﾌﾗﾝｼﾞ(2) 2
25 SL-6030892-TN SCREW M3 L=8 座金付き六角穴ﾎﾞﾙﾄ M3 L=8 12
26 402-00906 GUIDE RAIL_PC BOARD ｷﾊﾞﾝｶﾞｲﾄﾞﾚｰﾙ 2
27 402-00989 PLATE_BELT SUPPORT ﾍﾞﾙﾄｻﾎﾟｰﾄﾌﾟﾚｰﾄ 2
28 402-00990 PLATE_PC BOARD GUIDE(1) ｷﾊﾞﾝｶﾞｲﾄﾞﾌﾟﾚｰﾄ(1) 1
29 402-00991 PLATE_PC BOARD GUIDE(2) ｷﾊﾞﾝｶﾞｲﾄﾞﾌﾟﾚｰﾄ(2) 1
30 E2111-715-0A0 CONVEYOR PULLEY ASM. ﾊﾝｿｳﾌﾟｰﾘ(ｸﾐ) 4
31 E2089-721-0A0 CONVEYOR PULLEY B ASM. ﾊﾝｿｳﾌﾟｰﾘ B ｸﾐ 8
32 402-00909 COLLAR(1)PULLEY ﾌﾟｰﾘｰｶﾗｰ(1) 6
33 402-00910 COLLAR(2)PULLEY ﾌﾟｰﾘｰｶﾗｰ(2) 4
34 NM-6040001-SC NUT M4X0.7 TYPE1 六角 ﾅｯﾄ M4X×0.7 1 種 2
35 WP-0430801-SC WASHER M4 ﾋﾗｻﾞｶﾞﾈ M4 2
36 WS-0410002-KN SPRING WASHER M4 ﾊﾞﾈｻﾞｶﾞﾈ M4 2
37 402-02038 SPACER GUIDE ｶﾞｲﾄﾞｽﾍﾟｰｻｰ 4
38 402-02219 WASHER_PC BOARD GUIDE ｷﾊﾞﾝｶﾞｲﾄﾞﾖｳﾜｯｼｬｰ 8
39 402-00992 SUPPORT_PC BOARD GUIDE ｷﾊﾞﾝｶﾞｲﾄﾞｻﾎﾟｰﾄ 2
40 SM-1030552-TN PLATE SCREW M3 L=5 ｻﾗﾈｼﾞ M3 L=5 8
41 402-09121 CENTER SUPPORT(3) ｾﾝﾀｰｻﾎﾟｰﾄ(3) 1
42 402-09253 REINFORCING PLATE ﾎｷｮｳﾌﾟﾚｰﾄ 1
43 402-09280 REINFORCING BAR ﾎｷｮｳﾊﾞｰ 1
44 402-08797 RETAINER(2)_PC BOARD(FIXED) ｷﾊﾞﾝｵｻｴ 2(ｺﾃｲ) 2
45 SM-6040602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ 4
46 EZ2-584-956-01 BOLT (CBSST4-6) ﾃｲﾄｳ ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ (CBSST4-6) 4
47 E2055-721-000 PULLEY SPACER ﾌﾟｰﾘｽﾍﾟｰｻ 2
48 SM-4042501-SC SCREW M4X0.7 L=25 ﾅﾍﾞｺﾈｼﾞ M4X0.7 L=25 2
49 SM-4041601-SC SCREW M4X0.7 L=16 ﾅﾍﾞｺﾈｼﾞ M4X0.7 L=16 10
50 EZ7-683-408-04 BOLT HEXAGON SOCKET 3X16 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X16 8
51 EZ7-683-421-04 BOLT HEXAGON SOCKET 4X12 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ(C4X12) 8
52 402-03944 SCREW M2.5 L=6 ｻﾗﾈｼﾞ M2.5 L=6 10
53 SM-6041002-TP SCREW M4X0.7 L=10 六角穴ﾎﾞﾙﾄ M4X0.7 L=10 2
54 EZ1-492-251-11 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾞﾂｸ ｱﾂﾌﾟ ﾋﾟﾝ 4) 1
A-95
A26-1
【RX-7】コンベア モータ部
【RX-7】Conveyor motor
21
3
3
21
7
21
21
11
13
12
14
9
22
21
8
6
20
8
22
19
15
16
15
16
19
19
13
12
14
19
14
12
13
19
14
12
13
13
19
15
1
18
17
3
5
10
10
7
21
3
3
43
43
50
50
41
41
40
42
44
45
44
45
48
49
47
49
48
28
27
27
26
27
27
24
29
38
37
35
23
38
29
33
34
36
36
36
32
30
31
30
32
36
34
33
36
36
35
37
29
38
27
25
27
31
46
39
48
49
47
49
48
46
40
42
18
17
21
7
3
16
12
14
15
16
19
21
7
2
4
A-96
A26-1
【RX-7】コンベア モータ部
【RX-7】Conveyor motor
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ4-454-261-01 BRACKET (L), MOTOR ﾓ-ﾀ ﾌﾞﾗｹﾂﾄ (L) 1
2 EZ1-492-228-11 MOTOR ASSY ﾓ-ﾀ ASSY (ﾊﾊﾞﾁﾖｳ 2) 1
3 EZ4-454-289-01 NUT, MOTOR PLATE ﾓ-ﾀ ｲﾀ ﾅﾂﾄ 6
4 EZ1-492-230-14 BRAKE CLUTCH ASSY ﾌﾞﾚ-ｷ ｸﾗﾂﾁ ASSY 1
5 EZ1-492-218-32 MOTOR ASSY ﾓ-ﾀ ASSY (ｺﾝﾍﾞｱ 3) 1
6 EZ1-492-218-42 MOTOR ASSY ﾓ-ﾀ ASSY (ｺﾝﾍﾞｱ 4) 1
7 EZ4-453-822-01 PULLEY (P1110-009-1) (A) ﾀｲﾐﾝｸﾞ ﾌﾟ-ﾘ (P1110-009-1) A 4
8 EZ4-453-824-01 PULLEY (P1110-011-1) (C) ﾀｲﾐﾝｸﾞ ﾌﾟ-ﾘ (P1110-011-1) C 2
9 EZ4-453-828-01 BELT (318-3GT-9), TIMING ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ (318-3GT-9) 1
10 EZ4-454-293-01 NUT, IDLER PLATE ｱｲﾄﾞﾗ-ﾊﾞﾝ ﾅﾂﾄ 2
11 EZ4-454-263-01 BRACKET, IDLER ｱｲﾄﾞﾗ- ﾌﾞﾗｹﾂﾄ 1
12 EZ4-453-830-01 IDLER (FIP1130), FLANGE PULLEY ﾌﾗﾝｼﾞﾂｷ ﾌﾟ-ﾘ- ｱｲﾄﾞﾗ- (FIP1130) 5
13 EZ4-454-295-01 COLLAR (DIA.13 DIA.8.2-L10.5) ｶﾗ- (ﾌｱｲ 13-ﾌｱｲ 8.2-L10.5) 5
14 EZ4-454-294-01 SHAFT, IDLER ｱｲﾄﾞﾗ- ｼﾔﾌﾄ 5
15 EZ4-454-367-01 COLLAR (DIA.7), IDLER ｱｲﾄﾞﾗ ｶﾗ- (ﾌｱｲ 7) 4
16 EZ4-454-516-01 BOLT (TSB4.5-20) ﾎﾞﾙﾄ (TSB4.5-20) 4
17 EZ4-718-724-05 NUT(1TYPE),HEXAGON(M4X0.7 SUS) ﾛﾂｶｸ ﾅﾂﾄ (1 ｼﾕ) (M4X0.7 SUS) 2
18 EZ4-718-767-03 SET-SCREW (M4X10 SUS), HEAD ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ (M4X10 SUS) 2
19 EZ7-683-423-04 BOLT,HEXAGON SOCKET 4X16 6 ｶｸｱﾅﾂｷ ﾎﾞﾙﾄ 4X16 14
20 EZ7-683-436-04 BOLT,HEXAGON SOCKET 5X12 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 5X12 4
21 EZ4-718-766-02 SET-SCREW (M3X5 SUS), HEAD ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ (M3X5 SUS) 10
22 EZ4-453-820-01 KEY (K04020), PARALLEL ﾍｲｺｳ ｷ- (K04020) 2
23 EZ4-454-262-01 BRACKET (R), MOTOR ﾓ-ﾀ ﾌﾞﾗｹﾂﾄ (R) 1
24 EZ1-492-218-12 MOTOR ASSY ﾓ-ﾀ ASSY (ｺﾝﾍﾞｱ 1) 1
25 EZ1-492-218-21 MOTOR ASSY ﾓ-ﾀ ASSY (ｺﾝﾍﾞｱ 2) 1
26 EZ1-492-227-11 MOTOR ASSY ﾓ-ﾀ ASSY (ﾊﾊﾞﾁﾖｳ 1) 1
27 EZ4-454-289-01 NUT, MOTOR PLATE ﾓ-ﾀ ｲﾀ ﾅﾂﾄ 6
28 EZ4-454-293-01 NUT, IDLER PLATE ｱｲﾄﾞﾗ-ﾊﾞﾝ ﾅﾂﾄ 1
29 EZ4-453-822-01 PULLEY (P1110-009-1) (A) ﾀｲﾐﾝｸﾞ ﾌﾟ-ﾘ (P1110-009-1) A 3
30 EZ4-453-830-01 IDLER (FIP1130), FLANGE PULLEY ﾌﾗﾝｼﾞﾂｷ ﾌﾟ-ﾘ- ｱｲﾄﾞﾗ- (FIP1130) 2
31 EZ4-454-294-01 SHAFT, IDLER ｱｲﾄﾞﾗ- ｼﾔﾌﾄ 2
32 EZ4-454-295-01 COLLAR (DIA.13 DIA.8.2-L10.5) ｶﾗ- (ﾌｱｲ 13-ﾌｱｲ 8.2-L10.5) 2
33 EZ4-454-367-01 COLLAR (DIA.7), IDLER ｱｲﾄﾞﾗ ｶﾗ- (ﾌｱｲ 7) 2
34 EZ4-454-516-01 BOLT (TSB4.5-20) ﾎﾞﾙﾄ (TSB4.5-20) 2
35 EZ4-718-724-05 NUT(1TYPE),HEXAGON(M4X0.7 SUS) ﾛﾂｶｸ ﾅﾂﾄ (1 ｼﾕ) (M4X0.7 SUS) 2
36 EZ7-683-423-04 BOLT,HEXAGON SOCKET 4X16 6 ｶｸｱﾅﾂｷ ﾎﾞﾙﾄ 4X16 12
37 EZ4-718-767-03 SET-SCREW (M4X10 SUS), HEAD ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ (M4X10 SUS) 2
38 EZ4-718-766-02 SET-SCREW (M3X5 SUS), HEAD ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ (M3X5 SUS) 6
39 EZ4-454-928-01 BRACKET, TOOL CHIP ｼﾞｸﾞ ﾁﾂﾌﾟ ﾌﾞﾗｹﾂﾄ 1
40 EZ4-454-549-01 PIN (B3X8) PARALLEL ﾍｲｺｳ ﾋﾟﾝ (B3X8) 4
41 EZ4-454-927-01 BLOCK, TOOL CHIP ｼﾞｸﾞ ﾁﾂﾌﾟ ﾌﾞﾛﾂｸ 2
42 EZ4-455-731-01 UNION (KJH02-M3), HALF ﾊ-ﾌ ﾕﾆｵﾝ (KJH02-M3) 4
43 EZ7-683-421-04 BOLT HEXAGON SOCKET 4X12 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ(C4X12) 4
44 EZ4-701-529-01 TIE MOUNT (MB1) ﾀｲﾏｳﾝﾄ (MB1) 2
45 EZ7-682-246-09 SCREW +K 3X5 +K 3X5 2
46 EZ4-454-520-01 HOLDER (VUK05), FIXED ｺﾃｲﾖｳ ﾎﾙﾀﾞ (VUK05) 2
47 EZ4-454-521-01 GENERATOR (VUH05-44A), VACUUM ｼﾝｸｳ ﾊﾂｾｲｷ (VUH05-44A) 2
48 EZ4-455-732-01 STRAIGHT (KJH02-04) ｲｹｲ ｽﾄﾚ-ﾄ (KJH02-04) 4
49 EZ7-630-003-47 TUBE(TU0425B-100-X3) ﾎﾟﾘｳﾚﾀﾝﾁﾕ-ﾌﾞ(TU0425B-100-X3) 4
50 EZ4-461-299-01 GLASS CHIP (7X7) ｶﾞﾗｽ ﾁﾂﾌﾟ (7X7) 4
