A-158 A39-2 【共通】 EF フィーダ用台車本体 -2 【 COMMON 】 Trolley unit EF Feeder - 2 ｲﾗｽﾄ番号 Ref.No. 品番 Part Number Description 品名 個数 Q'ty 備考 Remarks 55 401-43523 DUMMY_ANTENNA ﾀﾞﾐｰｱﾝﾃﾅ (1) 56 SM-6030602-TN SCREW M3X6 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ …
A-157
A39-2
【共通】EF フィーダ用台車本体-2
【COMMON】Trolley unit EF Feeder - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 401-43580 TABLE_UNIT
ﾃｰﾌﾞﾙﾕﾆｯﾄ
1
2 401-43509 BANK_SUB_ASSY
ﾊﾞﾝｸｻﾌﾞｱｯｼｰ
(1)
3 401-43511 BANK_BASE ﾊﾞﾝｸﾍﾞｰｽ (1)
4 401-03747 FIXING_BLOCK
ﾌｨｷｼﾝｸﾞﾌﾞﾛｯｸ
(1)
5 401-43512 FIXING_BLOCK_S
ﾌｨｷｼﾝｸﾞﾌﾞﾛｯｸ
(1)
6 401-03746 FIXING_PLATE ﾌｨｷｼﾝｸﾞﾌﾟﾚｰﾄ (1)
7 401-43513 FIXING_PLATE_S
ﾌｨｷｼﾝｸﾞﾌﾟﾚｰﾄ
(1)
8 401-43514 LOCK_SHAFT_S
ﾛｯｸｼｬﾌﾄ
(1)
9 401-43515 RAIL_GUIDE_19 ﾚｰﾙｶﾞｲﾄﾞ 19 (1)
10 401-43516 GUIDE_PLATE
ｶﾞｲﾄﾞﾌﾟﾚｰﾄ
(20)
11 SM-6041402-TN SCREW M4X0.7 L=14
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=14
(6)
12 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (16)
13 SM-3041052-TN SCREW M4 L=10
丸ねじ M4 L=10
(6)
14 SM-3030552-TN SCREW M3 L=5
ﾏﾙﾈｼﾞ M3 L=5
(40)
15 SM-1030552-TN PLATE SCREW M3 L=5 ｻﾗﾈｼﾞ M3 L=5 (20)
16 SM-8041852-TP SCREW M4 L=18
六角穴付き止めねじ M4 L=18
(4)
17 WP-0430801-SC WASHER M4
ﾋﾗｻﾞｶﾞﾈ M4
(6)
18 400-84699 E_BANK_SHIM_0.10 E ﾊﾞﾝｸｼﾑ 0.10 (6)
19 400-84715 E_BANK_SHIM_0.05
E ﾊﾞﾝｸｼﾑ 0.05
(4)
20 400-84714 E_BANK_SHIM_0.03
E ﾊﾞﾝｸｼﾑ 0.03
(4)
21 400-84713 E_BANK_SHIM_0.02 E ﾊﾞﾝｸｼﾑ 0.02 (4)
22 E3074-729-000 BEARING_SHIM_D
ﾍﾞｱﾘﾝｸﾞｼﾑ D
(2)
23 PH-0200080-U0 PARALLEL PIN TYPE B 2X8
平行ﾋﾟﾝ B 種 2×8
(19)
24 401-43634 FDC_BRACKET_ASSY FDC ﾌﾞﾗｹｯﾄｱｯｼｰ (1)
25 401-53342 FDC_BRACKET_STAY
FDC_ﾌﾞﾗｹｯﾄｽﾃｰ
(2)
26 HK-0791900-00 CONNECTOR
ｺﾈｸﾀﾈｼﾞ
(38)
27 401-43517 FDC_BRACKET_S FDC ﾌﾞﾗｹｯﾄ (1)
28 SL-6051092-TN SCREW M5 L=10
座金付き六角穴ﾎﾞﾙﾄ M5 L=10
(4)
29 401-42759 EF IF CBL 1-5 ASM
電動ﾌｨｰﾀﾞｰ IF 1-5 組
(1)
30 401-42760 EF IF CBL 6-10 ASM 電動ﾌｨｰﾀﾞｰ IF 6-10 組 (1)
31 401-42761 EF IF CBL 11-15 ASM
電動ﾌｨｰﾀﾞｰ IF 11-15 組
(1)
32 401-42762 EF IF CBL 16-20 ASM
電動ﾌｨｰﾀﾞｰ IF 16-19 組
(1)
33 401-46476 TROLLEY CONTACT(T)A PCB ASM ﾄﾛﾘｰ CONTACT(T)A 基板組 (1)
34 SL-6061292-TN SCREW M6 L=12
座金付き六角穴ﾎﾞﾙﾄ M6 L=12
(4)
35 401-43639 BANK_PCB_BOX
ﾊﾞﾝｸｷﾊﾞﾝﾎﾞｯｸｽ
(1)
36 401-43518 BANK_PCB_BASE_N ﾊﾞﾝｸｷﾊﾞﾝﾍﾞｰｽ N (1)
37 401-43519 USB_BR
USB ﾌﾞﾗｹｯﾄ
(1)
38 SL-4030691-SC SCREW M3 L=6
座金付きなべ小ねじ M3 L=6
(2)
39 401-42764 ELEC BANK PCB ASM ｴﾚｷﾊﾞﾝｸ基板組 (1)
40 SL-4030691-SC SCREW M3 L=6
座金付きなべ小ねじ M3 L=6
(4)
41 HX-0029400-00 FIXED BASE
ｺﾃｲ ﾍﾞｰｽ
(8)
42 SL-4030691-SC SCREW M3 L=6 座金付きなべ小ねじ M3 L=6 (8)
43 401-43520 BANK_PCB_COVER
ﾊﾞﾝｸｷﾊﾞﾝｶﾊﾞｰ
(1)
44 SL-4030691-SC SCREW M3 L=6
座金付きなべ小ねじ M3 L=6
(4)
45 400-01306 CABLE PROTECT SHEET ｹｰﾌﾞﾙﾌﾟﾛﾃｸﾄｼｰﾄ (1)
46 SL-4040691-SC SCREW M4 L=6
座金付きなべ小ねじ M4 L=6
(4)
47 401-63295 USB MEMORY (SP008GBUF3J06V1D)
USB ﾒﾓﾘｰ (SP008GBUF3J06V1D)
(1)
48 401-43521 REGULATION_BAR ﾚｷﾞｭﾚｰｼｮﾝﾊﾞｰ (1)
49 SM-6020302-UZ SCREW M2 L=3
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M2 L=3
(20)
50 401-43893 REGULATION_BAR_SUPPORT
ﾚｷﾞｭﾚｰｼｮﾝﾊﾞｰｻﾎﾟｰﾄ
(1)
51 SM-6030602-TN SCREW M3X6 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3X6 (4)
52 SM-6041002-TN SCREW
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ
(4)
53 401-43522 BANK_COVER
ﾊﾞﾝｸｶﾊﾞｰ
(1)
54 SM-0040601-SC SCREW M4X0.7 L=6 ﾄﾗｽｺﾈｼﾞ M4X0.7 L=6 (6)
A-158
A39-2
【共通】EF フィーダ用台車本体-2
【COMMON】Trolley unit EF Feeder - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
55 401-43523 DUMMY_ANTENNA
ﾀﾞﾐｰｱﾝﾃﾅ
(1)
56 SM-6030602-TN SCREW M3X6
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3X6
(3)
57 HX-0029400-00 FIXED BASE ｺﾃｲ ﾍﾞｰｽ (2)
58 HX-0034400-00 FIXED BASE
ｿｸｾﾝﾊﾟｰﾂ
(2)
59 SM-4040601-SC SCREW M4X0.7 L=6
ﾅﾍﾞｺﾈｼﾞ M4X0.7 L=6
(4)
60 PJ-3010605-03 HALF UNION ﾊｰﾌ ﾕﾆｵﾝ (1)
61 PH-0300062-C0 PARALLEL PIN TYPE B 3X6
平行ﾋﾟﾝ B 種 3X6
(4)
62 SM-6041402-TN SCREW M4X0.7 L=14
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=14
(2)
63 SM-6030502-TN SCREW M3 L=5 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3 L=5 (4)
64 ST-4020521-SN TAPPING SCREW D=2 L=5
ﾀｯﾋﾟﾝねじ D=2 L=5
(8)
65 SL-4030881-SC SCREW M3 L=8
座金付きなべ小ねじ M3 L=8
(12)
66 401-43365 ETF_POSITION_LABEL ETF_ﾎﾟｼﾞｼｮﾝ_ﾗﾍﾞﾙ (2)
67 BT-0600401-EB URETHANE TUBE BLACK 6X4
ﾎﾟﾘｳﾚﾀﾝ ﾁｭｰﾌﾞ 黒 6X4
(0.4)
68 SL-4040891-SC SCREW M4X8
ｻﾞｶﾞﾈﾂｷﾅﾍﾞｺﾈｼﾞ M4 L=8
(4)
69 401-46480 TROLLEY CONTACT(T)B PCB ASM ﾄﾛﾘｰ CONTACT(T)B 基板組 (1)
70 EZ4-000-207-02 PIN (2) LOCATE
ﾛｹ-ﾄ ﾋﾟﾝ (2)
(2)
71 EZ4-453-564-01 PLUG TAPER SCREW
ﾃ-ﾊﾟ ｽｸﾘﾕ- ﾌﾟﾗｸﾞ
(1)
72 EZ4-455-727-01 TABLE PLUG ﾃ-ﾌﾞﾙ ﾌﾟﾗｸﾞ (1)
73 EZ4-463-630-01 TABLE SPACER (R B)
ﾃ-ﾌﾞﾙ ｽﾍﾟ-ｻ- R B
(1)
74 EZ4-705-470-11 RING O (CO 0006A P9)
O ﾘﾝｸﾞ (CO 0006A P9)
(2)
75 EZ4-477-023-01 CONNECTOR BRACKET L ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ L (MOLD) (1)
76 EZ4-478-177-01 CLAMP CONNECTOR HARNESS
ｺﾈｸﾀ- ﾊ-ﾈｽ ｸﾗﾝﾊﾟ- (MOLD)
(2)
77 EZ4-477-022-01 CONNECTOR BRACKET R
ｺﾈｸﾀｰ ﾌﾞﾗｹｯﾄ R (MOLD)
(1)
78 401-43635 TABLE_BASE_L_ASSY ﾃｰﾌﾞﾙﾍﾞｰｽ L ｱｯｼｰ 1
79 SM-6040802-TN SCREW M4X0.7 L=8
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8
(2)
80 401-43525 SLIDE_BLOCK_L
ｽﾗｲﾄﾞﾌﾞﾛｯｸ L
(1)
81 SM-6051602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (4)
82 SM-6051002-TN SCREW
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ
(2)
83 401-43527 SP_SHAFT
ｽﾌﾟﾘﾝｸﾞｼｬﾌﾄ
(1)
84 SL-6041292-TN SCREW M4 L=12 座金付き六角穴ﾎﾞﾙﾄ M4 L=12 (1)
85 401-43524 TABLE_BASE_L
ﾃｰﾌﾞﾙﾍﾞｰｽ L
(1)
86 401-43529 CUTTER_RAIL
ｶｯﾀｰﾚｰﾙ
(1)
87 EZ4-113-107-01 FOLLOWER (CF8VB) CAM ｶﾑ ﾌｵﾛｱ (CF8VB) (2)
88 EZ4-453-803-01 CUSHION CUTTER UNIT
ｶﾂﾀ- ﾕﾆﾂﾄ ｸﾂｼﾖﾝ
(1)
89 401-43636 TABLE_BASE_R_ASSY
ﾃｰﾌﾞﾙﾍﾞｰｽ R ｱｯｼｰ
1
90 401-43529 CUTTER_RAIL ｶｯﾀｰﾚｰﾙ (1)
91 SM-6040802-TN SCREW M4X0.7 L=8
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8
(2)
92 401-43530 SLIDE_BLOCK_R_
ｽﾗｲﾄﾞﾌﾞﾛｯｸ R
(1)
93 SM-6051602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (4)
94 SM-6051002-TN SCREW
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ
(2)
95 401-43532 ACT_BRACKET
ACT ﾌﾞﾗｹｯﾄ
(1)
96 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (5)
97 401-43527 SP_SHAFT
ｽﾌﾟﾘﾝｸﾞｼｬﾌﾄ
(1)
98 SL-6041292-TN SCREW M4 L=12
座金付き六角穴ﾎﾞﾙﾄ M4 L=12
(1)
99 HX-0015000-00 CABLE CLAMP ｹｰﾌﾞﾙｸﾘｯﾌﾟ (1)
100 WT-0430002-KN WASHER M4
ﾊﾂｷｻﾞｶﾞﾈ M4
(1)
101 SM-6040802-TN SCREW M4X0.7 L=8
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8
(2)
102 401-43528 TABLE_BASE_R ﾃｰﾌﾞﾙﾍﾞｰｽ R (1)
103 EZ4-149-845-01 ACTUATOR (D40A-A1) SWITCH
ﾄﾞｱ ｽｲﾂﾁ ｱｸﾁﾕｴ-ﾀ (D40A-A1)
(1)
104 EZ4-113-107-01 FOLLOWER (CF8VB) CAM
ｶﾑ ﾌｵﾛｱ (CF8VB)
(2)
105 EZ4-453-803-01 CUSHION CUTTER UNIT ｶﾂﾀ- ﾕﾆﾂﾄ ｸﾂｼﾖﾝ (1)
106 SM-6051602-TN SCREW
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ
3
107 SM-6051602-TN SCREW
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ
3
108 401-43638 SHOOT_ASSY ｼｭｰﾄｱｯｼｰ 1
A-159
A39-2
【共通】EF フィーダ用台車本体-2
【COMMON】Trolley unit EF Feeder - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
109 401-58881 SHOOT_NI
ｼｭｰﾄ_Ni
(1)
110 401-51345 SHOOT_SUPPORT
ｼｭｰﾄｻﾎﾟｰﾄ
(1)
111 SM-3030552-TN SCREW M3 L=5 ﾏﾙﾈｼﾞ M3 L=5 (2)
112 401-58883 TAPE_GUIDE_PLATE
ﾃｰﾌﾟｶﾞｲﾄﾞﾌﾟﾚｰﾄ
(1)
113 401-58885 TAPE_GUIDE_CHAIN
ﾃｰﾌﾟｶﾞｲﾄﾞﾁｪｰﾝ
(2)
114 SM-6020602-TN SCREW M2 L=6 ﾛｯｶｸｱﾅﾎﾞﾙﾄ M2 L=6 (4)
115 NM-6020001-SC NUT M2
ﾛﾂｶｸﾅﾂﾄ M2 1 ｼﾕ
(6)
116 401-58882 TAPE_GUIDE_CHAIN_BR
ﾃｰﾌﾟｶﾞｲﾄﾞﾁｪｰﾝﾌﾞﾗｹｯﾄ
(1)
117 401-58884 TAPE_GUDE_FIX_PLATE ﾃｰﾌﾟｶﾞｲﾄﾞﾌｨｸｽﾌﾟﾚｰﾄ (1)
118 SL-6030692-TN SCREW M3 L=6
座金付き六角穴ボルト M3 L=6
(2)
119 NM-6030003-SC NUT M3
ﾛﾂｶｸﾅﾂﾄ M3
(4)
120 WP-0320501-SC WASHER M3 ﾋﾗｻﾞｶﾞﾈ M3 (4)
121 WS-0310002-KN SPRING WASHER M3
ﾊﾞﾈｻﾞｶﾞﾈ 3.1X5.9X0.7
(4)
122 SM-3040652-TN SCREW M4 L=6
ﾏﾙﾈｼﾞ M4 L=6
2
123 SM-3030552-TN SCREW M3 L=5 ﾏﾙﾈｼﾞ M3 L=5 2
124 401-43537 SUPPORT_BAR
ｻﾎﾟｰﾄﾊﾞｰ
1
125 SM-3040552-TN SCREW M4 L=5
ﾏﾙﾈｼﾞ M4 L=5
2
126 401-43538 DISPOSAL_DUCT_BRACKET ﾃﾞｨｽﾎﾟｰｻﾞﾙﾀﾞｸﾄﾌﾞﾗｹｯﾄ 2
127 SM-6040802-TN SCREW M4X0.7 L=8
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8
8
128 401-43539 STAND_COVER_TOP
ｽﾀﾝﾄﾞｶﾊﾞｰﾄｯﾌﾟ
1
129 SM-1040801-SC SCREW M4X0.7 L=8 ｻﾗｺﾈｼﾞ M4X0.7 L=8 4
130 EZ4-453-863-01 DISPOSAL DUCT
ﾊｲｷ ﾀﾞｸﾄ
1
131 401-54185 CUTTER_UNIT
ｶｯﾀｰﾕﾆｯﾄ
1
132 401-69472 IFS-NX CAN CART ASM (RX-7) IFS-NX CAN 台車組 (RX-7) 1 OPTION
133 401-69045 BANK ID PCB ASM
ﾊﾞﾝｸ ID 基板組
(1)
134 SL-4030691-SC SCREW M3 L=6
座金付きなべ小ねじ M3 L=6
(1)
135 HX-0029400-00 FIXED BASE ｺﾃｲ ﾍﾞｰｽ (1)
136 HX-0023300-00 CABLE BAND
ｿｸｾﾝ ﾊﾞﾝﾄﾞ
(3)
137 401-69297 IFS PCB BOX
IFS ｷﾊﾞﾝ ﾎﾞｯｸｽ
(1)
138 401-69298 IFS PCB COVER IFS ｷﾊﾞﾝ ｶﾊﾞｰ (1)
139 SL-4030691-SC SCREW M3 L=6
座金付きなべ小ねじ M3 L=6
(3)
140 SL-4040891-SC SCREW M4 L=8
ｻﾞｶﾞﾈﾂｷ ﾅﾍﾞｺﾈｼﾞ M4 L=8
(4)
