A-162 A41 【共通】梱包添付品 【 COMMON 】 Accessories 1 2 3 4 6 7 8 9 11 13 10 5
A-161
A40
【共通】EF フィーダ用カッターユニット
【COMMON】Cutter unit EF Feeder
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 401-54185 CUTTER_UNIT
ｶｯﾀｰﾕﾆｯﾄ
1
2 401-51138 BASE(CUTTER)
ﾍﾞ-ｽ (ｶｯﾀｰﾕﾆｯﾄ)
(1)
3 PH-0300062-C0 PARALLEL PIN TYPE B 3X6 平行ﾋﾟﾝ B 種 3X6 (4)
4 401-60819 BASE_SUPPORT_L
ﾍﾞｰｽｻﾎﾟｰﾄ L
(1)
5 401-60820 BASE_SUPPORT_R
ﾍﾞｰｽｻﾎﾟｰﾄ R
(1)
6 SM-6031002-TN SCREW M3 L=10 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3 L=10 (2)
7 SM-6031602-TN SCREW M3 L=16
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3 L=16
(2)
8 EZ3-215-222-01 HANDLE(A-1042-C-4) SHAFT
ﾏﾙﾎﾞｳ ﾄﾂﾃ(A-1042-C-4)
(2)
9 EZ7-683-452-04 BOLT HEXAGON SOCKET 6X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 6X10 (4)
10 EZ4-453-559-01 LM GUIDE(SRS15MUUE)
LM ｶﾞｲﾄﾞ(SRS15MUUE)
(2)
11 SM-6031002-TN SCREW M3 L=10
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3 L=10
(8)
12 401-51154 SHIM_UPPER_EDGE ｼﾑ(ｳﾜﾊﾞ) (3)
13 401-51139 UPPER_EDGE
ｳﾜﾊﾞ
(1)
14 SL-6052092-TN SCREW M5 L=20
座金付き六角穴ボルト M5 L=20
(4)
15 401-51144 GUIDE_LOWER_EDGE ｼﾀﾊﾞｶﾞｲﾄﾞ (1)
16 401-61183 LOWER_EDGE_GUIDE_SHIM_100
ｼﾀﾊﾞｶﾞｲﾄﾞｼﾑ 100
(1)
17 401-61184 LOWER_EDGE_GUIDE_SHIM_50
ｼﾀﾊﾞｶﾞｲﾄﾞｼﾑ 50
(2)
18 401-51153 TAPPING_SCREW_4X16 ﾀｯﾋﾟﾝﾈｼﾞ 4×16 (4)
19 401-51140 SLIDE_BASE_LOWER_EDGE
ｽﾗｲﾄﾞﾍﾞ-ｽ (ｼﾀﾊﾞ)
(1)
20 SL-6031492-TN SCREW M3 L=14
座金付き六角穴ボルト M3 L=14
(16)
21 401-51141 LOWER_EDGE_A ｼﾀﾊﾞ A (3)
22 401-51142 LOWER_EDGE_B
ｼﾀﾊﾞ B
(3)
23 401-62481 PLATE_T0.2_CD
ﾌﾟﾚｰﾄＴ0.2_CD
(6)
24 SL-6051692-TN SCREW M5 L=16 座金付き六角穴ボルト M5 L=16 (12)
25 401-51150 COVER_LOWER_EDGE
ｶﾊﾞｰ(ｼﾀﾊﾞ)
(1)
26 SL-6040892-TN SCREW M4 L=8
座金付き六角穴ボルト M4 L=8
(3)
27 401-51145 CYLINDER_BRACKET ｼﾘﾝﾀﾞﾌﾞﾗｹｯﾄ (2)
28 401-51148 SV_BRACKET
SV ﾌﾞﾗｹｯﾄ
(1)
29 SL-6051292-TN SCREW M5 L=12
座金付き六角穴ボルト M5 L=12
(4)
30 401-46767 SOLENOID VALVE ASSY (CUTTER) ｿﾚﾉｲﾄﾞ ﾊﾞﾙﾌﾞ 組 (CUTTER) (1)
31 SL-6030692-TN SCREW M3 L=6
座金付き六角穴ボルト M3 L=6
(2)
32 EZ4-476-170-01 AIR CYLINDER(RDQA40-60)
ｸｳｱﾂ ｼﾘﾝﾀﾞ(RDQA40-60)
(1)
33 SL-6061692-TN SCREW M6 L=16 ｻﾞｶﾞﾈﾂｷﾛｯｶｸｱﾅﾎﾞﾙﾄ M6 L=16 (4)
34 EZ4-426-151-01 SILENCER(AN10-01)
ｻｲﾚﾝｻ(AN10-01)
(2)
35 EZ4-447-092-01 UNION (KQ2L04-01NS) ELBOW
ｴﾙﾎﾞ ﾕﾆｵﾝ (KQ2L04-01NS)
(4)
36 EZ4-447-092-11 UNION(KQ2L06-01NS) ELBOW ｴﾙﾎﾞ ﾕﾆｵﾝ(KQ2L06-01NS) (1)
37 401-51152 COVER_SUPPORT
ｶﾊﾞｰｻﾎﾟｰﾄ
(1)
38 SL-6061692-TN PARALLEL PIN TYPE B 3X6
平行ﾋﾟﾝ B 種 3X6
(2)
39 401-51143 CONNECTION_BLOCK ｺﾈｸｼｮﾝﾌﾞﾛｯｸ (1)
40 SM-6052502-TN SCREW
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ
(2)
41 401-51147 WASHER 6-20
ｻﾞｶﾞﾈ
(2)
42 401-51146 COLLAR ｶﾗｰ (1)
43 SM-6083002-TN SCREW M8 L=30
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M8 L=30
(1)
44 401-51151 COVER_CUTTER
ｶﾊﾞｰ(ｶｯﾀｰﾕﾆｯﾄ)
(1)
45 401-60822 TAPE_GUARD_VE ﾃｰﾌﾟｶﾞｰﾄﾞ VE (1)
46 SM-0040801-SC SCREW M4X8
トラスネジ M4X8
(4)
47 EZ4-453-560-01 FILTER(FSL200-66-B) INLINE
ｲﾝﾗｲﾝ ﾌｲﾙﾀ(FSL200-66-B)
(1)
48 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (2)
49 EZ4-457-931-11 TAPE(40) FIXED
ｺﾃｲ ﾃ-ﾌﾟ(40)
(1)
50 EZ7-630-003-47 TUBE(TU0425B-100-X3)
ﾎﾟﾘｳﾚﾀﾝﾁﾕ-ﾌﾞ(TU0425B-100-X3)
(0.445)
51 EZ7-632-385-50 TUBE POLYURETHAN (TU0604B) ﾎﾟﾘｳﾚﾀﾝ ﾁﾕ-ﾌﾞ (TU0604B) 4X6X3M (0.24)
52 EZ4-722-956-01 LABEL(SILVER) BLANK
ﾌﾞﾗﾝｸ ﾗﾍﾞﾙ ｷﾞﾝ(TTC82YS-10)
(3)
53 EZ4-716-434-11 TIE INSULOCK(AB100 BLACK)
ｲﾝｼﾕﾛﾂｸ ﾀｲ(AB100 ｸﾛ)
(1)
54 401-58937 LOWER_EDGE_SHIM_CD ｼﾀﾊﾞｼﾑ CD (6)
A-162
A41
【共通】梱包添付品
【COMMON】Accessories
1
2
3
4 6
7
8
9
11 13
10
5
A-163
A41
【共通】梱包添付品
【COMMON】Accessories
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 401-44555 EF ARRANGE CBL BLACKET ASM EF ARRANGE CBL BLACKET ASM 1
2 EZ1-846-577-12 CABLE BEFORE AND BEHIDN I/F 前後 I/F ｹｰﾌﾞﾙ 1
3 EZ4-454-592-01 DUST CAP (DL-P-D/C) ﾀﾞｽﾄ ｷｬｯﾌﾟ (DL-P-D/C) 2
4 EZ4-456-308-01 SHEET (S) FOOT ｱｼ ﾖｳ ｼ-ﾄ (S) 2
5 EZ4-456-309-01 BRACKET JOINT ﾚﾝｹﾂ ﾌﾞﾗｹｯﾄ 2
6 EZ4-761-958-01 SHEET (LEG) ｱｼ ﾖｳ ｼ-ﾄ 4
7 EZ4-761-962-01 CAP BOLT (CP-30-BC-20) ﾎﾞﾙﾄ ｷﾔﾂﾌﾟ (CP-30-BC-20) 4
8 EZ7-683-473-04 BOLT HEXAGON SOCKET 8X20 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 8X20 8
9 EZ7-688-007-12 W8 MIDDLE W8 MIDDLE 8
10 EZ1-845-148-11 MEMORY USB USB ﾒﾓﾘ (USM4GR B) 1
11 401-46085 RX-7 INSTRUCTION MANUAL(ST) RX-7 ﾄﾘｱﾂｶｲｾﾂﾒｲｼｮ(ST) 1
12 401-46086 RX-7 INSTRUCTION MANUAL(EN) RX-7 ﾄﾘｱﾂｶｲｾﾂﾒｲｼｮ(EN) 1
13 401-46087 RX-7 INSTRUCTION MANUAL(CH) RX-7 ﾄﾘｱﾂｶｲｾﾂﾒｲｼｮ(CH) 1
