A-178 A46 【 RX-7R 】固定バンク -3 【 RX-7R 】 BANK UNIT K - 3 １ Ａ ５５ ５４ ５４ ５１ ５２ ６６ ６５ ５６ ５７ ６０ ６０ ５９ ５９ ６１ ５８ ６２ ３３ ３３ ３２ ３１ ３４ ３６ ３５ Ａ ２８ ３５ ３７ ２９ Ｂ Ｂ １０ １０ １１ １１ １２ １２ １３ １３ ９ ８ １４ １５ １７ １５ １８ １７ １６ １９ １９ ２０ ２３ ２０ ２３ ２０ ２１ ２１…
A-177
A45
【RX-7R】固定バンク-2
【RX-7R】BANK UNIT K - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
103 401-67560 SHOOT_K_B ｼｭｰﾄ K_B (1)
104 401-67562 TAPE_GUIDE_PLATE_KB ﾃｰﾌﾟｶﾞｲﾄﾞﾌﾟﾚｰﾄ KB (1)
105 401-67561 TAPE_GUIDE_FIX_PLATE ﾃｰﾌﾟｶﾞｲﾄﾞﾌｨｸｽﾌﾟﾚｰﾄ (1)
106 401-67563 SPONGE_SHOOT ｽﾎﾟﾝｼﾞｼｭｰﾄ (1)
107 WP-0320501-SC WASHER M3 ﾋﾗｻﾞｶﾞﾈ M3 (4)
108 WS-0310002-KN SPRING WASHER M3 ﾊﾞﾈｻﾞｶﾞﾈ M3 (4)
109 NM-6030003-SC NUT M3X0.5 TYPE3 六角 ﾅｯﾄ M3X0.5 3 種 (4)
110 CM-3002000-04 FINGER INJURY CAUTION LABEL (50) 指怪我注意ｼｰﾙ (50) (1)
111 401-91206 SCREW_M4_L14 ｽｸﾘｭｰ_M4_L14 4
112 WP-0430801-SC WASHER M4 ﾋﾗｻﾞｶﾞﾈ M4 2
113 401-43537 SUPPORT_BAR ｻﾎﾟｰﾄﾊﾞｰ 1
114 SL-6040892-TN SCREW M4 L=8 座金付き六角穴ﾎﾞﾙﾄ M4 L=8 2
115 CM-3002000-04 FINGER INJURY CAUTION LABEL (50) 指怪我注意ｼｰﾙ (50) 1
116 401-67576 DISPOSAL_DUCT ﾊｲｷﾀﾞｸﾄ 1
117 401-67593 SPONGE_FRONT ｽﾎﾟﾝｼﾞﾌﾛﾝﾄ 1
118 401-67594 SPONGE_SIDE ｽﾎﾟﾝｼﾞｻｲﾄﾞ 2
119 SL-6030692-TN SCREW M3 L=6 座金付き六角穴ﾎﾞﾙﾄ M3 L=6 4
120 401-73042 FAN_UNIT ﾌｧﾝﾕﾆｯﾄ 1
121 401-73038 FAN_BASE ﾌｧﾝﾍﾞｰｽ (1)
122 401-73039 FAN_COVER ﾌｧﾝｶﾊﾞｰ (1)
123 SL-4030691-SC SCREW M3 L=6 座金付きなべ小ねじ M3 L=6 (12)
124 401-72514 TROLLY FAN ASM TROLLY FAN ASM (2)
125 400-93509 X_FAN40_GUARD ﾌｧﾝｶﾞｰﾄﾞ 40 (2)
126 SL-4032591-SC SCREW M3 L=25 座金付きなべ小ねじ M3 L=25 (4)
127 401-73040 FAN_BASE_BR ﾌｧﾝﾍﾞｰｽ BR (2)
128 SL-6030692-TN SCREW M3 L=6 座金付き六角穴ﾎﾞﾙﾄ M3 L=6 (4)
129 401-73037 PROHIBIT_SEAL_M ｶｼﾞｭｳｷﾝｼｼｰﾙ M (1)
130 SL-6040892-TN SCREW M4 L=8 座金付き六角穴ﾎﾞﾙﾄ M4 L=8 4
131 HX-0067100-0B GROMMET ｸﾞﾛﾒｯﾄ 0.2
A-178
A46
【RX-7R】固定バンク-3
【RX-7R】BANK UNIT K - 3
１
Ａ
５５
５４
５４
５１
５２
６６
６５
５６
５７
６０
６０
５９
５９
６１
５８
６２
３３
３３
３２
３１
３４
３６
３５
Ａ
２８
３５
３７
２９
Ｂ
Ｂ
１０
１０
１１
１１
１２
１２
１３
１３
９
８
１４
１５
１７
１５
１８
１７
１６
１９
１９
２０
２３
２０
２３
２０
２１
２１
２１
２２
２４
２７
２６
２５
１８
３０
３０
３８
３９
４０
４３
４５
４７
４８
４８
４６
４８
４７
４６
４８
４６
４８
４８
４７
４８
４７
４８
４６
４９
５０
６３ ６４
５３
６６
６７
Ｃ
Ｃ
Ｄ
Ｄ
Ｅ
Ｅ
５
５
４４
３
４
２
７
６
７
６
A-179
A46
【RX-7R】固定バンク-3
【RX-7R】BANK UNIT K - 3
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 401-69726 CUTTER_UNIT_K ｶｯﾀｰﾕﾆｯﾄ K 1
2 401-69744 BASE_CUTTER_A
ﾍﾞｰｽｶｯﾀｰ A
(1)
3 401-69745 BASE_CUTTER_B ﾍﾞｰｽｶｯﾀｰ B (1)
4 SM-6051002-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (16)
5 PH-0300080-U0 PARALLEL PIN TYPE B 3X8 平行ﾋﾟﾝ B 種 3×8 (2)
6 401-69747 GUIDE_ANGLE ｶﾞｲﾄﾞｱﾝｸﾞﾙ (2)
7 SM-6051002-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (4)
8 E1046-717-000 X COVER HANDLE
X ｶﾊﾞｰﾊﾝﾄﾞﾙ
(1)
9 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (2)
10 401-67529 SUB_BASE_CUTTER ｻﾌﾞﾍﾞｰｽｶｯﾀｰ (2)
11 401-67577 LINEAR GUIDE ﾘﾆｱｶﾞｲﾄﾞ (2)
12 SM-6041602-TN SCREW M4X16 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X16 (4)
13 SL-6043092-TN SCREW M4 L=30 座金付き六角穴ﾎﾞﾙﾄ M4 L=30 (8)
14 401-67548 SLIDE_BASE_LOWER_EDGE
ｽﾗｲﾄﾞﾍﾞｰｽﾛﾜｰｴｯｼﾞ
(1)
15 SB-7040001-00 BEARING ころがり軸受 (4)
16 401-67578 HOLD_PLATE ﾎｰﾙﾄﾞﾌﾟﾚｰﾄ (1)
17 401-67549 HOLD_COLLAR ﾎｰﾙﾄﾞｶﾗｰ (2)
18 401-67550 HOLDER_GUIDE_SHAFT ﾎﾙﾀﾞｶﾞｲﾄﾞｼｬﾌﾄ (2)
19 EZ4-453-818-01 BOLT (CBSTSR3-5) ﾁﾖｳ ｺﾞｸ ﾃｲﾄｳ ﾎﾞﾙﾄ (CBSTSR3-5) (2)
20 401-67579 SPRING_GUIDE_SHAFT
ｽﾌﾟﾘﾝｸﾞｶﾞｲﾄﾞｼｬﾌﾄ
(3)
21 SM-1030601-SC SCREW M3X6 ｻﾗﾈｼﾞ M3X6 (3)
22 401-67580 HOLD_SPRING ﾎｰﾙﾄﾞｽﾌﾟﾘﾝｸﾞ (1)
23 RE-0250000-K0 E-RING 2.5 E 形止め輪 2.5 (2)
24 401-67581 FACE_PLATE ﾌｪｲｽﾌﾟﾚｰﾄ (1)
25 WP-0320501-SC WASHER M3 ﾋﾗｻﾞｶﾞﾈ M3 (4)
26 WS-0310002-KN SPRING WASHER M3
ﾊﾞﾈｻﾞｶﾞﾈ M3
(4)
27 NM-6030003-SC NUT M3X0.5 TYPE3 六角 ﾅｯﾄ M3X0.5 3 種 (4)
28 401-67551 CONNECTION_BLOCK ｺﾈｸｼｮﾝﾌﾞﾛｯｸ (1)
29 SL-6053092-TN SCREW M5 L=30 座金付き六角穴ﾎﾞﾙﾄ M5 L=30 (2)
30 SL-6041692-TN SCREW M4 L=16 座金付き六角穴ﾎﾞﾙﾄ M4 L=16 (8)
31 401-67582 SPACER ｽﾍﾟｰｻ (2)
32 PA-5003501-00 AIR CYLINDER
ｴｱ ｼﾘﾝﾀﾞ
(1)
33 PC-0152040-00 SPEED CONTROLLER ｽﾋﾟｰﾄﾞ ｺﾝﾄﾛｰﾗ (2)
34 SM-6084002-TN SCREW M8 L=40 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M8 L=40 (4)
35 401-67585 WASHER_10_21 ﾜｯｼｬ 10_21 (2)
36 401-67586 COLLAR ｶﾗｰ (1)
37 SM-6103002-TN SCREW M10 L=30 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M10 L=30 (1)
38 401-69746 UPPER_EDGE
ｱｯﾊﾟｰｴｯｼﾞ
(1)
39 401-67587 SHIM_UPPER_EDGE ｼﾑｱｯﾊﾟｰｴｯｼﾞ (2)
40 400-84713 E_BANK_SHIM_0.02 E ﾊﾞﾝｸｼﾑ 0.02 (2)
41 400-84714 E_BANK_SHIM_0.03 E ﾊﾞﾝｸｼﾑ 0.03 (2)
42 400-84715 E_BANK_SHIM_0.05 E ﾊﾞﾝｸｼﾑ 0.05 (2)
43 400-84699 E_BANK_SHIM_0.10 E ﾊﾞﾝｸｼﾑ 0.10 (2)
44 SM-6051002-TN SCREW
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ
(4)
45 SM-6031402-TP SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (2)
46 401-69742 LOWER_EDGE_A ﾛﾜｰｴｯｼﾞ A (4)
47 401-69743 LOWER_EDGE_B ﾛﾜｰｴｯｼﾞ B (4)
48 SL-6051692-TN SCREW M5 L=16 座金付き六角穴ﾎﾞﾙﾄ M5 L=16 (16)
49 401-67588 COVER_LOWER_EDGE ｶﾊﾞｰﾛﾜｰｴｯｼﾞ (1)
50 SL-6040892-TN SCREW M4 L=8
座金付き六角穴ﾎﾞﾙﾄ M4 L=8
(2)
