A-184
A48
【共通】IFS-NX ユニット-2
【COMMON】IFS-NX unit - 2
4
5
6
7
9
10
17
11
17
11
16
15
14
14
12
12
13
13
22
36
38
37
39
40
41
42
43
44
45
46
48
49
50
51
52
53
54
54
55
56
57
59
59
58
57
59
58
59
60
61
66
79
80
81
82
83
84
85
106
78
90
91
94
95
96
97
98
99
101
100
101
107
18 21
8
61
2
92
93
102
A
A
B
B
C
C
1
67
131
23
125
124
86
126
127
89
126
96
35
127
128
129
129
65
65
65
64
64
65
63
62
68
66
34
24
34
28
28
27
25
25
26
29 32
122
115
109
110
111
108
123
33
69
47
103
73
70
76
75
76
87
104
71
77
72
3
74
74
105
88
116
117
118
114
113
114
113
115
115
112
119
120
121
130
127
A-185
A48
【共通】IFS-NX ユニット-2
【COMMON】IFS-NX unit - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 401-43580 TABLE_UNIT ﾃｰﾌﾞﾙﾕﾆｯﾄ 1
2 401-43509 BANK_SUB_ASSY ﾊﾞﾝｸｻﾌﾞｱｯｼｰ (1)
3 401-43511 BANK_BASE ﾊﾞﾝｸﾍﾞｰｽ (1)
4 401-03747 FIXING_BLOCK ﾌｨｷｼﾝｸﾞﾌﾞﾛｯｸ (1)
5 401-43512 FIXING_BLOCK_S ﾌｨｷｼﾝｸﾞﾌﾞﾛｯｸ (1)
6 401-03746 FIXING_PLATE ﾌｨｷｼﾝｸﾞﾌﾟﾚｰﾄ (1)
7 401-43513 FIXING_PLATE_S ﾌｨｷｼﾝｸﾞﾌﾟﾚｰﾄ (1)
8 401-43514 LOCK_SHAFT_S ﾛｯｸｼｬﾌﾄ (1)
9 401-43515 RAIL_GUIDE_19 ﾚｰﾙｶﾞｲﾄﾞ 19 (1)
10 401-43516 GUIDE_PLATE ｶﾞｲﾄﾞﾌﾟﾚｰﾄ (20)
11 SM-6041402-TN SCREW M4X0.7 L=14 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=14 (6)
12 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (16)
13 SM-3041052-TN SCREW M4 L=10 丸ねじ M4 L=10 (6)
14 SM-3030552-TN SCREW M3 L=5 ﾏﾙﾈｼﾞ M3 L=5 (40)
15 SM-1030552-TN PLATE SCREW M3 L=5 ｻﾗﾈｼﾞ M3 L=5 (20)
16 SM-8041852-TP SCREW M4 L=18 六角穴付き止めねじ M4 L=18 (4)
17 WP-0430801-SC WASHER M4 ﾋﾗｻﾞｶﾞﾈ M4 (6)
18 400-84699 E_BANK_SHIM_0.10 E ﾊﾞﾝｸｼﾑ 0.10 (6)
19 400-84715 E_BANK_SHIM_0.05 E ﾊﾞﾝｸｼﾑ 0.05 (4)
20 400-84714 E_BANK_SHIM_0.03 E ﾊﾞﾝｸｼﾑ 0.03 (4)
21 400-84713 E_BANK_SHIM_0.02 E ﾊﾞﾝｸｼﾑ 0.02 (4)
22 E3074-729-000 BEARING_SHIM_D ﾍﾞｱﾘﾝｸﾞｼﾑ D (2)
23 PH-0200080-U0 PARALLEL PIN TYPE B 2X8 平行ﾋﾟﾝ B 種 2×8 (19)
24 401-43634 FDC_BRACKET_ASSY FDC ﾌﾞﾗｹｯﾄｱｯｼｰ (1)
25 401-53342 FDC_BRACKET_STAY FDC_ﾌﾞﾗｹｯﾄｽﾃｰ (2)
26 HK-0791900-00 CONNECTOR ｺﾈｸﾀﾈｼﾞ (38)
27 401-43517 FDC_BRACKET_S FDC ﾌﾞﾗｹｯﾄ (1)
28 SL-6051092-TN SCREW M5 L=10 座金付き六角穴ﾎﾞﾙﾄ M5 L=10 (4)
29 401-42759 EF IF CBL 1-5 ASM 電動ﾌｨｰﾀﾞｰ IF 1-5 組 (1)
30 401-42760 EF IF CBL 6-10 ASM 電動ﾌｨｰﾀﾞｰ IF 6-10 組 (1)
31 401-42761 EF IF CBL 11-15 ASM 電動ﾌｨｰﾀﾞｰ IF 11-15 組 (1)
32 401-42762 EF IF CBL 16-20 ASM 電動ﾌｨｰﾀﾞｰ IF 16-19 組 (1)
33 401-46476 TROLLEY CONTACT(T)A PCB ASM ﾄﾛﾘｰ CONTACT(T)A 基板組 (1)
34 SL-6061292-TN SCREW M6 L=12 座金付き六角穴ﾎﾞﾙﾄ M6 L=12 (4)
35 401-43639 BANK_PCB_BOX ﾊﾞﾝｸｷﾊﾞﾝﾎﾞｯｸｽ (1)
36 401-43518 BANK_PCB_BASE_N ﾊﾞﾝｸｷﾊﾞﾝﾍﾞｰｽ N (1)
37 401-43519 USB_BR USB ﾌﾞﾗｹｯﾄ (1)
38 SL-4030691-SC SCREW M3 L=6 座金付きなべ小ねじ M3 L=6 (2)
39 401-42764 ELEC BANK PCB ASM ｴﾚｷﾊﾞﾝｸ基板組 (1)
40 SL-4030691-SC SCREW M3 L=6 座金付きなべ小ねじ M3 L=6 (4)
41 HX-0029400-00 FIXED BASE ｺﾃｲ ﾍﾞｰｽ (8)
42 SL-4030691-SC SCREW M3 L=6 座金付きなべ小ねじ M3 L=6 (8)
43 401-43520 BANK_PCB_COVER ﾊﾞﾝｸｷﾊﾞﾝｶﾊﾞｰ (1)
44 SL-4030691-SC SCREW M3 L=6 座金付きなべ小ねじ M3 L=6 (4)
45 400-01306 CABLE PROTECT SHEET ｹｰﾌﾞﾙﾌﾟﾛﾃｸﾄｼｰﾄ (1)
46 SL-4040691-SC SCREW M4 L=6 座金付きなべ小ねじ M4 L=6 (4)
47 401-63295 USB MEMORY (SP008GBUF3J06V1D) USB ﾒﾓﾘｰ (SP008GBUF3J06V1D) (1)
48 401-43521 REGULATION_BAR ﾚｷﾞｭﾚｰｼｮﾝﾊﾞｰ (1)
49 SM-6020302-UZ SCREW M2 L=3 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M2 L=3 (20)
50 401-43893 REGULATION_BAR_SUPPORT ﾚｷﾞｭﾚｰｼｮﾝﾊﾞｰｻﾎﾟｰﾄ (1)
51 SM-6030602-TN SCREW M3X6 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3X6 (4)
52 SM-6041002-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (4)
53 401-43522 BANK_COVER ﾊﾞﾝｸｶﾊﾞｰ (1)
54 SM-0040601-SC SCREW M4X0.7 L=6 ﾄﾗｽｺﾈｼﾞ M4X0.7 L=6 (6)
A-186
A48
【共通】IFS-NX ユニット-2
【COMMON】IFS-NX unit - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
55 401-43523 DUMMY_ANTENNA ﾀﾞﾐｰｱﾝﾃﾅ (1)
56 SM-6030602-TN SCREW M3X6 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3X6 (3)
57 HX-0029400-00 FIXED BASE ｺﾃｲ ﾍﾞｰｽ (2)
58 HX-0034400-00 FIXED BASE ｿｸｾﾝﾊﾟｰﾂ (2)
59 SM-4040601-SC SCREW M4X0.7 L=6 ﾅﾍﾞｺﾈｼﾞ M4X0.7 L=6 (4)
60 PJ-3010605-03 HALF UNION ﾊｰﾌ ﾕﾆｵﾝ (1)
61 PH-0300062-C0 PARALLEL PIN TYPE B 3X6 平行ﾋﾟﾝ B 種 3X6 (4)
62 SM-6041402-TN SCREW M4X0.7 L=14 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=14 (2)
63 SM-6030502-TN SCREW M3 L=5 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M3 L=5 (4)
64 ST-4020521-SN TAPPING SCREW D=2 L=5 ﾀｯﾋﾟﾝねじ D=2 L=5 (8)
65 SL-4030881-SC SCREW M3 L=8 座金付きなべ小ねじ M3 L=8 (12)
66 401-43365 ETF_POSITION_LABEL ETF_ﾎﾟｼﾞｼｮﾝ_ﾗﾍﾞﾙ (2)
67 BT-0600401-EB URETHANE TUBE BLACK 6X4 ﾎﾟﾘｳﾚﾀﾝ ﾁｭｰﾌﾞ 黒 6X4 (0.4)
68 SL-4040891-SC SCREW M4X8 ｻﾞｶﾞﾈﾂｷﾅﾍﾞｺﾈｼﾞ M4 L=8 (4)
69 401-46480 TROLLEY CONTACT(T)B PCB ASM ﾄﾛﾘｰ CONTACT(T)B 基板組 (1)
70 EZ4-000-207-02 PIN (2) LOCATE ﾛｹ-ﾄ ﾋﾟﾝ (2) (2)
71 EZ4-453-564-01 PLUG TAPER SCREW ﾃ-ﾊﾟ ｽｸﾘﾕ- ﾌﾟﾗｸﾞ (1)
72 EZ4-455-727-01 TABLE PLUG ﾃ-ﾌﾞﾙ ﾌﾟﾗｸﾞ (1)
73 EZ4-463-630-01 TABLE SPACER (R B) ﾃ-ﾌﾞﾙ ｽﾍﾟ-ｻ- R B (1)
74 EZ4-705-470-11 RING O (CO 0006A P9) O ﾘﾝｸﾞ (CO 0006A P9) (2)
75 EZ4-477-023-01 CONNECTOR BRACKET L ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ L (MOLD) (1)
76 EZ4-478-177-01 CLAMP CONNECTOR HARNESS ｺﾈｸﾀ- ﾊ-ﾈｽ ｸﾗﾝﾊﾟｰ (MOLD) (2)
77 EZ4-477-022-01 CONNECTOR BRACKET R ｺﾈｸﾀｰ ﾌﾞﾗｹｯﾄ R (MOLD) (1)
78 401-43635 TABLE_BASE_L_ASSY ﾃｰﾌﾞﾙﾍﾞｰｽ L ｱｯｼｰ 1
79 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (2)
80 401-43525 SLIDE_BLOCK_L ｽﾗｲﾄﾞﾌﾞﾛｯｸ L (1)
81 SM-6051602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (4)
82 SM-6051002-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (2)
83 401-43527 SP_SHAFT ｽﾌﾟﾘﾝｸﾞｼｬﾌﾄ (1)
84 SL-6041292-TN SCREW M4 L=12 座金付き六角穴ﾎﾞﾙﾄ M4 L=12 (1)
85 401-43524 TABLE_BASE_L ﾃｰﾌﾞﾙﾍﾞｰｽ L (1)
86 401-43529 CUTTER_RAIL ｶｯﾀｰﾚｰﾙ (1)
87 EZ4-113-107-01 FOLLOWER (CF8VB) CAM ｶﾑ ﾌｵﾛｱ (CF8VB) (2)
88 EZ4-453-803-01 CUSHION CUTTER UNIT ｶﾂﾀ- ﾕﾆﾂﾄ ｸﾂｼﾖﾝ (1)
89 401-43636 TABLE_BASE_R_ASSY ﾃｰﾌﾞﾙﾍﾞｰｽ R ｱｯｼｰ 1
90 401-43529 CUTTER_RAIL ｶｯﾀｰﾚｰﾙ (1)
91 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (2)
92 401-43530 SLIDE_BLOCK_R_ ｽﾗｲﾄﾞﾌﾞﾛｯｸ R (1)
93 SM-6051602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (4)
94 SM-6051002-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (2)
95 401-43532 ACT_BRACKET ACT ﾌﾞﾗｹｯﾄ (1)
96 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (5)
97 401-43527 SP_SHAFT ｽﾌﾟﾘﾝｸﾞｼｬﾌﾄ (1)
98 SL-6041292-TN SCREW M4 L=12 座金付き六角穴ﾎﾞﾙﾄ M4 L=12 (1)
99 HX-0015000-00 CABLE CLAMP ｹｰﾌﾞﾙｸﾘｯﾌﾟ (1)
100 WT-0430002-KN WASHER M4 ﾊﾂｷｻﾞｶﾞﾈ M4 (1)
101 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (2)
102 401-43528 TABLE_BASE_R ﾃｰﾌﾞﾙﾍﾞｰｽ R (1)
103 EZ4-149-845-01 ACTUATOR (D40A-A1) SWITCH ﾄﾞｱ ｽｲﾂﾁ ｱｸﾁﾕｴ-ﾀ (D40A-A1) (1)
104 EZ4-113-107-01 FOLLOWER (CF8VB) CAM ｶﾑ ﾌｵﾛｱ (CF8VB) (2)
105 EZ4-453-803-01 CUSHION CUTTER UNIT ｶﾂﾀ- ﾕﾆﾂﾄ ｸﾂｼﾖﾝ (1)
106 SM-6051602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ 3
107 SM-6051602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ 3
108 401-43638 SHOOT_ASSY ｼｭｰﾄｱｯｼｰ 1
