A-17 A5-2 【 RX-7R 】架台 ASSY-2 【 RX-7R 】 Base frame assy - 2 ｲﾗｽﾄ番号 Ref.No. 品番 Part Number Description 品名 個数 Q'ty 備考 Remarks 51 EZ4-478-175-01 CONNECTOR BRACKET UPPER L ｺﾈｸﾀｰ ﾌﾞﾗｹｯﾄｱｯﾊﾟｰ L (MOLD) 2 52 EZ4-455-639-01 C…
A-16
A5-2
【RX-7R】架台 ASSY-2
【RX-7R】Base frame assy - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ4-453-569-01 PLUG (CYP025-08B29449) ﾌﾟﾗｸﾞ (CYP025-08B29449) 4
2 EZ4-453-569-01 PLUG (CYP025-08B29449) ﾌﾟﾗｸﾞ (CYP025-08B29449) 3
3 EZ4-454-743-01 CONTROLLER (AS2201F-01-06SA) ｽﾋﾟ-ﾄﾞ ｺﾝﾄﾛ-ﾗ (AS2201F-01-06SA) 4
4 EZ7-623-208-22 SW 3 TYPE 2 SW 3 TYPE 2 12
5 EZ7-683-457-04 BOLT HEXAGON SOCKET 6X20 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 6X20 12
6 EZ7-683-465-04 BOLT HEXAGON SOCKET 6X40
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 6X40
8
7 PC-0126010-00 SPEED CONTROLLER ｽﾋﾟｰﾄﾞ ｺﾝﾄﾛｰﾗ 4
8 PJ-3040651-01 ELBOW UNION 6XPT1/8 ｴﾙﾎﾞ ﾕﾆｵﾝ 6XPT1/8 4
9 EZ4-138-825-02 PLUG (M10X1.5) SCREW ｽｸﾘﾕ- ﾌﾟﾗｸﾞ (M10X1.5) 4
10 EZ4-453-818-01 BOLT (CBSTSR3-5) ﾁﾖｳ ｺﾞｸ ﾃｲﾄｳ ﾎﾞﾙﾄ (CBSTSR3-5) 12
11 EZ4-454-729-01 CYLINDER(CXSM32-100) DUAL ROD ﾃﾞﾕｱﾙ ﾛﾂﾄﾞ ｼﾘﾝﾀﾞ (CXSM32-100) 4
12 EZ4-454-745-02 LM GUIDE (SHS15V1UU)
LM ｶﾞｲﾄﾞ (SHS15V1UU)
8
13 EZ4-454-941-02 RAIL GUIDE 1 (L) ﾚ-ﾙ ｶﾞｲﾄﾞ 1 (L) 2
14 EZ4-454-941-12 RAIL GUIDE 1 (R) ﾚ-ﾙ ｶﾞｲﾄﾞ 1 (R) 2
15 EZ4-454-942-02 RAIL GUIDE 2 (L) ﾚ-ﾙ ｶﾞｲﾄﾞ 2 (L) 4
16 EZ4-454-942-12 RAIL GUIDE 2 (R) ﾚ-ﾙ ｶﾞｲﾄﾞ 2 (R) 4
17 EZ4-454-943-02 BLOCK TABLE POSITIONING ﾃ-ﾌﾞﾙ ｲﾁｷﾞﾒ ﾌﾞﾛﾂｸ 4
18 EZ4-454-944-02 SIDE PLATE (R)
ｻｲﾄﾞ ﾌﾟﾚ-ﾄ (R)
1
19 EZ4-454-944-12 SIDE PLATE (L) ｻｲﾄﾞ ﾌﾟﾚ-ﾄ (L) 1
20 EZ4-454-945-01 CYLINDER PLATE ｼﾘﾝﾀﾞ- ﾌﾟﾚ-ﾄ 4
21 EZ4-458-991-01 COLLAR (8-6-3) Y AXIS ｶﾗ- (8-6-3) Y ｼﾞｸ 4
22 EZ4-488-222-01 SLIDER LIFT ﾘﾌﾄ ｽﾗｲﾀﾞ- 4
23 EZ4-705-547-11 PIN PARALLEL (A4X10) ﾍｲｺｳ ﾋﾟﾝ (A4X10) 12
24 EZ7-683-408-04 BOLT HEXAGON SOCKET 3X16
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X16
8
25 EZ7-683-419-04 BOLT HEXAGON SOCKET 4X8 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X8 32
26 EZ7-683-420-04 BOLT HEXAGON SOCKET 4X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X10 12
27 EZ7-683-423-04 BOLT HEXAGON SOCKET 4X16 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 48
28 EZ7-683-452-04 BOLT HEXAGON SOCKET 6X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 6X10 4
29 EZ7-6834-720-4 BOLT HEXAGON SOCKET 8X16 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 8X16 4
30 HA-0037900-0A SWITCH
ﾏｲｸﾛ SW
2
31 EZ4-457-358-01 VALVE (MVP63-J) MECHANICAL ﾒｶﾆｶﾙ ﾊﾞﾙﾌﾞ (MVP63-J) 2
32 EZ4-461-727-01 BRACKET MECHANICAL VALVE ﾒｶﾆｶﾙ ﾊﾞﾙﾌﾞ ﾌﾞﾗｹﾂﾄ 2
33 PX-0551040-00 SILENCER ｻｲﾚﾝｻ 2
34 PJ-3040851-01 ELBOW UNION 8XPT1/8 ｴﾙﾎﾞ ﾕﾆｵﾝ 8XPT1/8 1
35 PJ-3050600-04 T ﾁｰｽﾞ 4
36 SM-6042502-TN SCREW M4X0.7 L=25
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=25
2
37 EZ4-447-186-11 WYE (KQ2U06-00A) UNION ﾕﾆｵﾝ ﾜｲ (KQ2U06-00A) 2
38 402-07757 VALVE_ASM ﾊﾞﾙﾌﾞ組 1
39 400-94346 CHECK_VALVE ﾁｪｯｸﾊﾞﾙﾌﾞ 2
40 SM-6060802-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ 12
41 EZ2-580-594-01 SCREW +PSW M3X12 ﾈｼﾞ +PSW M3X12 8
42 EZ2-580-600-01 SCREW +PSW M4X8
ﾈｼﾞ +PSW M4X8
8
43 EZ3-719-601-61 SCREW (B2X5) TAPPING 0 ﾊﾞﾝ P3 ｼﾕ ﾀﾂﾋﾟﾝ B2X5 16
44 EZ4-113-099-01 CUSHION (1) URETHANE ｳﾚﾀﾝ ｸﾂｼﾖﾝ (1) 4
45 EZ4-447-109-11 UNION (KQ2L06-M5A) ELBOW ｴﾙﾎﾞ ﾕﾆｵﾝ (KQ2L06-M5A) 2
46 EZ4-452-347-01 LABEL (PLAIN) SERIAL NO.(1446) ｼﾘｱﾙ NO. ﾗﾍﾞﾙ (ﾑｼﾞ) (1446) 1
47 EZ4-453-566-01 COLLAR ｶﾗ- 4
48 EZ4-455-493-01 DIAMOND PIN
ﾀﾞｲﾔ ﾋﾟﾝ
1
49 EZ4-455-626-04 POSITIONING BUSH (MASTR) ｲﾁｷﾞﾒ ﾌﾞﾂｼﾕ (ｷｼﾞﾕﾝ) 2
50 EZ4-455-627-01 POSITIONING BUSH (SLAVE) ｲﾁｷﾞﾒ ﾌﾞﾂｼﾕ (ｼﾞﾕｳｿﾞｸ) 2
A-17
A5-2
【RX-7R】架台 ASSY-2
【RX-7R】Base frame assy - 2
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
51 EZ4-478-175-01 CONNECTOR BRACKET UPPER L ｺﾈｸﾀｰ ﾌﾞﾗｹｯﾄｱｯﾊﾟｰ L (MOLD) 2
52 EZ4-455-639-01 CONNECTOR BRACKET BOTTOM ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ ﾎﾞﾄﾑ 2
53 EZ4-455-640-01 CONNECTOR BRACKET SPACER ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ ｽﾍﾟ-ｻ 2
54 EZ4-478-176-01 CONNECTOR BRACKET UPPER R ｺﾈｸﾀｰ ﾌﾞﾗｹｯﾄｱｯﾊﾟｰ R (MOLD) 2
55 EZ4-463-738-01 CONNECTOR BRACKET R BOTTOM ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ R ﾎﾞﾄﾑ 2
56 EZ4-463-739-01 CONNECTOR BRACKET R SPACER ｺﾈｸﾀ- ﾌﾞﾗｹﾂﾄ R ｽﾍﾟ-ｻ 2
57 EZ4-472-320-01 CONNECTOR COVER ｺﾈｸﾀ- ｶﾊﾞ- 2
58 EZ4-531-184-01 PROTECTION CUSHION (L) ﾎｺﾞ ｸﾂｼﾖﾝ (L) 2
59 EZ4-531-184-11 PROTECTION CUSHION (R) ﾎｺﾞ ｸﾂｼﾖﾝ (R) 2
60 EZ4-705-597-41 PIN (DIA. 5) PARALLEL ﾍｲｺｳ ﾋﾟﾝ (ﾌｱｲ 5) 8
61 EZ4-716-434-21 TIE INSULOCK (AB150 BLACK) ｲﾝｼﾕﾛﾂｸ ﾀｲ (AB150 ｸﾛ) 37
62 EZ4-716-434-31 TIE INSULOCK (AB200 BLACK) ｲﾝｼﾕﾛﾂｸ ﾀｲ (AB200 ｸﾛ) 13
63 EZ4-720-203-01 PIN TOOL POSITIONING ｼﾞｸﾞ ﾖｳ ｲﾁｷﾞﾒ ﾋﾟﾝ (JPDPA10-14) 1
64 EZ4-722-956-01 LABEL(SILVER) BLANK ﾌﾞﾗﾝｸ ﾗﾍﾞﾙ ｷﾞﾝ(TTC82YS-10) 4
65 EZ7-682-265-04 SCREW +K 4X16 ﾈｼﾞ +K 4X16 8
66 EZ7-683-403-04 BOLT HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 8
67 EZ7-683-420-04 BOLT HEXAGON SOCKET 4X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X10 20
68 EZ7-683-421-04 BOLT HEXAGON SOCKET 4X12 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ(C4X12) 16
69 EZ7-683-422-04 BOLT HEXAGON SOCKET 4X14 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X14 4
70 EZ7-683-425-04 BOLT HEXAGON SOCKET 4X20 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X20 4
71 EZ7-683-435-04 BOLT HEXAGON SOCKET 5X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 5X10 16
72 EZ7-684-024-04 N 4 TYPE 2 N 4 TYPE 2 24
73 EZ7-688-004-11 W 4 MIDDLE W 4 MIDDLE 32
74 EZ7-688-005-11 W 5 MIDDLE W 5 MIDDLE 12
75 401-46468 TROLLEY CONTACT(M)A PCB ASM ﾄﾛﾘｰ CONTACT(M)A 基板組 1
76 401-72762 TROLLEY CONTACT(M)A ORI PCB ASM ﾄﾛﾘｰ CONTACT(M)A ORI 基板組 1
77 401-46472 TROLLEY CONTACT(M)B PCB ASM ﾄﾛﾘｰ CONTACT(M)B 基板組 2
78 402-09890 PARTITION_PLATE 仕切り板 2
79 402-11539 TROLLEY_SW_BR_ASM 台車上昇ｽｲｯﾁﾌﾞﾗｹｯﾄ組 2
80 SM-6041602-TN SCREW M4X16 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X16 (2)
81 402-08045 SENSOR_SHAFT_F ｾﾝｻｰｼｬﾌﾄ F (1)
82 RE-0400000-K0 E-RING 4 E 形止め輪 4 (1)
83 402-08376 SHAFT_HOLDER ｼｬﾌﾄﾎﾙﾀﾞｰ (1)
84 402-08064 SENSOR_BRACKET_F ｾﾝｻｰﾌﾞﾗｹｯﾄ F (1)
85 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 (2)
86 SM-6040602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (1)
