B-17
B5
【RX-7R】SYSTEM DIAGRAM (5)
【RX-7R】SYSTEM DIAGRAM (5)
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
51 402-00585 RESET SW CABLE ASM ﾘｾｯﾄｽｲｯﾁｹｰﾌﾞﾙｸﾐ 1
52 401-96361 IO1 CABLE ASM IO1 ｹｰﾌﾞﾙｸﾐ 1
53 EZ1-969-383-12 HARNESS (BOX IO2-AIRSUP MNT) ﾊ-ﾈｽ (BOX IO2-AIRSUP MNT) 1
54 401-96336 MAIN SW-TB1 WIRE ASM ﾒｲﾝ SW-TB1 ﾜｲﾔｰｸﾐ 1
55 402-00606 ACIN-TB1 CABLE ASM ACIN-TB1 ｹｰﾌﾞﾙｸﾐ 1
56 EZ1-969-092-12 HARNESS (CP3-VAC)
ﾊ-ﾈｽ (CP3-VAC)
1
57 EZ1-523-273-11 BREAKER CIRCUIT ｻ-ｷﾂﾄ ﾌﾞﾚ-ｶ (CP33V/2W) 1
58 HA-0061900-00 MAGNETIC CONTACTOR 電磁開閉器 1
59 402-03285 SDIO CN2703-MC CR CABLE ASM SDIO CN2703-MC CR ｹｰﾌﾞﾙｸﾐ 1
60 EZ1-969-081-13 HARNESS (MR1-CP3) ﾊ-ﾈｽ (MR1-CP3) 1
61 401-96262 JOINT FAN CABLE ASM ｼﾞｮｲﾝﾄ ﾌｧﾝ ｹｰﾌﾞﾙｸﾐ 1
62 EZ1-969-071-13 HARNESS (CP2-TB3)
ﾊ-ﾈｽ (CP2-TB3)
1
63 401-99881 CIRCUIT PROTECTOR ｻｰｷｯﾄﾌﾟﾛﾃｸﾀ 1
64 402-09944 RF POWER CABLE 4 ASM RF ﾊﾟﾜｰ ｹｰﾌﾞﾙ 4 ｸﾐ 1
65 EZ1-969-102-11 HARNESS (ATX-TP POW) ﾊ-ﾈｽ (ATX-TP POW) 1
66 402-03287 SDIO CN2704-MC CR CABLE ASM SDIO CN2704-MC CR ｹｰﾌﾞﾙｸﾐ 1
67 402-03285 SDIO CN2703-MC CR CABLE ASM SDIO CN2703-MC CR ｹｰﾌﾞﾙｸﾐ 1
68 EZ1-837-828-11 CABLE PC UNIT MC3 SERIAL
PC ﾕﾆﾂﾄ MC3 ｼﾘｱﾙ ｹｰﾌﾞﾙ
1
69 EZ6-720-331-01 IC CM8062301044204S-R05Y IC CM8062301044204S-R05Y 1
70 EZ1-855-270-11 CPU COOLER CPU ｸ-ﾗ- (RR-V211-15FK-R2) 1
71 EZ1-458-642-11 MEMORY 4GB ﾒﾓﾘ 4GB (TS512MLK64V3N) 1
72 402-03362 USB-J22 CABLE ASM USB-J22 ｹｰﾌﾞﾙｸﾐ 1
73 401-91456 MOTHER BOARD(RUBY-PB6511) ﾏｻﾞｰﾎﾞｰﾄﾞ (RUBY-PB6511) 1
74 402-03289 SDIO CN2904-HIO CABLE ASM
SDIO CN2904-HIO ｹｰﾌﾞﾙｸﾐ
1
75 EZ1-755-544-11 RELAY (RU2S-D-D24) ﾘﾚ- (RU2S-D-D24) 1
76 EZ1-755-545-11 SOCKET RELAY (SM2S-05B) ﾘﾚ- ｿｹﾂﾄ (SM2S-05B) 1
77 401-96366 CR7-TB6 CABLE ASM CR7-TB6 ｹｰﾌﾞﾙｸﾐ 1
78 401-96367 CR7-TB6 CABLE ASM2 CR7-TB6 ｹｰﾌﾞﾙｸﾐ 2 1
79 401-96362 CN2701-IO1 CABLE ASM CN2701-IO1 ｹｰﾌﾞﾙｸﾐ 1
80 EZ1-969-110-15 HARNESS (SDIO CN2901-PC CN1)
ﾊ-ﾈｽ (SDIO CN2901-PC CN1)
1
81 401-57971 CN2705 SIGNAL CABLE ASM CN2705 ｼｸﾞﾅﾙ ｹｰﾌﾞﾙｸﾐ 1
82 EZA-191-677-9A SDIO CONT COMPL SDIO CONT COMPL 1
83 401-46460 SDIO CONT PCB ASM SDIO CONT 基板組 1
84 401-57969 BOX CN1A SIGNAL CABLE ASM ﾎﾞｯｸｽ CN1A ｼｸﾞﾅﾙ ｹｰﾌﾞﾙｸﾐ 1
85 401-96368 CR7-SFR CABLE ASM CR7-SFR ｹｰﾌﾞﾙｸﾐ 1
86 HB-0015800-00 RELAY
ﾘﾚｰ
1
87 401-96358 CN2700-SFR CABLE ASM CN2700-SFR ｹｰﾌﾞﾙｸﾐ 1
88 401-96365 TB6-SFR CABLE ASM TB6-SFR ｹｰﾌﾞﾙｸﾐ 1
89 401-96357 ELE BOX-BOX CN1B_C CABLE ASM ELE BOX-BOX CN1B_C ｹｰﾌﾞﾙｸﾐ 1
90 401-57969 BOX CN1A SIGNAL CABLE ASM ﾎﾞｯｸｽ CN1A ｼｸﾞﾅﾙ ｹｰﾌﾞﾙｸﾐ 1
91 EZ1-969-080-13 HARNESS (TB2-MR1) ﾊ-ﾈｽ (TB2-MR1) 1
92 402-10304 CP1-TB7 CABLE ASM
CP1-TB7 ｹｰﾌﾞﾙｸﾐ
1
93 EZ1-576-339-11 BREAKER CIRCUIT (CP32V/3) ｻ-ｷﾂﾄ ﾌﾞﾚ-ｶ (CP32V/3) 1
94 EZ1-969-069-12 HARNESS (CP1-ATX) ﾊ-ﾈｽ (CP1-ATX) 1
95 401-96337 TB7-MC2 WIRE ASM TB7-MC2 ﾜｲﾔｰｸﾐ 1
96 EZ1-969-064-13 HARNESS (TB2-CP4) ﾊ-ﾈｽ (TB2-CP4) 1
97 402-10694 TB2-PS3 CABLE ASM TB2-PS3 ｹｰﾌﾞﾙｸﾐ 1
98 HA-0068700-00 MAGNETIC CONTACTOR
電磁開閉器
1
99 EZ1-969-074-11 HARNESS (MC2-MC3) ﾊ-ﾈｽ (MC2-MC3) 1
100 402-03277 MC3-PS2 CP5 CABLE ASM MC3-PS2 CP5 ｹｰﾌﾞﾙｸﾐ 1
B-18
B5
【RX-7R】SYSTEM DIAGRAM (5)
【RX-7R】SYSTEM DIAGRAM (5)
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
101 EZ1-523-275-11 BREAKER CIRCUIT ｻ-ｷﾂﾄ ﾌﾞﾚ-ｶ (CP33V/20WDN) 1
102 EZ1-969-078-13 HARNESS (CP5-SV1 SV2) ﾊ-ﾈｽ (CP5-SV1 SV2) 1
103 EZ1-523-270-11 BREAKER CIRCUIT ｻ-ｷﾂﾄ ﾌﾞﾚ-ｶ (CP32V/2WDN) 1
104 EZ1-969-079-13 HARNESS (CP4-SV1 SV2) ﾊ-ﾈｽ (CP4-SV1 SV2) 1
105 EZ1-474-521-11 REGULATOR SWITCHING(HWS600P#) ｽｲﾂﾁﾝｸﾞ ﾚｷﾞﾕﾚ-ﾀ (HWS600P#) 1
106 402-10693 PS3-CP2 WIRE ASM
PS3-CP2 ﾜｲﾔｰｸﾐ
1
107 EZ1-523-272-11 BREAKER CIRCUIT ｻ-ｷﾂﾄ ﾌﾞﾚ-ｶ (CP32V/15WDC) 1
108 402-03281 PS2-CP9 CABLE ASM PS2-CP9 ｹｰﾌﾞﾙｸﾐ 1
109 401-99882 CIRCUIT PROTECTOR ｻｰｷｯﾄﾌﾟﾛﾃｸﾀ 1
110 401-57967 SV3 SV4 POWER CABLE ASM SV3 SV4 ﾊﾟﾜｰ ｹｰﾌﾞﾙｸﾐ 1
111 EZ1-474-020-11 POWER ATX (ENSP3-450P-S20-H1V)
ATX ﾃﾞﾝｹﾞﾝ (ENSP3-450P-S20-H1V)
1
112 EZ1-756-676-11 BATTERY (BS10A-H24/2.0L)
ﾊﾞﾂﾃﾘ (BS10A-H24/2.0L)
1
113 EZ1-838-010-11 CABLE ATX POWER (WH-PS610-850)
ATX ﾃﾞﾝｹﾞﾝ ｹ-ﾌﾞﾙ (WH-PS610-850)
1
114 EZ1-833-193-11 CABLE ATX POWER (WH-V0408-500)
ATX ﾃﾞﾝｹﾞﾝ ｹ-ﾌﾞﾙ (WH-V0408-500)
1
115 EZ1-838-009-11 CABLE ATX POWER (WH-M2424-500)
ATX ﾃﾞﾝｹﾞﾝ ｹ-ﾌﾞﾙ (WH-M2424-500)
1
116 HX-0069200-00 POWER SUPPLY ﾊﾟﾜｰｻﾌﾟﾗｲ 1
117 402-10691 PS3-CP6/7/8/CR2 CABLE ASM PS3-CP6/7/8/CR2 ｹｰﾌﾞﾙｸﾐ 1
118 EZ1-523-303-11 BREAKER CIRCUIT (CP32V/10WDC)
BREAKER CIRCUIT (CP32V/10WDC)
1
119 402-03280 CP7/8-TB5/6 CABLE ASM CP7/8-TB5/6 ｹｰﾌﾞﾙｸﾐ 1
120 EZ1-523-272-11 BREAKER CIRCUIT ｻ-ｷﾂﾄ ﾌﾞﾚ-ｶ (CP32V/15WDC) 1
121 402-10692 PS3-CP6/CR3 CABLE ASM PS3-CP6/CR3 ｹｰﾌﾞﾙｸﾐ 1
122 EZ1-755-538-11 RELAY (RU4S-D-D24) ﾘﾚ- (RU4S-D-D24) 1
123 EZ1-755-539-11 SOCKET RELAY (SY4S-05B) ﾘﾚ- ｿｹﾂﾄ (SY4S-05B) 1
124 EZ1-969-799-11 HARNESS (COG-CR1)
ﾊ-ﾈｽ (COG-CR1)
1
125 402-03282 TB6-CR4 CABLE ASM TB6-CR4 ｹｰﾌﾞﾙｸﾐ 1
126 HB-0012800-0C RELAY ﾘﾚｰ 1
127 HB-0005800-10 RELAY ﾘﾚｰ ﾄﾒｶﾅｸﾞ 1
128 401-57968 SV3 SV4 SIGNAL CABLE ASM SV3 SV4 ｼｸﾞﾅﾙ ｹｰﾌﾞﾙｸﾐ 1
129 EZ1-832-158-11 CABLE RS232C (PS2601-02) RS232C ｹ-ﾌﾞﾙ (PS2601-02) 1
130 401-58259 SATA CABLE
SATA ｹｰﾌﾞﾙ
1
131 401-96521 DISK ASSY (P) ﾃﾞｨｽｸ ASSY (P) 1
132 EZ1-857-162-13 BOARD ASSY CAN IO (CART) CAN IO ﾎﾞｰﾄﾞ ASSY (CART) 1
133 401-58284 MOTION CONTROLER ﾓｰｼｮﾝｺﾝﾄﾛｰﾗｰ 1
134 EZ1-895-351-11 FRAME GRABBER ﾌﾚ-ﾑ ｸﾞﾗﾊﾞ- (ASP-8514X-SMD4) 1
135 EZA-192-221-6A (M) MC3 COMPL (M) MC3 COMPL 1
136 EZ1-969-111-11 HARNESS (MC3B-MCAN)
ﾊ-ﾈｽ (MC3B-MCAN)
1
137 EZ1-969-112-11 HARNESS (MCAN-CAN1 2) ﾊ-ﾈｽ (MCAN-CAN1 2) 1
138 EZ1-969-748-11 HARNESS ﾊ-ﾈｽ 1
139 402-11964 PC CN1-MB MC3B CAN CABLE ASM PC CN1-MB MC3B CAN ｹｰﾌﾞﾙｸﾐ 1
140 402-03288 SDIO CN2903-HIO CABLE ASM SDIO CN2903-HIO ｹｰﾌﾞﾙｸﾐ 1
141 EZ1-969-114-11 HARNESS (CAN-ADDA) ﾊ-ﾈｽ (CAN-ADDA) 1
142 EZ1-969-776-11 HARNESS (SDIO POW-TB6 CR1)
ﾊ-ﾈｽ (SDIO POW-TB6 CR1)
1
143 402-03276 CR3 14-24 CABLE ASM CR3 14-24 ｹｰﾌﾞﾙｸﾐ 1
144 EZ1-969-103-11 HARNESS (CAN1 2-CONV) ﾊ-ﾈｽ (CAN1 2-CONV) 1
145 HB-0012800-0C RELAY ﾘﾚｰ 1
146 HB-0005800-10 RELAY ﾘﾚｰ ﾄﾒｶﾅｸﾞ 1
147 402-03275 CR2 14-24 CABLE ASM CR2 14-24 ｹｰﾌﾞﾙｸﾐ 1
148 EZ1-969-086-12 HARNESS (SDIO CN2803-YX CN3)
ﾊ-ﾈｽ (SDIO CN2803-YX CN3)
1
149 401-18620 OPTICAL FIBER CABLE 1M ﾋｶﾘﾌｧｲﾊﾞｹｰﾌﾞﾙ 1M 1
150 400-44541 OPTICAL FIBER CABLE 0.15M ﾋｶﾘﾌｧｲﾊﾞｹｰﾌﾞﾙ 0.15M 1
B-19
B5
【RX-7R】SYSTEM DIAGRAM (5)
【RX-7R】SYSTEM DIAGRAM (5)
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
151 EZ1-969-077-12 HARNESS (TB2-SV1) ﾊ-ﾈｽ (TB2-SV1) 1
152 EZ1-969-077-22 HARNESS (TB2-SV2) ﾊ-ﾈｽ (TB2-SV2) 1
153 401-58294 SERVO AMPLIFIER ｻ-ﾎﾞ ｱﾝﾌﾟ 1
154 EZ1-492-145-11 AMPLIFIER SERVO (MR-J4W2-22B-MK019) ｻ-ﾎﾞ ｱﾝﾌﾟ (MR-J4W2-22B-MK019) 1
155 EZ1-492-147-11 AMPLIFIER SERVO ｻ-ﾎﾞ ｱﾝﾌﾟ (MR-MD202-S016) 1
156 402-07119 HEAD ETC-H1M H1E(R) CABLE ASM
ﾍｯﾄﾞ ETC-H1M H1E(R) ｹｰﾌﾞﾙｸﾐ
1
157 402-07118 HEAD ETC-H1M H1E(L) CABLE ASM ﾍｯﾄﾞ ETC-H1M H1E(L) ｹｰﾌﾞﾙｸﾐ 1
158 EZ1-969-098-13 HARNESS (CR2 3-TROLLY POW) ﾊ-ﾈｽ (CR2 3-TROLLY POW) 1
159 402-03297 TB5-BOX CN3 CABLE ASM TB5-BOX CN3 ｹｰﾌﾞﾙｸﾐ 1
160 402-03298 TB5-BOX CN4 CABLE ASM TB5-BOX CN4 ｹｰﾌﾞﾙｸﾐ 1
161 402-03299 TB5-BOX CN5 CABLE ASM TB5-BOX CN5 ｹｰﾌﾞﾙｸﾐ 1
162 EZA-198-100-1A CAN ADDA(H1000) COMPL
CAN ADDA(H1000) COMPL
1
163 401-46484 CAN ADDA PCB ASM CAN ADDA 基板組 1
164 EZ1-492-162-15 AMPLIFIER ASSY SENSOR ｾﾝｻ ｱﾝﾌﾟ ASSY (ZX2-LDA11) 1
165 EZ1-492-155-11 AMPLIFIER UNIT ｱﾝﾌﾟ ﾕﾆﾂﾄ (ZX2-LDA11) 1
