A-47 A15 【共通】ヘッド ASSY-6 【 COMMON 】 Head assy - 6
A-46
A14
【共通】ヘッド ASSY-5
【COMMON】Head assy - 5
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ1-492-547-14 MOTOR ASSY (H) MOTOR ASSY (H) 1
2 401-78054 BEARING COLLAR ﾍﾞｱﾘﾝｸﾞｶﾗｰ 1
3 EZ2-148-082-01 FOLLOWER, MINIATURE CAM (CFS2.5) ﾐﾆﾁﾕｱ ｶﾑ ﾌｵﾛｱ (CFS2.5) 1
4 EZ3-657-877-01 PIN, PARALLEL ﾍｲｺｳ ﾋﾟﾝ (ﾅﾝｼﾂ) 2
5 EZ3-703-358-52 PIN PARALLEL (DIA. 2X6) ﾍｲｺｳﾋﾟﾝ (ﾌｱｲ 2X6) 2
6 EZ4-453-913-01 LEVER, HOLDER ﾚﾊﾞ- ﾎﾙﾀﾞ 1
7 EZ4-453-947-01 RETAINER (2), BEARING ﾍﾞｱﾘﾝｸﾞ ｵｻｴ (2) 1
8 EZ4-453-948-01 COLLAR, H AXIS H ｼﾞｸ ｶﾗ- 1
9 EZ4-453-955-01 BRACKET, MOTOR ﾓ-ﾀ ﾌﾞﾗｹﾂﾄ 1
10 EZ4-453-956-01 HOLDER (1), BEARING ﾍﾞｱﾘﾝｸﾞ ﾎﾙﾀﾞ (H 1) 1
11 EZ4-453-957-01 HOLDER (H 2), BEARING ﾍﾞｱﾘﾝｸﾞ ﾎﾙﾀﾞ (H 2) 1
12 EZ4-453-958-01 PLATE (1), SUPPORT ｻﾎﾟ-ﾄ ﾌﾟﾚ-ﾄ (1) 1
13 EZ4-453-959-01 PLATE (2), SUPPORT ｻﾎﾟ-ﾄ ﾌﾟﾚ-ﾄ (2) 1
14 EZ4-453-961-01 SHAFT, LINEAR ﾘﾆｱ ｼﾔﾌﾄ 1
15 EZ4-453-962-01 H AXIS NUT HOLDER H ｼﾞｸ ﾅﾂﾄ ﾎﾙﾀﾞ 1
16 EZ4-454-012-01 STOPPER (H), UPPER H ｼﾞｸ ｱﾂﾊﾟ- ｽﾄﾂﾊﾟ- 1
17 EZ4-454-013-01 STOPPER (H), UNDER H ｼﾞｸ ｱﾝﾀﾞ- ｽﾄﾂﾊﾟ- 1
18 EZ4-454-044-01 COUPLING (SFC-005SA2-5B-5B) ｶﾂﾌﾟﾘﾝｸﾞ (SFC-005SA2-5B-5B) 1
19 EZ4-454-047-01 BEARING (MR105) ﾍﾞｱﾘﾝｸﾞ (MR105) 2
20 EZ4-454-048-01 LINEAR BUSH ﾘﾆｱ ﾌﾞﾂｼﾕ (SM6G-LUU) 1
21 EZ4-454-050-01 LOCK NUT (LNM6X0.75) ﾛﾂｸ ﾅﾂﾄ (LNM6X0.75) 1
22 EZ4-454-051-01 BEARING (AC6-16DF) ｱﾝｷﾞﾕﾗ ﾍﾞｱﾘﾝｸﾞ (AC6-16DF) 1
23 EZ4-454-055-01 BALL SCREW (WHF0612S-3.4GT+) ﾎﾞ-ﾙ ﾈｼﾞ (WHF0612S-3.4GT+) 1
24 EZ4-454-725-01 RING (12) ｱﾅﾖｳ C ｶﾞﾀ ﾄﾒ ﾜ (12) 1
25 EZ4-718-766-01 SET-SCREW (M3X4 SUS), HEAD ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ (M3X4 SUS) 2
26 EZ7-683-000-10 BOLT, HEXAGON SOCKET 3X30 6 ｶｸｱﾅﾂｷ ﾎﾞﾙﾄ 3X30 1
27 EZ7-683-403-04 BOLT,HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 33
28 EZ7-683-404-04 BOLT,HEXAGON SOCKET 3X8 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X8 4
29 EZ7-683-481-04 BOLT, HEXAGON SOCKET 2.5X4 6 ｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ 2.5X4 3
A-47
A15
【共通】ヘッド ASSY-6
【COMMON】Head assy - 6
A-48
A15
【共通】ヘッド ASSY-6
【COMMON】Head assy - 6
ｲﾗｽﾄ番
号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ4-454-045-01
FINE U NUT ﾌｱｲﾝ U ﾅﾂﾄ (FU-00SUS)
1
2 EZ4-456-867-01
BOLT (SSH) HEXAGON SOCKET ﾛﾂｶｸ ｱﾅﾂｷ ｺﾞｸ ﾃｲﾄｳ ﾎﾞﾙﾄ (SSH) 5
3 EZ3-272-056-01
BALL (DIA. 1.2) STEEL ｽﾁ-ﾙ ﾎﾞ-ﾙ (ﾌｱｲ 1.2) 32
4 EZ3-279-059-02
SPRING (O RING -D#) O RING
ﾉｽﾞﾙ O ﾘﾝｸﾞ ﾊﾞﾈ (O ﾘﾝｸﾞ -D*)
16
5 401-82117
RESIN SCREW(M2X6) ｼﾞｭｼﾈｼﾞ(M2X6) 32
6 EZ3-703-358-52
PIN PARALLEL (DIA. 2X6) ﾍｲｺｳﾋﾟﾝ (ﾌｱｲ 2X6) 16
7 EZ3-854-267-01
FLANGELESS BALL BEARING
ﾎﾞ-ﾙﾍﾞｱﾘﾝｸﾞ(6800ZZ)
2
8 EZ4-453-914-01
NOZZLE DRIVE GEAR (TAPER) ﾉｽﾞﾙ ｸﾄﾞｳ ｷﾞｱ 1
9 EZ4-453-915-01
COLLAR INNER ｲﾝﾅ- ｶﾗ- 1
10 EZ4-453-916-01
MANIFOLD ROTARY
ﾛ-ﾀﾘ- ﾏﾆﾎ-ﾙﾄﾞ
1
11 EZ4-453-917-01
GEAR RT (MAIN) ｷﾞｱ-RT (ﾒｲﾝ) 1
12 EZ4-453-918-01
GEAR RT (SUB) ｷﾞｱ-RT (ｻﾌﾞ) 1
13 EZ4-453-919-01
GEAR RN (MAIN)
ｷﾞｱ-RN (ﾒｲﾝ)
1
14 EZ4-453-920-01
GEARM RN (SUB) ｷﾞｱ-RN (ｻﾌﾞ) 1
15 EZ4-453-923-01
SHAFT MAIN ﾒｲﾝ ｼﾔﾌﾄ 1
16 EZ4-453-924-01
RN IDLE GEAR SHAFT
RN ｱｲﾄﾞﾙ ｷﾞｱ ｼﾔﾌﾄ
1
17 EZ4-453-926-01
WASHER SPACER ｽﾍﾟ-ｻ 1
18 EZ4-453-927-01
WASHER U NUT U ﾅﾂﾄ ﾜﾂｼﾔ 1
19 401-76158
RETAINER(1)_SPRING
ﾊﾞﾈｳｹ(1)
16
20 401-76159
BUSHING_SPRING RETAINER ﾊﾞﾈｳｹﾌﾞｯｼｭ 16
21 EZ4-454-003-02
RETAINERM PIN ﾋﾟﾝ ｵｻｴ 16
22 EZ4-454-004-01
SPRING COMPRESSION(DIA2.4X6.2)
ｱﾂｼﾕｸ ｺｲﾙ ﾊﾞﾈ (ﾌｱｲ 2.4X6.2)
16
23 EZ4-454-005-01
PIECE (DIA1.2X1.6) ｾﾂﾄ ﾋﾟ-ｽ (ﾌｱｲ 1.2X1.6) 32
24 401-79294
PIN_DIA0.86 ﾋﾟﾝ(DIA0.8x6) 16
25 401-95260
JOINT COUPLING2
ｶｯﾌﾟﾘﾝｸﾞｼﾞｮｲﾝﾄ 2
16
26
EZ4-454-025-01
SOCKET UPPER GEAR (B) ｳｴ ﾊｸﾞﾙﾏ ｿｹﾂﾄ (B) 2 INDEX 2,10 (RX-7 用_P16）
EZ4-454-025-11
SOCKET UPPER GEAR (D) ｳｴ ﾊｸﾞﾙﾏ ｿｹﾂﾄ (D) 2 INDEX 4,12 (RX-7 用_P16）
EZ4-454-025-21
SOCKET UPPER GEAR (F)
ｳｴ ﾊｸﾞﾙﾏ ｿｹﾂﾄ (F)
2
INDEX 6,14 (RX-7 用_P16）
EZ4-454-025-31
SOCKET UPPER GEAR (H) ｳｴ ﾊｸﾞﾙﾏ ｿｹﾂﾄ (H) 2 INDEX 8,16 (RX-7 用_P16）
27
401-87755
NOZZLE GEAR (B) ﾉｽﾞﾙ ｷﾞｱ (B) 2 (RX-7R 用_P16S）
401-87757
NOZZLE GEAR (D)
ﾉｽﾞﾙ ｷﾞｱ (D)
2
(RX-7R 用_P16S）
401-87759
NOZZLE GEAR (F) ﾉｽﾞﾙ ｷﾞｱ (F) 2 (RX-7R 用_P16S）
401-87761
NOZZLE GEAR (H) ﾉｽﾞﾙ ｷﾞｱ (H) 2 (RX-7R 用_P16S）
28 EZ4-454-032-01
SPACER GEAR
ｷﾞｱﾖｳ ｽﾍﾟ-ｻ-
7
29 EZ4-454-033-01
NZ GEAR SPACER ﾉｽﾞﾙ ｷﾞｱ ｽﾍﾟ-ｻ 8
30 EZ4-454-034-05
NUT BEARING ﾍﾞｱﾘﾝｸﾞ ﾅﾂﾄ 16
31 EZ4-454-042-01
NOZZLE GEAR
ﾉｽﾞﾙ ｷﾞｱ
16
(RX-7 用_P16）
32
401-87753
NOZZLE GEAR (3) ﾉｽﾞﾙ ｷﾞｱ (3) 16 (RX-7R 用_P16S）
402-01303
TORSION SPRING (A) ﾈｼﾞﾘﾊﾞﾈ (A) 16 (RX-7R 用_P16S）
402-01304
SNAP RING
ｽﾅｯﾌﾟﾘﾝｸﾞ
16
(RX-7R 用_P16S）
33 EZ4-454-045-01
FINE U NUT ﾌｱｲﾝ U ﾅﾂﾄ (FU-00SUS) 2
34 EZ4-454-049-02
NZ SHAFT (LTS4CSS+91.5LPF) ﾉｽﾞﾙ ｼﾔﾌﾄ (LTS4CSS+91.5LPF) 16
35 EZ4-454-056-01
O RING (S10)
O ﾘﾝｸﾞ (S10)
2
36 EZ4-454-057-01
O RING (SS-080) O ﾘﾝｸﾞ (SS-080) 2
37 EZ4-454-075-01
MINIATURE Y PACKING MYA-15 ﾐﾆ Y ﾊﾟﾂｷﾝ (MYA-15) 2
38 EZ4-454-081-01
SHAFT S064B
ｼﾔﾌﾄ S062B
32
(RX-7 用_P16）
39 EZ4-454-082-01
BOLT (SNZS-M1.4X3) ｾｲﾐﾂｷｷﾖｳ ﾅﾍﾞｺﾈｼﾞ (SNZS-M1.4X3) 16
40 EZ4-454-746-02
HOLDER (2) SPRING ﾊﾞﾈ ｳｹ (2) 16
41 EZ4-454-752-01
MECHANICAL VALVE
ﾒｶﾆｶﾙ ﾊﾞﾙﾌﾞ
16
42 EZ4-454-757-01
O RING (S8) O ﾘﾝｸﾞ (S8) 1
43 EZ4-454-758-02
NZ SHAFT SPRING ﾉｽﾞﾙ ｼﾔﾌﾄ ｽﾌﾟﾘﾝｸﾞ 16
44 EZ4-454-769-01 KEY PARALLEL (R03006) ﾍｲｺｳ ｷ- (R03006) 1
45 EZ4-454-770-01 KEY PARALLEL (R03008) ﾍｲｺｳ ｷ- (R03008) 1
