A-56 A18 【 RX-7 】 P8 ヘ ッ ド ASSY-3 【 RX-7 】 P8 Head assy - 3 1 8 52 50 53 51 57 55 58 54 56 59 60 39 44 29 30 43 35 41 47 40 40 46 46 33 38 20 19 47 31 32 48 48 45 22 21 37 27 37 27 34 28 42 36 36 26 25 49 46 61 65 64 62 …
A-56
A18
【RX-7】P8 ヘッド ASSY-3
【RX-7】P8 Head assy - 3
1
8
52
50
53
51
57
55
58
54
56
59
60
39
44
29
30
43
35
41
47
40
40
46
46
33
38
20
19
47
31
32
48
48
45
22
21
37
27
37
27
34
28
42
36
36
26
25
49
46
61
65
64
62
63
12
12
7
11
11
11
4
4
11
6
18
11
5
15
16
10
11
2
11
9
24
23
13
14
12
17
3
17
A
A
9
A-57
A18
【RX-7】P8 ヘッド ASSY-3
【RX-7】P8 Head assy - 3
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 401-55889 COUPLING_JOINT ｶｯﾌﾟﾘﾝｸﾞｼﾞｮｲﾝﾄ 1
2 401-56161 BRACKET_CONNECTOR ｺﾈｸﾀｰﾌﾞﾗｹｯﾄ 1
3 401-56171 PLATE(2)_REINFORCE ﾎｷｮｳﾌﾟﾚｰﾄ(2) 1
4 401-56326 MAIN SHAFT GUARD ﾒｲﾝｼｬﾌﾄｶﾞｰﾄﾞ 2
5 401-56403 BATTERY BOARD BLACKET ﾊﾞｯﾃﾘｷﾊﾞﾝﾌﾞﾗｹｯﾄ 1
6 401-56405 BATTERY BASE PLATE ﾊﾞｯﾃﾘｰﾍﾞｰｽﾌﾟﾚｰﾄ 1
7 401-56455
SMALL HEAD CAP SCREW(M3X10)_HEX SOCKET
ﾛｯｶｸｱﾅﾂｷｼｮｳｱﾀﾏﾎﾞﾙﾄ(M3X10) 4
8 401-56639
HEXAGON SOCKET SCREW(M1.6X2)_FLAT TYPE
ﾛｯｶｸｱﾅﾂｷﾄﾒﾈｼﾞ(M1.6x2)ﾋﾗｻｷ 2
9 401-60744 TAPE(40)_FIXED ｺﾃｲﾃｰﾌﾟ (40) 2
10 EZ7-683-402-04 BOLT HEXAGON SOCKET 3X5 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X5 2
11 EZ7-683-403-04 BOLT HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 12
12 EZ7-683-404-04 BOLT HEXAGON SOCKET 3X8 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X8 10
13 EZ1-492-202-12 BATTERY ASSY ﾊﾞﾂﾃﾘ- ASSY 1
14 EZ1-843-626-11 CONNECTOR (DL2-96R) ｺﾈｸﾀ (DL2-96R) 1
15 EZ1-895-367-12 BOARD BACKUP MONITORING ﾊﾞﾂｸｱﾂﾌﾟ ﾓﾆﾀ- ﾎﾞ-ﾄﾞ 1
16 EZ4-454-032-01 SPACER GEAR ｷﾞｱﾖｳ ｽﾍﾟ-ｻ- 2
17 EZ4-454-078-01 BOLT (SET-M3X6-NI) ﾃｲﾄｳﾎﾞﾙﾄ (SET-M3X6-NI) 6
18 EZ4-458-314-02 BATTERY CLIP ﾊﾞﾂﾃﾘ- ｸﾘﾂﾌﾟ 1
19 401-55896 BLOCK_CAMFOLLOWER ｶﾑﾌｫﾛｱｰﾌﾞﾛｯｸ 1
20 401-55897 SHAFT(1)_BEARING ﾍﾞｱﾘﾝｸﾞｼｬﾌﾄ(1) 1
21 401-55899 SHAFT(3)_BEARING ﾍﾞｱﾘﾝｸﾞｼｬﾌﾄ(3) 1
22 401-55900 LEVER_LINK ﾘﾝｸﾚﾊﾞｰ 1
23 401-55901 COLLAR(6)_BEARING ﾍﾞｱﾘﾝｸﾞｶﾗｰ(6) 1
24 401-55902 COLLAR(6)_BEARING ﾍﾞｱﾘﾝｸﾞｶﾗｰ(6) 1
25 401-55903 COLLAR(7)_BEARING ﾍﾞｱﾘﾝｸﾞｶﾗｰ(7) 1
26 401-55904 COLLAR(7)_BEARING ﾍﾞｱﾘﾝｸﾞｶﾗｰ(7) 1
27 401-55905 COLLAR(8)_BEARING ﾍﾞｱﾘﾝｸﾞｶﾗｰ(8) 2
28 401-55906 COLLAR(9)_BEARING ﾍﾞｱﾘﾝｸﾞｶﾗｰ(9) 1
29 401-56154 PLATE_MOTOR ﾓｰﾀｰﾌﾟﾚｰﾄ 1
30 401-56156 BRACKET(1)_SENSOR ｾﾝｻｰﾌﾞﾗｹｯﾄ(1) 1
31 401-56157 DOG(DOWN)_SENSOR ｼﾀｾﾝｻｰﾄﾞｸﾞ 1
32 401-56158 DOG(UP)_SENSOR ｳｴｾﾝｻｰﾄﾞｸﾞ 1
33 401-56160 BLOCK_MOTOR BASE ﾓｰﾀｰﾍﾞｰｽﾌﾞﾛｯｸ 1
34 401-56172 LG SHAFT(LG4S+57) LG ｼｬﾌﾄ(LG4S+57) 1
35 401-56173 SHAFT_DRIVE ｸﾄﾞｳｼﾞｸ 1
36 401-56416 BEARING(MR74-H-JMC3) ﾍﾞｱﾘﾝｸﾞ(MR74-H-HJMC3) 2
37 401-56418 BEARING(S672HWMC3) ﾍﾞｱﾘﾝｸﾞ(S672HWMC3) 2
38 401-56452 LINEAR GUIDE(MLC5C1R28H/D) ﾘﾆｱｶﾞｲﾄﾞ(MLC5C1R28H/D) 1
39 401-56536 MOTOR ASSY (VALVE) MOTOR ASSY (VALVE) 1
40 401-56538 SENSOR ASSY (VALVE) SENSOR ASSY (VALVE) 1
41 401-56626
LOW_SMALL HEAD CAP SCREW(M3X8)_HEAXGON S ﾛｯｶｸｱﾅﾂｷﾃｲﾄｳｼｮｳｱﾀﾏﾎﾞﾙﾄ(M3x8)
1
42 401-56637 NUT 2TYPE(M2SUS)_HEXAGON ﾛｯｶｸﾅｯﾄ 2TYPE(M2SUS) 1
43 EZ7-683-481-04 BOLT HEXAGON SOCKET 2.5X4 6 ｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ 2.5X4 2
44 EZ7-621-996-05 BOLT HEXAGON SOCKET 2.6X5 6 ｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ 2.6X5 4
45 EZ7-683-480-24 BOLT HEXAGON SOCKET 2X5 6 ｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ 2X5 2
46 EZ7-683-403-04 BOLT HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 4
47 EZ4-454-067-01 CAMFLLOWER (CFS3) ﾐﾆﾁﾕｱ ｶﾑﾌｵﾛｱ (CFS3) 2
48 EZ4-718-721-01 BOLT HEXAGON SOCKET(M2X3 SUS) ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ (M2X3 SUS) 4
49 NM-6040001-SC NUT M4X0.7 TYPE1 六角 ﾅｯﾄ M4X×0.7 1 種 1
50 401-56151 BASE(RN)_MOTOR ﾓｰﾀｰﾍﾞｰｽ RN 1
51 401-56446 COUPLING(XBS-15C2-5X5) ｶｯﾌﾟﾘﾝｸﾞ(XBS-15C2-5X5) 1
52 401-56520 MOTOR ASSY (RN) MOTOR ASSY (RN) 1
53 401-56611
LOW HEAD CAP SCREW(M3X8)_HEXAGON SOCKET
ﾛｯｶｸｱﾅﾂｷﾃｲﾄｳﾎﾞﾙﾄ(M3x8) 2
54 401-56140 COLLAR_SET ｾｯﾄｶﾗｰ 1
