A-62
A20-1
【RX-7】搬送部ユニット-幅調整 1
【RX-7】Conveyor unit - 1
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ4-454-259-02 BASE, CONVEYOR ｺﾝﾍﾞｱ ﾍﾞ-ｽ 1
2 EZ4-454-254-01 SUPPORT (L), FIXED ｺﾃｲ ｼﾁﾕｳ (L) 1
3 EZ4-454-255-01 BRACKET, FIXED SUPPORT ｺﾃｲ ｼﾁﾕｳ ﾌﾞﾗｹﾂﾄ 1
4 EZ4-454-254-11 SUPPORT (R), FIXED ｺﾃｲ ｼﾁﾕｳ (R) 1
5 EZ4-454-255-01 BRACKET, FIXED SUPPORT ｺﾃｲ ｼﾁﾕｳ ﾌﾞﾗｹﾂﾄ 1
6 EZ4-454-260-02 BRACKET, RAIL ﾚ-ﾙ ﾌﾞﾗｹﾂﾄ 1
7 EZ4-454-502-01 GUIDE (MHS15C3R640S2ET213) ｶﾞｲﾄﾞ (MHS15C3R640S2ET213) 3
8 EZ4-454-256-01 SUPPORT (LR), MOVABLE ｶﾄﾞｳ ｼﾁﾕｳ (LR) 1
9 EZ4-454-258-01 BRACKET, MOVABLE SUPPORT ｶﾄﾞｳ ｼﾁﾕｳ ﾌﾞﾗｹﾂﾄ 1
10 EZ4-454-257-01 SUPPORT (C), MOVABLE ｶﾄﾞｳ ｼﾁﾕｳ (C) 1
11 EZ4-454-258-01 BRACKET, MOVABLE SUPPORT ｶﾄﾞｳ ｼﾁﾕｳ ﾌﾞﾗｹﾂﾄ 1
12 EZ4-454-256-01 SUPPORT (LR), MOVABLE ｶﾄﾞｳ ｼﾁﾕｳ (LR) 1
13 EZ4-454-258-01 BRACKET, MOVABLE SUPPORT ｶﾄﾞｳ ｼﾁﾕｳ ﾌﾞﾗｹﾂﾄ 1
14 EZ4-454-257-01 SUPPORT (C), MOVABLE ｶﾄﾞｳ ｼﾁﾕｳ (C) 1
15 EZ4-454-258-01 BRACKET, MOVABLE SUPPORT ｶﾄﾞｳ ｼﾁﾕｳ ﾌﾞﾗｹﾂﾄ 1
16 EZ4-700-061-01 BEARING (6000ZZ) ﾍﾞｱﾘﾝｸﾞ (6000ZZ) 18
17 EZ4-453-827-01 SCREW (TMR14-RX739/TNBC) ﾀﾞｲｹｲﾈｼﾞ(TMR14-RX739/TNBC-AT*) 6
18 EZ4-761-803-11 NUT, FINE U (TREATMENT HAVE) ﾌｱｲﾝ U ﾅﾂﾄ (ｼﾖﾘ ｱﾘ) (FU00SS) 6
19 EZ4-453-831-01 BEARING (626ZZ1) ﾍﾞｱﾘﾝｸﾞ (626ZZ1) 12
20 EZ4-454-515-01 WASHER (FWSSA-D19-V16.0-T4.0) ｷﾝｿﾞｸﾜﾂｼﾔ(FWSSA-D19-V16.0-T4.0) 4
21 EZ4-455-705-01 COLLAR (D10-D6.2-L2.8) ｶﾗ- (D10-D6.2-L2.8) 4
22 EZ4-455-481-01 SPLIN (HTS7P-2+HTP7SX730) ﾛﾂｶｸ ｽﾌﾟﾗｲﾝ(HTS7P-2+HTP7SX730) 2
23 EZ4-455-480-01 SPLIN (HTS7P-2+HTP7SX717) ﾛﾂｶｸ ｽﾌﾟﾗｲﾝ(HTS7P-2+HTP7SX717) 2
24 EZ4-454-288-02 BRACKET, CABLE BARE ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ 1
25 EZ1-492-229-31 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾊﾞ ﾘﾐﾂﾄ RL4) 1
26 EZ4-454-292-01 DOG (3RR), SENSOR ｾﾝｻ- ﾄﾞｸﾞ (3RR) 1
27 EZ4-454-370-01 DOG (4RR), SENSOR ｾﾝｻ- ﾄﾞｸﾞ (4RR) 1
28 EZ4-454-365-02 PLATE L2-3 (LR), SENSOR ｾﾝｻ ﾌﾟﾚ-ﾄ L2-3 (LR) 4
29 EZ4-454-366-12 PLATE L4 (R), SENSOR ｾﾝｻ ﾌﾟﾚ-ﾄ L4 (R) 1
30 EZ4-454-368-02 BRACKET (2R), CABLE BARE ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ (2R) 1
31 EZ4-454-369-02 BRACKET (4RL), CABLE BARE ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ (4RL) 1
32 EZ4-454-366-02 PLATE L4 (L), SENSOR ｾﾝｻ ﾌﾟﾚ-ﾄ L4 (L) 1
33 EZ4-454-364-02 BRACKET (3R), CABLE BARE ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ (3R) 1
34 EZ4-454-290-01 DOG (2R), SENSOR ｾﾝｻ- ﾄﾞｸﾞ (2R) 1
35 EZ4-454-372-01 DOG (4R-A2), SENSOR ｾﾝｻ ﾄﾞｸﾞ (4R-A2) 1
36 EZ4-455-707-01 PLATE SENCER 4R-A2 ﾌﾟﾚ-ﾄ ｾﾝｻ (4R-A2) 1
37 EZ4-454-371-01 BRACKET (L), DUCT ﾀﾞｸﾄ ﾌﾞﾗｹﾂﾄ L 2
38 EZ4-455-708-01 BRACKET (C), DUCT ﾀﾞｸﾄ ﾌﾞﾗｹﾂﾄ (C) 1
39 EZ4-454-503-01 BARE (TKP0130W15R20), CABLE ｹ-ﾌﾞﾙ ﾍﾞｱ (TKP0130W15R20) 4
40 EZ1-492-217-14 SOLENOID VALVE ASSY ｿﾚﾉｲﾄﾞ ﾊﾞﾙﾌﾞ ASSY 1
41 EZ4-453-569-01 PLUG (CYP025-08B29449) ﾌﾟﾗｸﾞ (CYP025-08B29449) 3
42 EZ4-426-151-01 SILENCER(AN10-01) ｻｲﾚﾝｻ(AN10-01) 2
43 EZ4-447-063-41 UNION (KQ2L08-01AS), ELBOW ｴﾙﾎﾞ ﾕﾆｵﾝ (KQ2L08-01AS) 2
44 EZ4-457-146-31 CONTROLLER (AS1211F-M5-02A) ｽﾋﾟ-ﾄﾞ ｺﾝﾄﾛ-ﾗ-(AS1211F-M5-02A) 16
45 EZ1-492-215-21 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾊﾞ ｹﾞﾝﾃﾝ RL4) 1
46 EZ4-453-764-01 RAIL, DIN(5PERF60MM/Z) DIN ﾚ-ﾙ (NS35/7, 5PERF60MM/Z) 2
47 EZ4-453-826-01 PULLEY (P1110-015) (E), TIMING ﾀｲﾐﾝｸﾞ ﾌﾟ-ﾘ (P1110-015) E 6
48 EZ4-453-823-01 PULLEY (P1110-010-1) (B) ﾀｲﾐﾝｸﾞ ﾌﾟ-ﾘ (P1110-010-1) B 4
49 EZ2-177-403-01 BELT, TIMING (234-3GT-9) ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ (234-3GT-9) 4
50 EZ4-453-828-21 BELT (1947-3GT-9), TIMING ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ (1947-3GT-9) 3
A-63
A20-1
【RX-7】搬送部ユニット-幅調整 1
【RX-7】Conveyor unit - 1
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
51 EZ4-473-489-01 BRACKET, HARNESS GUIDE ﾊ-ﾈｽ ｶﾞｲﾄﾞ ﾌﾞﾗｹﾂﾄ 2
52 EZ4-431-981-31 PIN (DIA. 4), PARALLEL ﾍｲｺｳ ﾋﾟﾝ ﾌｱｲ 4 ｼﾘ-ｽﾞ 26
53 EZ7-683-423-04 BOLT,HEXAGON SOCKET 4X16 6 ｶｸｱﾅﾂｷ ﾎﾞﾙﾄ 4X16 77
54 EZ7-683-420-04 BOLT,HEXAGON SOCKET 4X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X10 50
55 EZ7-683-436-04 BOLT,HEXAGON SOCKET 5X12 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 5X12 24
56 EZ7-683-401-04 BOLT,HEXAGON SOCKET 3X4 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X4 12
57 EZ7-683-403-04 BOLT,HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 54
58 EZ7-683-427-04 BOLT,HEXAGON SOCKET 4X25 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 4X25 6
59 EZ4-718-766-02 SET-SCREW (M3X5 SUS), HEAD ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ (M3X5 SUS) 8
60 EZ2-915-937-11 BOLT (M4 SUS), SOCKET BUTTON ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾀﾝ ﾎﾞﾙﾄ (M4 SUS) 20
61 EZ7-624-198-21 STOP RING 10, TYPE C C ｶﾞﾀ ﾄﾒﾜ 10 (ｼﾞｸ ﾖｳ) 6
62 EZ4-701-529-01 TIE MOUNT (MB1) ﾀｲﾏｳﾝﾄ (MB1) 35
63 EZ7-682-249-09 SCREW +K 3X10 +K 3X10 26
64 EZ7-682-246-09 SCREW +K 3X5 +K 3X5 9
65 EZ7-683-435-04 BOLT,HEXAGON SOCKET 5X10 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 5X10 55
66 EZ4-454-517-01 PIN (B4X16 SUS), PARALLEL ﾍｲｺｳ ﾋﾟﾝ (B4X16 SUS) 6
67 EZ1-492-249-11 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾞﾂｸ ｱﾂﾌﾟﾋﾟﾝ 2) 1
68 EZ7-621-255-75 SCREW +P 2X12 +P 2X12 12
69 EZ4-454-549-01 PIN (B3X8) PARALLEL ﾍｲｺｳ ﾋﾟﾝ (B3X8) 2
70 401-55273 SLIT (OS-EX10-15) ｽﾘｯﾄ (OS-EX10-15) 3
71 EZ1-492-250-12 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾞﾂｸ ｱﾂﾌﾟﾋﾟﾝ 3) 1
72 EZ1-492-251-11 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾞﾂｸ ｱﾂﾌﾟﾋﾟﾝ 4) 1
73 EZ1-492-229-22 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾊﾞ ﾘﾐﾂﾄ RL3) 1
74 EZ1-492-311-11 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾊﾞ ﾘﾐﾂﾄ RL3(2)) 1
75 EZ1-492-215-11 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾊﾞ ｹﾞﾝﾃﾝ RL2) 1
76 EZ1-492-229-11 SENSOR ASSY ｾﾝｻ ASSY (ﾊﾊﾞ ﾘﾐﾂﾄ RL2) 1
