A-79 A22-3 【 RX-7R 】シングル搬送レーン 1 【 RX-7R 】 Single Conveyor lane - 1 ｲﾗｽﾄ番号 Ref.No. 品番 Part Number Description 品名 個数 Q'ty 備考 Remarks 51 EZ4-536-831-01 T APE FIXED ｺﾃｲﾃ-ﾌﾟ 8 52 402-09074 CENT ER SUPPORT(1) ｾﾝﾀｰｻﾎﾟｰﾄ(1)…
A-78
A22-3
【RX-7R】シングル搬送レーン 1
【RX-7R】Single Conveyor lane - 1
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ1-492-207-11 SENSOR FIBER (FT-AL05) ﾌｱｲﾊﾞ ｾﾝｻ (FT-AL05) 3
2 EZ1-492-216-12 SENSOR ASSY ｾﾝｻ ASSY (ｸﾗﾝﾌﾟ 1) 1
3 EZ1-492-216-22 SENSOR ASSY ｾﾝｻ ASSY (ｸﾗﾝﾌﾟ 2) 1
4 EZ4-447-052-11 UNION (KQ2H02-M3G) HALF ﾊ-ﾌ ﾕﾆｵﾝ (KQ2H02-M3G) 8
5 402-00902 CONVEYOR RAIL_LANE1 ｺﾝﾍﾞｱｰﾚｰﾙ_ﾚｰﾝ 1 1
6 402-00610 COLLAR(M3)_STEP
ﾀﾞﾝﾂｷｶﾗｰ(M3)
8
7 402-00912 JOINT(A)CYLINDER ｼﾘﾝﾀﾞｰｼﾞｮｲﾝﾄ(A) 4
8 402-00985 SENSOR BRACKET(1) ｾﾝｻｰﾌﾞﾗｹｯﾄ(1) 1
9 402-00986 SENSOR BRACKET(2) ｾﾝｻｰﾌﾞﾗｹｯﾄ(2) 1
10 402-03788 SENSOR BRACKET(C2) ｾﾝｻｰﾌﾞﾗｹｯﾄ(C2) 1
11 EZ4-454-328-01 STOPPER CLAMP ｸﾗﾝﾌﾟ ｽﾄﾂﾊﾟ 4
12 402-00911 CLAMP BRACKET
ｸﾗﾝﾌﾟﾌﾞﾗｹｯﾄ
2
13 EZ4-454-500-01 CYLINDER (CDUJB8-11-DCP6468P) ｼﾘﾝﾀﾞ (CDUJB8-11-DCP6468P) 4
14 EZ4-454-501-01 GUIDE (LWLG9C1R52BS1EB09) ｶﾞｲﾄﾞ (LWLG9C1R52BS1EB09) 4
15 EZ4-454-519-01 SOLENOID (SBP5) BALL ﾎﾞ-ﾙ ﾌﾟﾗﾝｼﾞﾔ (SBP5) 4
16 EZ4-455-733-01 WYE (KJU02-00) UNION ﾕﾆｵﾝ ﾜｲ (KJU02-00) 4
17 EZ4-702-261-02 BOLT HEXAGON SOCKET (M3X6) ﾛﾂｶｸ ｱﾅﾂｷ ｻﾗ ﾎﾞﾙﾄ (M3X6) 6
18 EZ4-716-434-11 TIE INSULOCK(AB100 BLACK)
ｲﾝｼﾕﾛﾂｸ ﾀｲ(AB100 ｸﾛ)
6
19 EZ4-722-956-01 LABEL(SILVER) BLANK ﾌﾞﾗﾝｸ ﾗﾍﾞﾙ ｷﾞﾝ(TTC82YS-10) 2
20 EZ7-630-003-55 TUBE (TU0212B-20) 2MMX20M BLK ﾁﾕｰﾌﾞ(TU0212B-20) 2MMX20M BLK 7.08
21 EZ7-682-247-09 SCREW +K 3X6 SCREW +K 3X6 6
22 EZ7-683-401-04 BOLT HEXAGON SOCKET 3X4 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X4 16
23 EZ7-683-403-04 BOLT HEXAGON SOCKET 3X6 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X6 34
24 EZ7-683-404-04 BOLT HEXAGON SOCKET 3X8
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X8
8
25 EZ7-683-421-04 BOLT HEXAGON SOCKET 4X12 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ(C4X12) 8
26 402-00906 GUIDE RAIL_PC BOARD ｷﾊﾞﾝｶﾞｲﾄﾞﾚｰﾙ 2
27 SM-6040802-TN SCREW M4X0.7 L=8 ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8 2
28 SM-6040602-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ 2
29 400-00863 CONVEYOR_BELT_S ｺﾝﾍﾞｱﾍﾞﾙﾄ S 2
30 400-00850 DRIVE_PULLEY_F
ﾄﾞﾗｲﾌﾞﾌﾟｰﾘ F
2
31 SM-8040602-TP SCREW M4X0.7 L=6 ﾄﾒﾈｼﾞ 4
32 402-00989 PLATE_BELT SUPPORT ﾍﾞﾙﾄｻﾎﾟｰﾄﾌﾟﾚｰﾄ 2
33 402-00990 PLATE_PC BOARD GUIDE(1) ｷﾊﾞﾝｶﾞｲﾄﾞﾌﾟﾚｰﾄ(1) 1
34 402-00991 PLATE_PC BOARD GUIDE(2) ｷﾊﾞﾝｶﾞｲﾄﾞﾌﾟﾚｰﾄ(2) 1
35 402-03944 SCREW M2.5 L=6 ｻﾗﾈｼﾞ M2.5 L=6 10
36 E2111-715-0A0 CONVEYOR PULLEY ASM.
ﾊﾝｿｳﾌﾟｰﾘ(ｸﾐ)
4
37 E2089-721-0A0 CONVEYOR PULLEY B ASM. ﾊﾝｿｳﾌﾟｰﾘ B ｸﾐ 10
38 402-00909 COLLAR(1)PULLEY ﾌﾟｰﾘｰｶﾗｰ(1) 10
39 402-00910 COLLAR(2)PULLEY ﾌﾟｰﾘｰｶﾗｰ(2) 4
40 SM-4042001-SC SCREW M4X0.7 L=20 ﾅﾍﾞｺﾈｼﾞ M4X0.7 L=20 4
41 SM-4041601-SC SCREW M4X0.7 L=16 ﾅﾍﾞｺﾈｼﾞ M4X0.7 L=16 10
42 NM-6040001-SC NUT M4X0.7 TYPE1
六角 ﾅｯﾄ M4X×0.7 1 種
4
43 WP-0430801-SC WASHER M4 ﾋﾗｻﾞｶﾞﾈ M4 4
44 WS-0410002-KN SPRING WASHER M4 ﾊﾞﾈｻﾞｶﾞﾈ M4 4
45 402-02038 SPACER GUIDE ｶﾞｲﾄﾞｽﾍﾟｰｻｰ 4
46 402-02219 WASHER_PC BOARD GUIDE ｷﾊﾞﾝｶﾞｲﾄﾞﾖｳﾜｯｼｬｰ 8
47 402-00992 SUPPORT_PC BOARD GUIDE ｷﾊﾞﾝｶﾞｲﾄﾞｻﾎﾟｰﾄ 2
48 402-01297 SPACER_PULLEY
ﾌﾟｰﾘｰｽﾍﾟｰｻｰ
2
49 SM-1030552-TN PLATE SCREW M3 L=5 ｻﾗﾈｼﾞ M3 L=5 8
50 EZ4-701-529-01 TIE MOUNT (MB1) ﾀｲﾏｳﾝﾄ (MB1) 4
A-79
A22-3
【RX-7R】シングル搬送レーン 1
【RX-7R】Single Conveyor lane - 1
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
51 EZ4-536-831-01 TAPE FIXED ｺﾃｲﾃ-ﾌﾟ 8
52 402-09074 CENTER SUPPORT(1) ｾﾝﾀｰｻﾎﾟｰﾄ(1) 1
53 402-08796 RETAINER(2)_PC BOARD(SLIDE) ｷﾊﾞﾝｵｻｴ 2(ｽﾗｲﾄﾞ) 2
54 SM-6050802-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ 4
55 EZ7-683-408-04 BOLT HEXAGON SOCKET 3X16 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X16 8
