PART No. ｲﾗｽﾄ No. REF No. PART NAME REMARKS Q'TY 20 部品加 工部(Vｶｯ ﾄ部(4P)2) PART P ROCESS SECT. ( V-CUT SECT.( 4P)-2) 部 品 名 品 番 個数 備 考 R 2 R 3 R 1 1 006 N210149093AA LEVER 1 007 X01L1301202 LEVER 1 008 X01L1301302 LEVER…
部品加工部(Vｶｯﾄ部(4P)2)
PART PROCESS SECT. (V-CUT SECT.(4P)-2)
20
FN610130477AA_06-2
M261
PART No.
ｲﾗｽﾄ
No.
REF
No.
PART NAME
REMARKSQ'TY
20
部品加工部(Vｶｯﾄ部(4P)2)
PART PROCESS SECT. (V-CUT SECT.(4P)-2)
部 品 名品 番 個数 備 考
R
2
R
3
R
1
1
006 N210149093AA
LEVER
1007 X01L1301202
LEVER
1008 X01L1301302
LEVER
2
012 X01A13008
PIN
1015 X01A13029
SPRING
1016 X01A13030
SPRING
2
017 X01A13033
PIN
1
018 N210133270AC
CUTTER
1019 N210133271AC
CUTTER
1020 N210124716AA
GUIDE
1
021 N210124717AA
GUIDE
2
022 X01A13038
PIN
1023 X01A13042
SPRING
1024 X01A13044
SPRING
2
025 X01A13054
SPRING HOOK
NART6UUVR
2
N005
N531NART-060
ROLLER FOLLOWER
NP3.2X3.5
2
N006
N560NP3.23.5
GREASE NIPPLE
M2.5-6H-4T A2J (Trivalent)
2
N007
N510017841AA
HEXAGON NUT
2.5 10H A2J (Trivalent)
2
N008
N510041286AA
ROUND PLAIN WASHER
M2.5X6-10.9 A2J (Trivalent)
2
N009
N510017246AA
HEX. SOCKET HEAD CAP BOLT
M4X16-45H A2J (Trivalent)
2
N010
N510018367AA
HEX. SOCKET SET SCREW
MMS2.5-8
4
N018
N510020582AA
PIN
M4X16-10.9 A2J (Trivalent)
2
X506
N510017351AA
HEX. SOCKET HEAD CAP BOLT
4 10H A2J (Trivalent)
2
X562
N510018497AA
ROUND PLAIN WASHER
M4-6H-4T A2J (Trivalent)
2
X592
N510017855AA
HEXAGON NUT
M3X10-10.9 A2J (Trivalent)
4
X610
N510017305AA
HEX. SOCKET HEAD CAP BOLT
