F2FeederPartsList - 第18页
1-11
I･pulse F2 Series
F2-82-0603 (A type)
P 5
No. Code No. Parts Name Q'ty Parts No.
LG4-M1A60-100
BACK PLATE ASSY
1
AS -A08-8250
1 K87-M116A-100 SPRING HOOK PIN 4 CTF-M08- 166-B
2 KW1-M116U-000
ROLLER
2 CTF-M08- 342
3 LG4-M1A72-000
CONNECT PIN
1 FTA-A08-8146
4 LG4-M1A71-000
ROD CONNECT
1 FTA-A08-8147
5 LG4-M1A61-100
BACK PLATE
1 FTA-A08-8250
6 LG4-M1AA3-000
MICRO SWITCH ASSY
1 FTA-A08-8151-6
7 LG4-M1AA4-000
VALVE HARNESS ASSY
1 FTA-A08-8151-7
8 LG4-M1A6A-000
ROLLER AXIS T
1 FTA-A08-8173
9 LG4-M1A6C-000
LEAF T
1 FTA-A08-8173-1
10 LG4-M1A6B-000
ROLLER AXIS U
1 FTA-A08-8174
11 LG4-M1A6D-000
LEAF U
1 FTA-A08-8174-1
12 LG4-M1A6U-100
MIDDE GUIDE PLATE U
1 FTA-A08-8275
13 LG4-M1A6N-100
MIDDLE GUIDE PLATE C
1 FTA-A08-8276
LG4-M1AB1-000
VAL PACK CYLINDER
1 BDA10×15-327W
LG4-M1AB1-001
VAL PACK CYLINDER
1 BDA10×15-350W
15 LG4-M1AB3-000
BARB CONNECTOR
1 BF3BU-136W
16 K87-M111N-000
SCREW,PAN HEAD+
5 3MC-3-P
17 LG4-M1ADC-000
SCREW,PAN HEAD+
1 3MC-7-P
18 K87-M11B4-100
SCREW,FLAT HEAD+
2 3MK-12-P
19 LG4-M1ADD-000
SCREW,FLAT HEAD
4 3MK-14-P
20 K87-M21BN-000
SCREW,NUT
2 3MH-P
21 K87-M11D7-000
CIRCLIP E
1 E.32
22
23
24
25
26
27
28
29
30
31
32
14
1-10
1-11
I･pulse F2 Series
F2-82-0603 (A type)
P 6
No. Code No. Parts Name Q'ty Parts No.
LG4-M1A81-000 D.ROLLER ALL ASSY 1 AS3-A08-1170-D
LG4-M1A81-001 D.ROLLER ALL ASSY 1 AS5-A08-1170-D
LG4-M1A81-002 D.ROLLER ALL ASSY 1 AS6-A08-1170-D
LG4-M1A82-000
INDEKING LEVER ASSY
1 AS -A08-8164
LG4-M1A82-001
INDEKING LEVER ASSY
1 AS1-A08-8164
LG4-M1A82-002
INDEKING LEVER ASSY
1 AS2-A08-8164
KW1-M119F-000
DRIVE ROLLER ASSY
1 AS -A08-1170-D
KW1-M119L-000
IDLER ROLLER ASSY
1 AS -A08-1162-D
1 K87-M111C-000
PLANE WASHER
1 CTF-A08- 16-B
2 K87-M117B-000
PLANE WASHER
1 CTF-M08- 76-B
3 KW1-M119D-000
LEVER METAL
1 FTA-A08-1158-C
4 KW1-M119R-000
COLLAR
1 FTA-A08-1161
5 KW1-M119M-000
IDLE ROLLER
1 FTA-A08-1162-D
6 KW1-M119G-000
DRIVE ROLLER
1 FTA-A08-1170-D
7 KW1-M119H-000
COVER PLATE
1 FTA-A08-1171-B
8 KW1-M11A3-001
LOWER GUIDE PLATE,L
1 FTA-A08-1179-C
9 LG4-M1A62-000
METAL SHAFT
1 FTA-A08-8155
10 LG4-M1A63-000
LEVER AXIS PIN
1 FTA-A08-8159
11 LG4-M1A64-000
COLLAR
1 FTA-A08-8159-1
12 LG4-M1A65-010
TENSION LEVER
1 FTA-A08-8160-B
13 LG4-M4A8B-000
TENSION LEV. RE. SP.
1 FTA-A12-8160-700
14 LG4-M1A66-000
ROLLER AXIS
1 FTA-A08-8163
15 LG4-M1A83-000
INDEKING LEVER
1 FTA-A08-8164
16 LG4-M1A8A-000
INDEKING LEV.RE. SP.
1 FTA-A08-8164-440
LG4-M1A84-000
ARM STUD
1 FTA-A08-8166
LG4-M1A84-010
ARM STUD
1 FTA-A08-8166-B
18 LG4-M1A6M-100
MIDDLE GUIDE PLATE T
1 FTA-A08-8277
LG4-M1A6P-010
LOWER GUIDE PLATE,R
1 FTA-A08-8178-B
LG4-M1A6P-011
LOWER GUIDE PLATE,R
1 FTA-A08-8178-C
20 KW1-M119B-000 ONE･WAY CLUTCH 1 OWC4-13-3.1-L
KW1-M119E-000 ONE･WAY CLUTCH 1 OWC6-16-3.5-L
KW1-M119E-001 ONE･WAY CLUTCH 1 OWC6-16-3.5-176
22 K87-M11BF-000
SCREW,FLAT HEAD
1 P2MK-4-IB
23 K87-M11BB-000
SCREW,FLAT HEAD
1 P2.6MK-5-IB
24 K87-M21BB-000 SCREW,TRUSS HEAD+ 1 T2.6M-5-P
25 K87-M111N-000 SCREW,PAN HEAD+ 6 3MC-3-P
26 K87-M11BE-000 THRUST WASHER 2 3V-0.5-8-P
21
19
17
1-12
