4E- 3
I･pulse F2 Series
F2-12 (E type)
P 1
No. Code No. Parts Name Q'ty Parts No.
※1 LG4-M4A10-030 BODY ASSY 1 AS1-A12-8101-C
LG4-M4A1M-110 MAIN LEVER ASSY 1 AS4-A12-8131
1 K87-M111G-100 PUSH PIN 1 CTF-M08- 325
2 LG4-M1A1L-000 THRUST WASHER 1 CTF- 53- 38-02
3 K87-M111H-200 BACK STOPPER 1 FTA-A08-1114
4 LG4-M4A1T-000 ARM AXIS PIN 1 FTA-A12-8134
5 LG4-M4A11-020 BODY 1 FTA-A12-8101-C
※1 6 LG4-M1A12-500 MAIN GUIDE PIN 1 FTA-E08-8502
※1 7 LG4-M1A13-500 LOCATE PIN R 1 FTA-E08-8503
※1 8 LG4-M1A14-500 LOCATE PIN F 1 FTA-E08-8504
9 LG4-M4A15-000 PLUG HOLDER GUIDE 1 FTA-A12-8105
10 LG4-M1A16-000 PLUG HOLDER 1 FTA-A08-8106
11 KW1-M221F-100 STOPPER PIN 1 CTF-M12- 313
12 LG4-M4A19-001 BACK STOPPER RE. SP. 1 FTA-A08-6164-1600
13 K87-M211B-000 BACK STOPPER AXIS 1 CTF-M12- 315
14 LG4-M1A1K-000 LEVER AXIS PIN 1 FTA-A08-8130-B
15 LG4-M4A1N-000 MAIN LEVER 1 FTA-A12-8131
16 LG4-M4A1P-100 ARM 1 FTA-A12-8235
17 LG4-M4A1S-000 ARM AXIS PIN 1 FTA-A12-8139
18 K87-M1186-000 BARB CONNECTOR 1 BF3BU
19 LG4-M1AB2-000 PLUG 1 MA-MC05PM
20 LG4-M4ABA-010 AIR HOSE 1 U3B-167
21 K87-M23B3-000 SCREW,SET 3 3MY-5
22 K87-M111R-000 SCREW,SET 6 3MY-5-F
23 K87-M1115-000 CIRCULAR RIVET 1 2-10
24 LG4-M1AD2-000 CIRCLIP C 1 STW-7
25
26
27
28
29
30
31
32
※1…F2-12-2318E～
4E-2
4E-3
I･pulse F2 Series
F2-12 (E type)
P 2
No. Code No. Parts Name Q'ty Parts No.
KW1-M1120-000 SPROCKET ASSY 1 AS2-A08-1107-P4
LG4-M4A2A-010 RACKING LEVER ASSY 1
AS-A12-8117-C
LG4-M4A2M-000 RATCHET AXIS ASSY
1
AS-A12-8112
1 K87-M111C-000 PLANE WASHER 1
CTF-A08- 16-B
2
LG4-M4A2E-000
RACKING LEVER 1
FTA-A12-8108
3 K87-M112F-000 SPRING HOOK PIN 1
CTF-A08- 211-B2
4 K87-M112M-100 FLANGE A 1
CTF-A08- 712-1
5 LG4-M1A2F-000 SCREW COIL SPRING 1
FTA-A08-8111-1
6 K87-M1121-000 METAL 1
FTA-A08-1103
7 K87-M1122-000 RIVET 3
FTA-A08-1103-1
8 KW1-M1123-000 SPROCKET 1
FTA-A08-1104-B
9 K87-M1124-000 RATCHET 1
FTA-A08-1107-P4
10 K87-M112G-100 RACKING POLE 1
FTA-A08-1111
11
LG4-M1A2D-000 SHUTTER DRIVE PIN
1
FTA-A08-8109
12
LG4-M1A2C-000 RACKING POLE AXIS
1
FTA-A08-8110
13
LG4-M4A2N-000 RATCHET AXIS
1
FTA-A12-8112
14
LG4-M4A2P-000 FLANGE B
1
FTA-A12-8112-2
15
LG4-M4A2B-010 MAIN ARM
1
FTA-A12-8117-C
16
LG4-M4A1R-010 SUB ARM
1
FTA-A12-8138-B
17 K87-M11BF-000
SCREW,FLAT HEAD
1
P2MK-4-IB
18
19
20
21
22
23
24
25
26
27
28
29
30
31
