I･pulse F2 Series F2-12 (E type) P 1 No. Code No. Parts Name Q'ty Parts No. LG4-M4A10-050 BODY ASSY 1 AS1-A12-8101-D LG4-M4A10-060 BODY ASSY 1 AS2-A12-8101-D LG4-M4A1M-010 MAIN LEVER ASSY 1 AS3-A12-8131 1 K87-M111G-…

100%1 / 933
I･pulse　 F2　Series
F2-12 (E type)
P 1
No. Code No. Parts Name Q'ty Parts No.
LG4-M4A10-050 BODY ASSY 1 AS1-A12-8101-D
LG4-M4A10-060 BODY ASSY 1 AS2-A12-8101-D
LG4-M4A1M-010 MAIN LEVER ASSY 1 AS3-A12-8131
1 K87-M111G-100 PUSH PIN 1 CTF-M08- 325
2 LG4-M1A1L-000 THRUST WASHER 1 CTF- 53- 38-02
3 K87-M111H-200 BACK STOPPER 1 FTA-A08-1114
4 LG4-M4A1T-000 ARM AXIS PIN 1 FTA-A12-8134
5 LG4-M4A11-030 BODY 1 FTA-A12-8101-D
6 LG4-M1A12-510 MAIN GUIDE PIN 1 FTA-E08-8502-B
7 LG4-M1A13-510 LOCATE PIN R 1 FTA-E08-8503-B
8 LG4-M1A14-510 LOCATE PIN F 1 FTA-E08-8504-B
LG4-M4A15-000 PLUG HOLDER GUIDE 1 FTA-A12-8105
LG4-M1A15-010 PLUG HOLDER GUIDE 1 FTA-A08-8105-B
LG4-M1A16-000 PLUG HOLDER 1 FTA-A08-8106
LG4-M1A16-010 PLUG HOLDER 1 FTA-A08-8106-B
11 KW1-M221F-100 STOPPER PIN 1 CTF-M12- 313
12 LG4-M4A19-001 BACK STOPPER SPRING 1 FTA-A08-6164-1600
13 K87-M211B-000 BACK STOPPER AXIS 1 CTF-M12- 315
14 LG4-M1A1K-000 LEVER AXIS PIN 1 FTA-A08-8130-B
15 LG4-M4A1N-000 MAIN LEVER 1 FTA-A12-8131
16 LG4-M4A1P-000 ARM 1 FTA-A12-8135-B
17 LG4-M4A1S-000 ARM AXIS PIN 1 FTA-A12-8139
18 K87-M1186-000 BARB CONNECTOR 1 BF3BU
19 LG4-M1AB2-000 PLUG 1 MA-MC05PM
20 LG4-M4ABA-010 AIR HOSE 1 U3B-167
21 K87-M23B3-000 SCREW,SET　 3 3MY-5
22 K87-M111R-000 SCREW,SET 6 3MY-5-F
23 K87-M1115-000 CIRCULAR RIVET 1 2-10
※1 24 LG4-M1AD2-000 CIRCLIP C 1 STW-7
※1…F2-12-003248E～
※1 10
※1
※1 9
