7C-7
I･pulse F2 Series
F2-32 (C type)
P 3
No. Code No. Parts Name Q'ty Parts No.
LG4-M6A30-010
HOLD LEVER ASSY 1 AS-A24-8190-C
LG4-M6A3A-002
CLAMP LEVER ASSY 1 AS4-A24-8191-B
1 K87-M111G-100 PUSH PIN 1
CTF-M08- 325
2
LG4-M1A1K-000
LEVER AXIS PIN 1
FTA-A08-8130-B
3
LG4-M1A3A-000 HINGE PIN 1
1
FTA-A08-8191-1
4
LG4-M1A3B-000 HINGE PIN 2
1
FTA-A08-8192-1
5
LG4-M1A36-000 ARM
1
FTA-A08-8193
6
LG4-M1A33-000 LINK PLATE
1
FTA-A08-8194
7
LG4-M1A3L-000 CLANK ARM AXIS PIN
1
FTA-A08-8195
8
LG4-M1A37-000 ADJUST CLAMP PIN
1
FTA-A08-8196
9
LG4-M1A3K-001 CLAMP LEVER AXIS PIN
1 FTA-A08-8197-B
10 LG4-M6A31-010 HOLD LEVER
1 FTA-A24-8190-C
11
LG4-M6A3B-001 CLAMP LEVER
1 FTA-A24-8191-B
12
LG4-M6A3D-000
STUD 1 FTA-A24-8191-1
13
LG4-M6A3M-000
SCREW COIL SPRING 1
FTA-A24-8191-SCSp
14 LG4-M6A3C-001 CLANK ARM
1 FTA-A24-8192-B
15
LG4-M6A32-000 LINK PIN T
1
FTA-A24-8198
16
LG4-M6A39-000 LINK PIN U
1
FTA-A24-8199
17
LG4-M6AH2-000
BOARD ITGA 1
18 LG4-M6AA6-100
SENSOR HARNESS ASSY 1
FTA-A24-8266-1
19
LG4-M6A1B-100
SENSOR PLATE 1
FTA-A24-8267
20
LG4-M6ABB-100
SENSOR HARNESS GUIDE 2
SKM-2
21
LG4-M6ABC-100
INSULOK TIES 2 ALT-102S-B
22 LG4-M1ADG-100 SCREW,PAN HEAD+
2
P2MC-4-P
23
LG4-M6ADH-100 SCREW,PAN HEAD+
2
T4M-6-P
24 LG4-M6ADG-000
BOLT,HEX SOCKET HEAD
2
3MX-5-P
25 K87-M111T-000 SCREW,SET 1 3MY-3-F
26
K87-M111R-000 SCREW,SET 2 3MY-5-F
27 LG4-M1AD4-100 SCREW NUT 2
2MH-P
28 K87-M21BN-000
SCREW NUT
1
3MH-P
29 K87-M21BM-000 SPRING LOCK WASHER 1
3MU-P
30
31
32
33
7C-6
7C-7
I･pulse F2 Series
F2-32 (C type)
P 4
No. Code No. Parts Name Q'ty Parts No.
※1
LG4-M7A40-010
TAPE GUIDE PLATE UNIT 1 AS-A32-8119-D
※1
LG4-M7A4A-000
TAPE GUIDE PLATE ASSY 1 AS1-A32-8119-D
1 LG4-M7A46-001 LOCK LEVER
1
FTA-A32-8127-B
2
LG4-M6A48-000 T.G. PUSH SPRING
1
FTA-A24-8127-73
3 LG4-M1A4K-000 T.G.A. GUIDE PIN
1
FTA-A08-8129
4
LG4-M7A43-000 SHUTTER PIECE
1
FTA-A32-8120-1
5
KW1-M4544-010
SHUTTER GUIDE PIN
2
FTA-A24-1121-B
6
LG4-M7A41-010
TAPE GUIDE PLATE 1
FTA-A32-8119-D
7 LG4-M6A4F-000 SIDE COVER
1
FTA-A24-8125-1
8
LG4-M7A42-010
SHUTTER PLATE 1
FTA-A32-8120-C
9 LG4-M6A49-001 COVER PLATE
1
FTA-A24-8123-B
10
LG4-M6A4L-000 TAPE GUIDE AXIS PIN
2
FTA-A24-8124
11 LG4-M6A47-000 T.G.GUIDE PIN
1
FTA-A24-8125
12 K87-M111P-000 SCREW,FLAT HEAD+ 2 P2MK-3
13
K87-M1547-000 SCREW,TRUSS HEAD 2 T2M-2.5-P
14 K87-M1548-000 PLANE WASHER 2 2MV(2V-0.4-6-P)
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
※1．．．F2-32-161C～
