7D-5
I･pulse  F2 Series
F2-32 (D type)
P 3
No. Code No. Parts Name Q'ty Parts No.
LG4-M6A30-010 HOLD LEVER ASSY 1 AS-A24-8190-C
LG4-M6A3A-002 CLAMP LEVER ASSY 1 AS4-A24-8191-B
1 K87-M111G-100 PUSH PIN 1 CTF-M08- 325
2 LG4-M1A1K-000 LEVER AXIS PIN 1 FTA-A08-8130-B
3 LG4-M1A3A-000 HINGE PIN 1 1 FTA-A08-8191-1
4 LG4-M1A3B-000 HINGE PIN 2 1 FTA-A08-8192-1
5 LG4-M1A36-000 ARM 1 FTA-A08-8193
6 LG4-M1A33-000 LINK PLATE 1 FTA-A08-8194
7 LG4-M1A3L-000 CLANK ARM AXIS PIN 1 FTA-A08-8195
8 LG4-M1A37-000 ADJUST CLAMP PIN 1 FTA-A08-8196
9 LG4-M1A3K-001 CLAMP LEVER AXIS PIN 1 FTA-A08-8197-B
10 LG4-M6A31-010 HOLD LEVER 1 FTA-A24-8190-C
11 LG4-M6A3B-001 CLAMP LEVER 1 FTA-A24-8191-B
12 LG4-M6A3D-000 STUD 1 FTA-A24-8191-1
13 LG4-M6A3M-000 SCREW COIL SPRING 1
FTA-A24-8191-SCSp
14 LG4-M6A3C-001 CLANK ARM 1 FTA-A24-8192-B
15 LG4-M6A32-000 LINK PIN T 1 FTA-A24-8198
16 LG4-M6A39-000 LINK PIN U 1 FTA-A24-8199
17 LG4-M6AH2-000 BOARD ITGA 1
18 LG4-M6AA6-100 SENSOR HARNESS ASSY 1 FTA-A24-8266-1
19 LG4-M6A1B-100 SENSOR PLATE 1 FTA-A24-8267
20 LG4-M6ABB-100 SENSOR HARNESS GUIDE 2 SKM-2
21 LG4-M6ABC-100 INSULOK TIES 2 ALT-102S-B
22 LG4-M1ADG-100 SCREW,PAN HEAD+ 2 P2MC-4-P
23 LG4-M6ADH-100 SCREW,PAN HEAD+ 2 T4M-6-P
24 LG4-M6ADG-000 BOLT,HEX SOCKET HEAD 2 3MX-5-P
25 K87-M111T-000 SCREW,SET 1 3MY-3-F
26 K87-M111R-000 SCREW,SET 2 3MY-5-F
27 LG4-M1AD4-100 SCREW NUT 2 2MH-P
28 K87-M21BN-000 SCREW NUT 1 3MH-P
29 K87-M21BM-000 SPRING LOCK WASHER 1 3MU-P
30
31
32
33
