I･pulse F2 Series
F2-32 (D type)
P 8
No. Code No. Parts Name Q'ty Parts No.
※1 LG4-M6A9D-000 REEL GUIDE ARM ASSY 1 AS-A24-8269-B
1 LG4-M4A92-010 REEL TENTION AXIS 1 FTA-A12-8182-B
※1 2 LG4-M4A9B-002 COIL SPRING 1 FTA-A12-8183-D
※1 3 LG4-M6A9A-101 REEL GUIDE ARM 1 FTA-A24-8269-B
※1 4 LG4-M4A9C-001 GUIDE ARM 1 FTA-A12-8181-E1
5 LG4-M7A65-010 REEL AXIS 1 FTA-A32-8172-B
6 K87-M55BN-000 SCREW,FLAT HEAD+ 1 3MK-8-P
7 LG4-M4ADH-000 SCREW,FLAT HEAD+ 1 4MK-12-P
※1 8 LG4-M4AD5-000 FLAT RIVET 2 2×4-2.5-BS
9 LG4-M4ADF-000 CIRCLIP E 1 E.50
10 LG4-M7AC1-100 SERIAL NO. STICKER 1 FTA-A32-8250-SNS
11 LG4-M7AC3-100 SERIAL NO. STICKER 1
FTA-A32-8250-SNS1
12 LG4-M1ACX-111 PROTECTION SEAL 1 FTA-A08-8253-PS-C
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
※1…F2-32-346D～
