APPENDIX 7
ENEPIG PWB Surface Finish Shear Test Project
Dave Hillman, Brad Williams, Tim Pearson, Ross Wilcoxon and Jennet Volden
Rockwell Collins Inc.
INTRODUCTION
Rockwell Collins conducted solderball shear testing for the IPC 4-14 Plating Processes Subcommittee as part of their efforts
to create a specification for electroless nickel/electroless palladium/immersion gold (ENEPIG) circuit card finishes. A test
program was conducted to assess the solderball shear strength of a series of test coupons with different electroless palladium
plating thicknesses using both tin/lead and lead-free soldering processes.
Test Vehicle The IPC 4-14 subcommittee supplied solderball shear test coupons that were 2.4 inches long x 0.93 inches
wide x 0.063 inches thick. The solderball pad was 0.025 inches in diameter. The palladium thickness varied for each coupon.
Table A7-1 lists the measured palladium thickness/coupon combinations and Figure A7-1 illustrates the shear test coupon.
Solder Processes The shear test coupons were manually stenciled using low residue tin/lead (Sn63Pb37) and lead-free
(SAC305) solder pastes per IPC-JSTD-004 and a 0.005 inch thick stainless steel stencil. A 0.025 inch diameter Sn63Pb37
alloy solder sphere and a 0.035 inch diameter SAC305 alloy solder sphere were manually placed on a random selection of
stenciled deposits. The test coupons were then processed in a five zone Electrovert Omniflow reflow oven using a nitrogen
reflow atmosphere. The peak reflow temperature for the Sn63Pb37 alloy was 220 °C and for the SAC305 alloy was 245 °C.
The Time Above Liquidus for the Sn63Pb37 alloy was 30-60 seconds and for the SAC305 alloy was 45-90 seconds. The test
coupons were cleaned using an in-line cleaner that used Kyzen Aquanox A4625 saponifier/deionized water solution.
Table A7-1 Test Coupon Serial Number and Palladium Thickness
Sample Number Pallidium Thickness (µinches)
1 3.48
2 5.49
3 6.84
4 1.57
5 6.38
6 8.32
16 3.8
17 5.93
18 6.9
19 17.95
Figure A7-1 Shear Test Coupon – Note right portion of the test coupon is missing due to removal for cross-sectional analysis (left view)
and close up view of solder paste deposit reflowed on coupon pads (smaller solder joints) and a pad with a solderball reflowed on pad (large sol-
der joint) (right view)
IPC-4556 January 2013
48
Shear Test Parameters The solderball shear testing was conducted using a DAGE 5000 shear test system. A BS5KG car-
tridge was used with a 50 gram ball shear load. A shear speed of 500 um/second, a shear height of 50 µm and an over travel
distance of 100 µm were used in the test. Figure A7-2 illustrates the DAGE 5000 shear system used in the test.
Figure A7-2 DAGE 5000 Shear Test System – Macro View (left view) and Close Up of Shear Head (right view)
All of the shear test failures were of a cohesive nature and not of an adhesive mode at the solder joint or coupon pad loca-
tions. The latter adhesive failure modes are illustrated in Figure A7-3.
Figure A7-3 Solderball Shear Results – Coupon pad ripped out of board during shear test (left view) and solderball sheared through sol-
der joint during shear test (right view)
January 2013 IPC-4556
49
Test Results Table A7-2 through Table A7-5 list the solderball shear test results. The test coupon shear test results popu-
lations were consistent with the Sn63Pb37 alloy results having standard deviations that were 1-5% of the average while the
SAC305 alloy results had standard deviations that were 10-30% of the average. There are no industry specification minimum
values available for results comparison use.
Table A7-2 Sn63Pb37 Solderball Shear Test Results Coupon Set 1 (grams)
Table A7-3 Sn63Pb37 Solderball Shear Test Results Coupon Set 2 (grams)
IPC-4556 January 2013
50
Sample 6
１３１８．５
１３４５．４
１３２８．４
１４４５．２
１４０３．１
１３５１．１
１２８０．２
１２５６日
１３８６
１３２８．４
１３２４．５
１３３４．１
１２９６．２
１３１１．８
１２９５．３
１２５０．８
１２５７．６
１２９０．７
１３３０．９
１２８０．５
Average
１３２０．７６５
Std Dev
４９．７１８７２
Sample 16
１３４３．６｜
１３７８．１
１３９９
１３６５
１３９１．９
１３５２．２
１３７０．１
１３７３．６
１３６０．８
１３６６．７｜
１３７０．１
１６．７７７６９７
Sample 17
１２８７．７｜
１３２７．５
１３３６
１３８７．３
１３６８．５
１３３７．７
１３６６．８｜
１３７６．２
１３４４．７］
１３７４．１
１３５０．６５
２９．８９１８８９
Sample 18
１３０６．８
１２６１．４
１３１７．３
１３３４．５
１３５１．５
１３４３．６
１３１１．１
１３８５．９
１２７２．４
１３４５．５
１３２３
３７．４５０６７９
Sample 19
１３１６．８
１３４３．２
１３４１．８
１３８８．２
１３５９
１２３８
１３４５．６
１３６６．２
１３３４．１
１３５３．２
１３３８．６１
４０．２０４３２４
Sample 1
１３４５．６｜
１３７４．３
１３１２．９
１３９５．４
１３９０．８
１３７５．９
１３６２｜
１３２５．８
１３４３．７
１３１６．５
Average
Std Dev
１３５４．２９
２９．９８２２３
Sample 2
１２９２．４
１３３５．２｜
１３６３．５
１３６６．５
１３３４
１２７４．８
１４１３．７
１３３１．７
１２９３．９
１４１５．４
１３６８．１
１３８８．３｜
１３３２．２｜
１２８６．８｜
１３６９６
１２９５
１３４７
１３０９．２｜
１２９８
１２９４．３
１３３５．４８
４２．６１０５７
Sample 3
１２６２．８｜
１２６３．９
１２５７．５
１３８６．８
１４０１．１
１３６０．５
１３９８．８
１３３２．３｜
１３２０
１３７６．２｜
１３４０．７
１３７１．５｜
１２７９．１
１４０７．１
１３６６．４
１３５９．３
１３４９．１
１３４８．１
１２７９．１
１２９５．９
１３３７．８１
４９．２６１７６
Sample 4
１２２９
１３７５
１４０１．３
１３１５．１
１１０６．７
１２０６．２
１２４８
１２０９．４
１２１７．３
１２７５．７
１２６０｜
１１４４．２｜
１１４８．５
１２４８．５
１１９４．４］
１２００．２］
１２７４．４
１１５４
１３７９
１３２３．９
Sample 5
１３０７
１２３６．７
１４０５．９
１２８８．１
１３３０．３
１２８０．５
１３９１
１３４１．７
１３９６．８
１２６１．７
１３６７．９
１３６９．１
１３８１．７
１３６３．１
１４０１．３
１３３７．４
１４０４．６
１３３９．２
１３３５．６
１２４５．５４
８１．９８７３１
１３４４．１８９
５０．５０４９６
