5. Conditions
With hybrid calibration offset measurement, autocalibration is performed if any of the
following conditions are true:
Ÿ If a head with a serial number different to that in the memory of the machine is
attached.
Ÿ If a camera with a serial number different to that in the memory of the machine is
attached.
Ÿ If the position of the parts camera is recognized by the machine to be different
from the position in the memory of the machine.
Ÿ If the setting [Module Configuration] - [Placement angle measurement] is
changed from "Used" to "Not used", or from "Not used" to "Used".
Ÿ For M3-2(c), M6-2(c), M3-3(c), M3-3S, M6-3(c), and M6-3L modules, if the
setting [Module Configuration] - [Calibration Settings] - [Hybrid calibration] is
changed from "Used" to "Not used", or from "Not used" to "Used".
(Measurement is not performed again if the setting is changed and then returned
to its original setting before the machine is switched on.)
Hybrid Calibration Offset Measurement and Correction Operation Manual NXT V8.95
FUJI CORPORATION 8/18
6. Procedure flow
The following diagram shows the procedure flow from upgrade to completion of
production when using the hybrid calibration offset measurement function. Refer to the
individual chapters for details.
Perform version upgrade
Confirm the settings in Accessory
Software (“4. Enabling hybrid calibration
offset measurement”)
Perform hybrid calibration measurement
In case of error:
“8. Troubleshooting errors that occur
during hybrid calibration measurement”
Perform changeover
Perform hybrid calibration offset
Perform autocalibration
Perform production
Position the jig nozzles (“7. Performing
changeover”)
Transmit the job
Hybrid Calibration Offset Measurement and Correction Operation Manual NXT V8.95
FUJI CORPORATION 9/18
7. Performing changeover
7.1. Performing changeover for hybrid calibration measurement
The following explains how to perform changeover for hybrid calibration
measurement.
Set the jig nozzles in the nozzle station as shown below.
NXT-2 operation panel NXT-3 operation panel
Jig nozzles that can be used (nozzles IDs are given)
Head type
Machine condition
H01,
H02(F)
G04(F)
H12S,
H12HS,
H08
H12L
H04,
H04S(F
)
V12D,
H24
OF DX(S1) DX(R4) DX(R12)
φ5.0 jig nozzle for glass
jig parts
J11 J13 - - J17 - J21 J60 J39 -
φ1.3 jig nozzles for chip
jig parts
J12 J14 J16 J63 J18 J44 - J59 J41 J16
Ÿ Dedicated jig nozzles are required for hybrid calibration measurement. It is
necessary to combine these with the normal jig nozzles used for
autocalibration.
Ÿ The number of dedicated hybrid calibration jig nozzles does not depend on the
number of holders on the head. Instead, one nozzle is required for each of the
jig parts.
