3. Control-to-Control Communication Error Code and List of Error Messages
0005-002 4-23 Tg0248-PM-ER
Error Code Display A Display B
10510001 SETTING THE RECOGNITION
MONITOR DISPLAY MODE
“COMP. RECOG SELECTION” EXCEEDS THE RANGE
OF SETTING.
“CAMERA NO.” EXCEEDS THE RANGE OF SETTING.
10510003 SETTING THE RECOGNITION
MONITOR DISPLAY MODE
“COMPONENT ID” EXCEEDS THE RANGE OF SETTING.
10510004 SETTING THE RECOGNITION
MONITOR DISPLAY MODE
“COMPONENT NO.” EXCEEDS THE RANGE OF
SETTING.
10510002 SETTING THE RECOGNITION
MONITOR DISPLAY MODE
10510005 SETTING THE RECOGNITION
MONITOR DISPLAY MODE
“HEAD NO.” EXCEEDS THE RANGE OF SETTING.
10510006 SETTING THE RECOGNITION
MONITOR DISPLAY MODE
“NOZZLE ID” EXCEEDS THE RANGE OF SETTING.
10510007 SETTING THE RECOGNITION
MONITOR DISPLAY MODE
“DISPLAY MODE” EXCEEDS THE RANGE OF SETTING
10500000 SETTING THE RECOGNITION
FUNCTION
“EXECUTIVE FUNCTION” EXCEEDS THE RANGE OF
SETTING.
10510000 SETTING THE RECOGNITION
MONITOR DISPLAY MODE
“MODE” EXCEEDS THE RANGE OF SETTING.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
3. Control-to-Control Communication Error Code and List of Error Messages
0005-002 4-24 Tg0248-PM-ER
Error Code Display A Display B
10520000 SETTING THE RECOGNITION
ERROR IMAGE SAVE MODE
“FUNCTION” EXCEEDS THE RANGE OF SETTING.
10520001 SETTING THE RECOGNITION
ERROR IMAGE SAVE MODE
“MODE” EXCEEDS THE RANGE OF SETTING.
10520002 SETTING THE RECOGNITION
ERROR IMAGE SAVE MODE
“COMP. RECOG SELECTION” EXCEEDS THE RANGE
OF SETTING.
10520003 SETTING THE RECOGNITION
ERROR IMAGE SAVE MODE
“CAMERA NO.” EXCEEDS THE RANGE OF SETTING.
10520004 SETTING THE RECOGNITION
ERROR IMAGE SAVE MODE
“COMPONENT ID” EXCEEDS THE RANGE OF SETTING.
10520005 SETTING THE RECOGNITION
ERROR IMAGE SAVE MODE
“COMPONENT NO.” EXCEEDS THE RANGE OF
SETTING.
10520006 SETTING THE RECOGNITION
ERROR IMAGE SAVE MODE
“NOZZLE ID” EXCEEDS THE RANGE OF SETTING.
10520008 SETTING THE RECOGNITION
ERROR IMAGE SAVE MODE
“IMAGE NO.” EXCEEDS THE RANGE OF SETTING.
10520007 SETTING THE RECOGNITION
ERROR IMAGE SAVE MODE
10540000 SETTING THE RECOGNITION
TEACH MODE
“PARAMETER” EXCEEDS THE RANGE OF SETTING.
“HEAD NO.” EXCEEDS THE RANGE OF SETTING.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
3. Control-to-Control Communication Error Code and List of Error Messages
0005-002 4-25 Tg0248-PM-ER
Error Code Display A Display B
10560000 INITIALIZING THE INTERNAL
COMPONENT DATA
“MODE” EXCEEDS THE RANGE OF SETTING.
10
XXXXXX
ETC.
except the
above-
described
codes
ETC.
10550001 MACHINE TYPE RECOGNI-
TION
“LANGUAGE” EXCEEDS THE RANGE OF SETTING.
10550002 MACHINE TYPE RECOGNI-
TION
“TRACKBALL PORT” EXCEEDS THE RANGE OF
SETTING.
10550000 MACHINE TYPE RECOGNI-
TION
“MACHINE CODE” OR “TYPE CODE” EXCEEDS THE
RANGE OF SETTING.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
