0005-002 2-91 Tg0248-PM-ER
Error Code Display A Display B
3. Trouble Shooting after Error Display
60 05 05 SAFETY CIRCUIT
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
60 05 04 SAFETY CIRCUIT
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
60 05 03 SAFETY CIRCUIT
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
0005-002 2-92 Tg0248-PM-ER
Error Code Display A Display B
3. Trouble Shooting after Error Display
(Cause 1) The specified camera may not be able to recognize the lead width and pitch in the
component library data for the current program.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Select other view range camera.
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can’t be re-started, contact our service personnel.
61 02 01 INSIDE RECOGNITION
XXXXXX
REFER TO “SECTION 4 RECOGNITION ERROR”.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
Note: Refer to “Section 4 Recognition Error Codes”.
61 01 01 PLACEMENT NOZZLE NO AVAILABLE NOZZLE FOUND IN NOZZLE
STOCKER.
(Cause 1) No available nozzle found in nozzle stocker.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Register the nozzle used for the nozzle arrangement data.
(2) Arrange the nozzle in the nozzle stocker.
(3) Re-start the operation.
(4) If the machine can’t be reset even after this check work, contact our service personnel be-
cause the sensor cable or sensor may be defective.
61 03 01 COMPONENT RECOGNITION
DATA
UNAVAILABLE RECOGNITION IN DESIGNATED
CAMERA.
UNAVAILABLE RECOGNITION IN CAMERA WITH
MACHINE.
(Cause 1) There is no appropriate camera visual field available to cameras A1, A2, B1 and B2.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Check error message on program change and correct data.
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can’t be re-started, contact our service personnel.
61 03 02 COMPONENT RECOGNITION
DATA
P.C.B. FROM EL-CONVEYOR WAS NOT RECEIVED.
0005-002 2-93 Tg0248-PM-ER
Error Code Display A Display B
3. Trouble Shooting after Error Display
62 02 01 L-CONVEYOR OVERTIME
P.C.B. FROM INP. MACHINE WAS NOT RECEIVED.
62 02 02 L-CONVEYOR OVERTIME P.C.B. TO OUTPUT MACHINE WAS NOT TRANS-
FERRED.
62 02 03 L-CONVEYOR OVERTIME
P.C.B. ON L-CONVEYOR WAS NOT ABLE TO MOVE
TO ITS OUTLET.
62 02 05 L-CONVEYOR OVERTIME P.C.B. FROM P-CONVEYOR WAS NOT RECEIVED.
(Cause 1) A P.C.B. may be caught on the conveyor.
(Cause 2) The conveyor width may be maladjusted.
(Cause 3) The P.C.B. size may be larger than the specified size.
(Cause 4) The time indicated by the conveyor timer may be incorrect.
(Cause 5) A P.C.B. may have been removed during the P.C.B. feeding.
(Reset Procedure in the case of Causes 1, 2, 3, 4 and 5)
Reset Procedure
(1) Remove the caught P.C.B.
(2) Re-start.
(3) If the device can’t be re-started, contact our sales personnel because the sensor cable or
sensor may be defective.
62 02 04 L-CONVEYOR OVERTIME
