0005-002 2-103 Tg0248-PM-ER
Error Code Display A Display B
3. Trouble Shooting after Error Display
62 09 10 R-CONVEYOR P.C.B. DETEC-
TION
P.C.B. XFR. FROM P-CNVR. WERE DISCONTINUED
BEFORE P.C.B. XFR. ACT. COMPLETED.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Check whether or not P.C.B. is hanging over on R-conveyor.
Check whether or not P.C.B. transfer error occurs at P-conveyor.
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can’t be re-started, contact our service personnel.
Error Code Display A Display B
0005-002 2-104 Tg0248-PM-ER
3. Trouble Shooting after Error Display
63 01 06 CONTROL BOARD INTERLOCK ERROR WAS DETECTED. PRESS THE
[SYS CLR] BUTTON.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
63 01 05 CONTROL BOARD INTERLOCK ERROR WAS DETECTED. PLEASE RE-
START.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
63 01 04 CONTROL BOARD FAILURE IN COMMUNICATION WITH TOUCH
SCREEN CONTROLLER.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
63 01 03 CONTROL BOARD LOW BATTERY VOLTAGE OF MEMORY BOARD WAS
DETECTED.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
63 01 01 CONTROL BOARD LOW BATTERY VOLTAGE OF CALENDAR IC ON CPU
1 BOARD WAS DETECTED.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
3. Trouble Shooting after Error Display
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
Note: Refer to “Section 4 Recognition Error Code”.
65 01 02 LIGHTING CONTROL BOARD
COMM. XXXXXXXX
MOTOR CONTROLLER STATUS: ALARM DETECTED.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
Note: Refer to “Section 4 Recognition Error Code”.
Error Code Display A Display B
0009-001 2-104-1 Tg0248-PM-ER
63 02 02 MOTOR CONTROL BOARD JUMPER SETTING FOR THE MOTOR CONTROL
BOARD (VPG-46#2) IS WRONG.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Check the jumper setting for the motor control board (VPG-46#2).
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can’t be re-started, contact our service personnel.
65 01 01 RECOG. COMMUNICATION
XXXXXXXX
OVERLOAD WAS DETECTED.
63 02 01 MOTOR CONTROL BOARD JUMPER SETTING FOR THE MOTOR CONTROL
BOARD (VPG-46#1) IS WRONG.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Check the jumper setting for the motor control board (VPG-46#1).
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can’t be re-started, contact our service personnel.
