0103-003 2-115 Tg0248-PM-ER
Error Code Display A Display B
3. Trouble Shooting after Error Display
(Cause 1) This is the device's self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press [SYS CLR] button.
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can't be re-started, contact our service personnel.
6C 04 01 INTERNAL DATA ERROR INTERNAL DATA UNUSUALLY OCCURRED.
6C 04 02 INTERNAL DATA ERROR THERE WAS A FAILURE INCLUDING READING OF
TEXT DATA.
(Cause 1) There is a possibility that text data are not installed or damaged.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Re-install CPU1 program.
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can't be re-started, contact our service personnel.
6C 03 02 NO CONTINUOS STARTING
DISABLES CONTINUOUS STARTING OF PLACEMENT OPERATION
FROM THE MIDDLE STEPS.(ENABLE SEMI-AUTOMATIC OPERATION)
(Cause 1) This is the device's self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Check other error message with the message.
(2) Press the [SYS CLR] button after the cause of an error is removed.
(3) Re-start the placement operation from the middle step by Semi-Automatic Operation.
0005-002 2-116 Tg0248-PM-ER
Error Code Display A Display B
3. Trouble Shooting after Error Display
6D 01 04 JIG COMPONENT JIG COMPONENT NOT PLACED ON BACKLIGHT
PLATE.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
6D 01 03 JIG COMPONENT JIG COMPONENT NOT PICKED UP FROM BACK-
LIGHT PLATE.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
6D 01 02 JIG COMPONENT JIG COMPONENT NOT RE-STORED IN STOCKER.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
6D 01 01 JIG COMPONENT JIG COMPONENT NOT PICKED UP FROM STOCKER.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
0005-002 2-117 Tg0248-PM-ER
Error Code Display A Display B
3. Trouble Shooting after Error Display
6D 04 01 TEACH COMP. CAMR. MAG.
XXXXXXXX
JIG COMPONENT NOT RECOGNIZED.
6D 03 02 TEACH BEAM OFFSET
XXXXXXXX
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
6D 03 01 TEACH BEAM OFFSET
XXXXXXXX
CHECKER MARK NOT RECOGNIZED ON JIG P.C.B.
(Cause 1) The checkered mark may be dirty.
(Cause 2) The device lighting may be turned on.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
6D 02 01 TEACH P.E.C. CAMERA OFFSET
XXXXXXXX
ROUND MARK NOT RECOGNIZED ON JIG P.C.B.
(Cause 1) The jig P.C.B. may be dirty.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
Note: Refer to “Section 4 Recognition Error Codes”.
