Priority
No.
Item (Section A) Check Message (Section B) Check Code Remarks
BANK CARRIAGE CART-A IS NOT LOCATED AT THE
SPECIFIED POS. FOR CONNECTION.
MOVE THE CART TO THE SPECIFIED POSITION
THROUGH THE SETUP OPERATION.
030142XX
♦
BANK CARRIAGE CART-B IS NOT LOCATED AT THE
SPECIFIED POS. FOR CONNECTION.
MOVE THE CART TO THE SPECIFIED POSITION
THROUGH THE SETUP OPERATION.
030143XX
♦
BANK CARRIAGE CART-A IS NOT LOCATED AT THE
POS. WHERE IT CAN BE CONNECTED.
MOVE THE CART TO POS. WHERE CART CAN BE
CONNECTED THROUGH THE SETUP OPE.
030144XX
♦
BANK CARRIAGE CART-B IS NOT LOCATED AT THE
POS. WHERE IT CAN BE CONNECTED.
MOVE THE CART TO POS. WHERE CART CAN BE
CONNECTED THROUGH THE SETUP OPE.
030145XX
♦
REMOVE THE P.C.B. AT INLET OF CONVEYOR.
030146XX
♦
PLEASE INPUT BARCODE DATA IN MANUAL INPUT
SCREEN.
030147XX
♦
CANCEL BYPASS OPERATION OF SELECTED HEAD OR
DO NOT USE THE HEAD.
030201XX
HEAD BYPASS
THE SPECIFIED HEAD IS BYPASSED.
030202XX
BEAM ABNORMAL
APPROACH
BEAM APPROACH DETECTION SENSOR IS DETECTED.
PRESS THE [SYS CLR] BUTTON.
030301XX
030401XXALTERNATED TRAY L
MAGAZINE
BOTH UPPER AND LOWER MAGAZINES CANNOT BE
STARTED BECAUSE BOTH ARE CONNECTED.
02
ALTERNATED TRAY R
MAGAZINE
BOTH UPPER AND LOWER MAGAZINES CANNOT BE
STARTED BECAUSE BOTH ARE CONNECTED.
000501XX
NO CURRENT
SELECT THE CURRENT PROGRAM.
050101XX
SET UP CONVEYOR WIDTH (PWC-AXIS).
050201XX
SETUP CHECK
SET UP P.C.B. LOCATE LEVER (PPC-AXIS).
050202XX
♦
REMOVE FEEDER OF FEEDER BASE #1 CONNECTOR #11.
050301XX
REMOVE FEEDER OF FEEDER BASE #1 CONNECTOR #12.
050302XX
REMOVE FEEDER OF FEEDER BASE #1 CONNECTOR #13.
050303XX
REMOVE FEEDER OF FEEDER BASE #1 CONNECTOR #14.
050304XX
REMOVE FEEDER OF FEEDER BASE #1 CONNECTOR #15.
050305XX
REMOVE FEEDER OF FEEDER BASE #1 CONNECTOR #16.
050306XX
SET UP STICK FEEDER OF FEEDER BASE #1
CONNECTOR #11.
050307XX
SET UP STICK FEEDER OF FEEDER BASE #1
CONNECTOR #12.
050308XX
SET UP STICK FEEDER OF FEEDER BASE #1
CONNECTOR #13.
050309XX
SET UP STICK FEEDER OF FEEDER BASE #1
CONNECTOR #14.
050310XX
SET UP STICK FEEDER OF FEEDER BASE #1
CONNECTOR #15.
050311XX
SET UP STICK FEEDER OF FEEDER BASE #1
CONNECTOR #16.
050312XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #1
CONNECTOR #11.
050313XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #1
CONNECTOR #12.
050314XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #1
CONNECTOR #13.
050315XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #1
CONNECTOR #14.
050316XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #1
CONNECTOR #15.
050317XX
03
FEEDER CHECK 1
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #1
CONNECTOR #16.
050318XX
3. List of Check Messages
0005-002 3-6 Tg0248-PM-ER
Priorit
y
No.
Item (Section A) Check Message (Section B) Check Code Remarks
REMOVE FEEDER OF FEEDER BASE #2 CONNECTOR #21.
050401XX
REMOVE FEEDER OF FEEDER BASE #2 CONNECTOR #22.
050402XX
REMOVE FEEDER OF FEEDER BASE #2 CONNECTOR #23.
050403XX
REMOVE FEEDER OF FEEDER BASE #2 CONNECTOR #24.
050404XX
REMOVE FEEDER OF FEEDER BASE #2 CONNECTOR #25.
050405XX
REMOVE FEEDER OF FEEDER BASE #2 CONNECTOR #26.
050406XX
SET UP STICK FEEDER OF FEEDER BASE #2 CONNEC-
TOR #21.
050407XX
SET UP STICK FEEDER OF FEEDER BASE #2 CONNEC-
TOR #22.
050408XX
SET UP STICK FEEDER OF FEEDER BASE #2 CONNEC-
TOR #23.
050409XX
SET UP STICK FEEDER OF FEEDER BASE #2 CONNEC-
TOR #24.
050410XX
SET UP STICK FEEDER OF FEEDER BASE #2 CONNEC-
TOR #25.
050411XX
SET UP STICK FEEDER OF FEEDER BASE #2 CONNEC-
TOR #26.
050412XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #2
CONNECTOR #21.
050413XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #2
CONNECTOR #22.
050414XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #2
CONNECTOR #23.
050415XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #2
CONNECTOR #24.
050416XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #2
CONNECTOR #25.
050417XX
FEEDER CHECK 2
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #2
CONNECTOR #26.
050418XX
REMOVE FEEDER OF FEEDER BASE #3 CONNECTOR #31.
050501XX
REMOVE FEEDER OF FEEDER BASE #3 CONNECTOR #32.
050502XX
REMOVE FEEDER OF FEEDER BASE #3 CONNECTOR #33.
050503XX
REMOVE FEEDER OF FEEDER BASE #3 CONNECTOR #34.
050504XX
REMOVE FEEDER OF FEEDER BASE #3 CONNECTOR #35.
050505XX
REMOVE FEEDER OF FEEDER BASE #3 CONNECTOR #36.
050506XX
SET UP STICK FEEDER OF FEEDER BASE #3 CONNECTOR #31.
050507XX
SET UP STICK FEEDER OF FEEDER BASE #3 CONNECTOR #32.
050508XX
SET UP STICK FEEDER OF FEEDER BASE #3 CONNECTOR #33.
050509XX
SET UP STICK FEEDER OF FEEDER BASE #3 CONNECTOR #34.
050510XX
SET UP STICK FEEDER OF FEEDER BASE #3 CONNECTOR #35.
050511XX
SET UP STICK FEEDER OF FEEDER BASE #3 CONNECTOR #36.
050512XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #3
CONNECTOR #31.
050513XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #3
CONNECTOR #32.
050514XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #3
CONNECTOR #33.
050515XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #3
CONNECTOR #34.
050516XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #3
CONNECTOR #35.
050517XX
03
FEEDER CHECK 3
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #3
CONNECTOR #36.
050518XX
REMOVE FEEDER OF FEEDER BASE #4 CONNECTOR #41.
050601XX
REMOVE FEEDER OF FEEDER BASE #4 CONNECTOR #42.
050602XX
REMOVE FEEDER OF FEEDER BASE #4 CONNECTOR #43.
050603XX
REMOVE FEEDER OF FEEDER BASE #4 CONNECTOR #44.
050604XX
REMOVE FEEDER OF FEEDER BASE #4 CONNECTOR #45.
050605XX
REMOVE FEEDER OF FEEDER BASE #4 CONNECTOR #46.
050606XX
SET UP STICK FEEDER OF FEEDER BASE #4 CONNEC-
TOR #41.
050607XX
FEEDER CHECK 4
SET UP STICK FEEDER OF FEEDER BASE #4 CONNEC-
TOR #42.
050608XX
3. List of Check Messages
0005-002 3-7 Tg0248-PM-ER
Priority
No.
Item (Section A) Check Message (Section B) Check Code Remarks
SET UP STICK FEEDER OF FEEDER BASE #4 CONNEC-
TOR #43.
050609XX
SET UP STICK FEEDER OF FEEDER BASE #4 CONNEC-
TOR #44.
050610XX
SET UP STICK FEEDER OF FEEDER BASE #4 CONNEC-
TOR #45.
050611XX
03
SET UP STICK FEEDER OF FEEDER BASE #4 CONNEC-
TOR #46.
050612XX
FEEDER CHECK 4
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #4
CONNECTOR #41.
050613XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #4
CONNECTOR #42.
050614XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #4
CONNECTOR #43.
050615XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #4
CONNECTOR #44.
050616XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #4
CONNECTOR #45.
050617XX
SET UP VIBRATORY STICK FEEDER OF FEEDER BASE #4
CONNECTOR #46.
050618XX
ZERO FEEDER
CHECK WHETHER OR NOT A FEEDER (ADHESIVE TAPE,
ETC.) HAS NOT COMPLETED ITS FEEDING OPERATION.
ALSO, CHECK THAT A FEEDER IS INSTALLED COR-
RECTLY.
AND ZERO FEEDER.
050701XX
Unconditional
only in “PAUSE”
Mode
COMPONENT
LIBRARY DATA
ERROR
DATA RELATIVE TO RECOGNITION UNUSUALLY
OCCURRED.
CHECK THE DATA.
050801XX
070101XX
REMOVE MAINTENANCE AREA SENSOR [A] (BACK
SIDE) SHADED.;BPH081,082
070201XX
MAINTENANCE AREA
SENSOR
REMOVE MAINTENANCE AREA SENSOR [B] (FRONT
SIDE) SHADED. :BPH083,084
070202XX
REMOVE FEEDER MIS-SET SENSOR [A1] SHADED.
;BPH053
070301XX
REMOVE FEEDER MIS-SET SENSOR [A2] SHADED.
;BPH054
070302XX
REMOVE FEEDER MIS-SET SENSOR [B1] SHADED.
;BPH055
070303XX
FEEDER MIS-SET
REMOVE FEEDER MIS-SET SENSOR [B2] SHADED.
;BPH055
070304XX
REMOVE NOZZLE MIS-SET SENSOR [A1] SHADED.
;F(A1)-BPH061
070401XX
REMOVE NOZZLE MIS-SET SENSOR [A2] SHADED.
;F(A2)-BPH061
070402XX
♦
NOZZLE MIS-SET
REMOVE NOZZLE MIS-SET SENSOR [B1] SHADED.
;F(B1)-BPH061
070403XX
UNAVAILABLE DATA
INPUT AVAILABLE FEEDER NO. IN CURRENT PRO-
GRAM.
070501XX
Reserved Data
COMPONENT REJECT CUP [A] BECAME FULL.
REMOVE COMPONENT FROM COMPONENT REJECT
CUP [A]. ;(CC(A)-BPH044)
070601XX
COMPONENT REJECT CUP [B] BECAME FULL.
REMOVE COMPONENT FROM COMPONENT REJECT
CUP [B]. ;(CC(B)-BPH044)
070602XX
COMPONENT REJECT CONVEYOR [A] BECAME FULL.
REMOVE COMPONENT FROM COMPONENT REJECT
CONVEYOR [A]. ;(CC(A)-BPH046)
070603XX
04
COMPONENT REJECT
COMPONENT REJECT CONVEYOR [B] BECAME FULL.
REMOVE COMPONENT FROM COMPONENT REJECT
CONVEYOR [B]. ;(CC(B)-BPH046)
070604XX
