3. Control-to-Control Communication Error Code and List of Error Messages
0005-002 4-16 Tg0248-PM-ER
Error Code Display A Display B
10363101 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD WIDTH TOLERANCE” EXCEEDS THE RANGE OF
SETTING.
10363102 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD-TO-LEAD TOLERANCE SET” EXCEEDS THE
RANGE OF SETTING.
10363103 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD-TO-LEAD TOLERANCE” EXCEEDS THE RANGE
OF SETTING.
10364001 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“CORNER DATA FORM” EXCEEDS THE RANGE OF
SETTING.
10364002 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“CORNER DATA SIZE” EXCEEDS THE RANGE OF
SETTING.
10364003 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“EDGE DATA FORM” EXCEEDS THE RANGE OF
SETTING.
10364004 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“EDGE DATA DETECT POS.” EXCEEDS THE RANGE
OF SETTING.
“ELECTRICAL CONTACT FORM” EXCEEDS THE
RANGE OF SETTING.
10364006 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“ELECTRICAL CONTACT DIRECTION” EXCEEDS THE
RANGE OF SETTING.
10364007 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“ELECTRICAL CONTACT WIDTH” EXCEEDS THE
RANGE OF SETTING.
10364008 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“ELECTRICAL CONTACT LENGTH” EXCEEDS THE
RANGE OF SETTING.
10364005 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
10364009 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“ELECTRICAL CONTACT POSITION” EXCEEDS THE
RANGE OF SETTING.
“ELECTRICAL CONTACT WIDTH TOLERANCE SET”
EXCEEDS THE RANGE OF SETTING.
10364101 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“ELECTRICAL CONTACT WIDTH TOLERANCE”
EXCEEDS THE RANGE OF SETTING.
10365000 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“PACKAGE TYPE” EXCEEDS THE RANGE OF SETTING.
10364100 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
10365001 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD FULL LENGTH” EXCEEDS THE RANGE OF
SETTING.
10365002 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD PITCH” EXCEEDS THE RANGE OF SETTING.
10365003 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“NUMBER OF LEADS” EXCEEDS THE RANGE OF
SETTING.
10365004 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“ADDITIONAL SET” EXCEEDS THE RANGE OF
SETTING.
“NUMBER OF MISSING LEADS” EXCEEDS THE RANGE
OF SETTING.
10365006 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“MISSING LEAD START” EXCEEDS THE RANGE OF
SETTING.
10365005 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
10363004 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD POSITION” EXCEEDS THE RANGE OF SETTING.
10363100 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD WIDTH TOLERANCE SET” EXCEEDS THE
RANGE OF SETTING.
3. Control-to-Control Communication Error Code and List of Error Messages
0005-002 4-17 Tg0248-PM-ER
Error Code Display A Display B
10365101 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD WIDTH TOLERANCE” EXCEEDS THE RANGE OF
SETTING.
10365102 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“OUTWARD LENGTH CHECK” EXCEEDS THE RANGE
OF SETTING.
10365103 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“OUTWARD LENGTH TOLERANCE” EXCEEDS THE
RANGE OF SETTING.
10365104 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD POSITION CHECK” EXCEEDS THE RANGE OF
SETTING.
10365105 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD POSITION TOLERANCE” EXCEEDS THE RANGE
OF SETTING.
10365106 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD DETECTED POSITION” EXCEEDS THE RANGE
OF SETTING.
10365107 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“WIDTH DETECTED AREA SELECTION” EXCEEDS THE
RANGE OF SETTING.
“WIDTH DETECTED AREA” EXCEEDS THE RANGE OF
SETTING.
10367000 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“BALL GRID TYPE” EXCEEDS THE RANGE OF
SETTING.
10367001 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“BALL IMAGE” EXCEEDS THE RANGE OF SETTING.
10367002 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“BALL DIAMETER” EXCEEDS THE RANGE OF
SETTING.
10365108 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
10367003 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“NUMBER OF BALL GROUPS” EXCEEDS THE RANGE
OF SETTING.
“BALL GROUP POSITION” EXCEEDS THE RANGE OF
SETTING.
10367005 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“BALL PITCH” EXCEEDS THE RANGE OF SETTING.
10367006 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“NUMBER OF BALLS” EXCEEDS THE RANGE OF
SETTING.
10367004 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
10367007 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“NUMBER OF MISSING BALL BLOCKS” EXCEEDS THE
RANGE OF SETTING.
10367008 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“MISSING BALL START” EXCEEDS THE RANGE OF
SETTING.
10367009 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“NUMBER OF MISSING BALLS” EXCEEDS THE RANGE
OF SETTING.
10367010 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“POLARITY DETERMINATION” EXCEEDS THE RANGE
OF SETTING.
“INSPECTION RANGE” EXCEEDS THE RANGE OF
SETTING.
10367012 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“INSPECTION RANGE IMAGE” EXCEEDS THE RANGE
OF SETTING.
10367011 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
(NEXT PAGE)
10365007 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD GROUP POSITION” EXCEEDS THE RANGE OF
SETTING.
“LEAD WIDTH CHECK” EXCEEDS THE RANGE OF
SETTING.
10365100 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
3. Control-to-Control Communication Error Code and List of Error Messages
0005-002 4-18 Tg0248-PM-ER
Error Code Display A Display B
10367100 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“BALL OFFSET CHECK” EXCEEDS THE RANGE OF
SETTING.
10367101 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“BALL OFFSET TOLERANCE” EXCEEDS THE RANGE
OF SETTING.
10368000 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“NUMBER OF LEAD GROUPS” EXCEEDS THE RANGE
OF SETTING.
10368001 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD TYPE NO.” EXCEEDS THE RANGE OF SETTING.
10368002 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“NUMBER OF LEAD TYPES” EXCEEDS THE RANGE OF
SETTING.
10368003 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“LEAD MODE” EXCEEDS THE RANGE OF SETTING.
10369000 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“NUMBER OF EDGES” EXCEEDS THE RANGE OF
SETTING.
“EDGE START POSITION” EXCEEDS THE RANGE OF
SETTING.
10369002 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“EDGE DIRECTION” EXCEEDS THE RANGE OF
SETTING.
10369003 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“EDGE WIDTH” EXCEEDS THE RANGE OF SETTING.
10369001 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
10400001 TEACHING THE CAMERA
MAGNIFICATION
“GRID PITCH” EXCEEDS THE RANGE OF SETTING.
10400000 TEACHING THE CAMERA
MAGNIFICATION
“CAMERA NO.” EXCEEDS THE RANGE OF SETTING.
10367013 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
“INSPECTION POSITION” EXCEEDS THE RANGE OF
SETTING.
“MISSING BALL DETECTION MODE” EXCEEDS THE
RANGE OF SETTING.
10367014 TRANSFERRING THE COM-
PONENT RECOGNITION DATA
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
