5. Component Recognition Error Code and List of Error Messages
0103-003 4-38 Tg0248-PM-ER
Error Code Display A Display B
2022A210 ELECTRICAL CONTACT
to 219 PITCH
Note: A represents “2” or “3”.
PITCH OF ELCTC.1 AND ELCTC.3 EXCEEDS THE TOL-
ERANCE.
(Cause 1) Is the electrical contact position data in the component library correct?
(It can be checked in the component recognition test).
(Cause 2) Is the Component Size Tolerance too small?
The Component Size Tolerance becomes valid only when the “Recognition Data” and
“Component Size Tolerance” are set manually.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Press the [ZERO] button to return all the axes to their original positions.
(2) Re-start.
(3) If the device can’t be re-started, contact our service personnel.
2022A110 ELECTRICAL CONTACT
to 119 PITCH
Note: A represents “2” or “3”.
PITCH OF ELCTC.1 AND ELCTC.2 EXCEEDS THE TOL-
ERANCE.
5. Component Recognition Error Code and List of Error Messages
0103-001 4-38-1 Tg0248-PM-ER
Error Code Display A Display B
20233110 ELECTRICAL CONTACT ARRAY
to 119 DIRECTION BEND ERROR
ELCTC. ARRAY DIR.BEND OF ELCTC.1 (UPPER) EX-
CEEDS THE TOLERANCE.
20233120 ELECTRICAL CONTACT ARRAY
to 129 DIRECTION BEND ERROR
ELCTC. ARRAY DIR.BEND OF ELCTC.2 (UPPER) EX-
CEEDS THE TOLERANCE.
20233210 ELECTRICAL CONTACT ARRAY
to 219 DIRECTION BEND ERROR
ELCTC. ARRAY DIR.BEND OF ELCTC.1 (LEFT) EX-
CEEDS THE TOLERANCE.
20233220 ELECTRICAL CONTACT ARRAY
to 229 DIRECTION BEND ERROR
ELCTC. ARRAY DIR.BEND OF ELCTC.2 (LEFT) EX-
CEEDS THE TOLERANCE.
20233230 ELECTRICAL CONTACT ARRAY
to 239 DIRECTION BEND ERROR
ELCTC. ARRAY DIR.BEND OF ELCTC.3 (LEFT) EX-
CEEDS THE TOLERANCE.
20233130 ELECTRICAL CONTACT ARRAY
to 139 DIRECTION BEND ERROR
ELCTC. ARRAY DIR.BEND OF ELCTC.3 (UPPER) EX-
CEEDS THE TOLERANCE.
20233320 ELECTRICAL CONTACT ARRAY
to 329 DIRECTION BEND ERROR
ELCTC. ARRAY DIR.BEND OF ELCTC.2 (LOWER) EX-
CEEDS THE TOLERANCE.
20233310 ELECTRICAL CONTACT ARRAY
to 319 DIRECTION BEND ERROR
ELCTC. ARRAY DIR.BEND OF ELCTC.1 (LOWER) EX-
CEEDS THE TOLERANCE.
20233330 ELECTRICAL CONTACT ARRAY
to 339 DIRECTION BEND ERROR
ELCTC. ARRAY DIR.BEND OF ELCTC.3 (LOWER) EX-
CEEDS THE TOLERANCE.
20233410 ELECTRICAL CONTACT ARRAY
to 419 DIRECTION BEND ERROR
ELCTC. ARRAY DIR.BEND OF ELCTC.1 (RIGHT) EX-
CEEDS THE TOLERANCE.
20233420 ELECTRICAL CONTACT ARRAY
to 429 DIRECTION BEND ERROR
ELCTC. ARRAY DIR.BEND OF ELCTC.2 (RIGHT) EX-
CEEDS THE TOLERANCE.
20233430 ELECTRICAL CONTACT ARRAY
to 439 DIRECTION BEND ERROR
ELCTC. ARRAY DIR.BEND OF ELCTC.3 (RIGHT) EX-
CEEDS THE TOLERANCE.
(Cause 1) Is the electrical contact position X or Y correct?
(Cause 2) Is the electrical contact bent?
(Cause 3) Is the component size tolerance too small?
(Reset Procedure in the case of Causes 1, 2 and 3)
Reset Procedure
(1) Press the [ZERO] button to return all the axes to their original positions.
(2) Re-start.
(3) If the device can’t be re-started, contact our service personnel.
5. Component Recognition Error Code and List of Error Messages
0103-003 4-39 Tg0248-PM-ER
Error Code Display A Display B
2025A110 ELECTRICAL CONTACT
to 119 LENGTH ERROR
Note: A represents “2” or “3”.
LENGTH OF ELECTRICAL CONTACT 1 (UPPER) EX-
CEEDS THE TOLERANCE.
2025A120 ELECTRICAL CONTACT
to 129 LENGTH ERROR
Note: A represents “2” or “3”.
LENGTH OF ELECTRICAL CONTACT 2 (UPPER) EX-
CEEDS THE TOLERANCE.
2025A210 ELECTRICAL CONTACT
to 219 LENGTH ERROR
Note: A represents “2” or “3”.
LENGTH OF ELECTRICAL CONTACT 1 (LEFT) EX-
CEEDS THE TOLERANCE.
2025A220 ELECTRICAL CONTACT
to 229 LENGTH ERROR
Note: A represents “2” or “3”.
LENGTH OF ELECTRICAL CONTACT 2 (LEFT) EX-
CEEDS THE TOLERANCE.
2025A130 ELECTRICAL CONTACT
to 139 LENGTH ERROR
Note: A represents “2” or “3”.
LENGTH OF ELECTRICAL CONTACT 3 (UPPER) EX-
CEEDS THE TOLERANCE.
2025A230 ELECTRICAL CONTACT
to 239 LENGTH ERROR
Note: A represents “2” or “3”.
LENGTH OF ELECTRICAL CONTACT 3 (LEFT) EX-
CEEDS THE TOLERANCE.
2025A310 ELECTRICAL CONTACT
to 319 LENGTH ERROR
Note: A represents “2” or “3”.
LENGTH OF ELECTRICAL CONTACT 1 (LOWER) EX-
CEEDS THE TOLERANCE.
2025A320 ELECTRICAL CONTACT
to 329 LENGTH ERROR
Note: A represents “2” or “3”.
LENGTH OF ELECTRICAL CONTACT 2 (LOWER) EX-
CEEDS THE TOLERANCE.
2025A330 ELECTRICAL CONTACT
to 339 LENGTH ERROR
Note: A represents “2” or “3”.
LENGTH OF ELECTRICAL CONTACT 3 (LOWER) EX-
CEEDS THE TOLERANCE.
2025A420 ELECTRICAL CONTACT
to 429 LENGTH ERROR
Note: A represents “2” or “3”.
LENGTH OF ELECTRICAL CONTACT 2 (RIGHT) EX-
CEEDS THE TOLERANCE.
2025A430 ELECTRICAL CONTACT
to 439 LENGTH ERROR
Note: A represents “2” or “3”.
LENGTH OF ELECTRICAL CONTACT 3 (RIGHT) EX-
CEEDS THE TOLERANCE.
2025A410 ELECTRICAL CONTACT
to 419 LENGTH ERROR
Note: A represents “2” or “3”.
LENGTH OF ELECTRICAL CONTACT 1 (RIGHT) EX-
CEEDS THE TOLERANCE.
(Cause 1) Is the electrical contact length correct?
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [ZERO] button to return all the axes to their original positions.
(2) Re-start.
(3) If the device can’t be re-started, contact our service personnel.
