5. Component Recognition Error Code and List of Error Messages
Error Code Display A Display B
2040A140 ELECTRICAL CONTACT (UP-
to 149 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
CORNER (UPPER-RIGHT) OF ELECTRICAL CON-
TACT 1 IS UNABLE RECOGNITION.
2040A150 ELECTRICAL CONTACT (UP-
to 159 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
INTERNAL ERROR OCCURRED DURING EDGE
RECOGNITION OF ELECTRICAL CONTACT 1.
2040A010 ELECTRICAL CONTACT (UP-
to 049 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
NOZZLE PROTRUSION PRESENTS ON SOME ELEC-
TRICAL CONTACTS.
EDGE (LOWER-RIGHT) OF ELECTRICAL CONTACT 1
IS UNABLE RECOGNITION.
EDGE (UPPER-LEFT) OF ELECTRICAL CONTACT 1 IS
UNABLE RECOGNITION.
2040A190 ELECTRICAL CONTACT (UP-
to 199 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
EDGE (UPPER-RIGHT) OF ELECTRICAL CONTACT 1
IS UNABLE RECOGNITION.
2040A200 ELECTRICAL CONTACT (UP-
to 209 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
INTERNAL ERROR OCCURRED DURING CORNER
RECOGNITION OF ELECTRICAL CONTACT 2.
2040A220 ELECTRICAL CONTACT (UP-
to 229 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
CORNER (LOWER-LEFT) OF ELECTRICAL CONTACT
2 IS UNABLE RECOGNITION.
2040A230 ELECTRICAL CONTACT (UP-
to 239 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
CORNER (LOWER-RIGHT) OF ELECTRICAL CON-
TACT 2 IS UNABLE RECOGNITION.
2040A210 ELECTRICAL CONTACT (UP-
to 219 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
CORNER (UPPER-LEFT) OF ELECTRICAL CONTACT
2 IS UNABLE RECOGNITION.
(NEXT PAGE)
2040A240 ELECTRICAL CONTACT (UP-
to 249 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
CORNER (UPPER-RIGHT) OF ELECTRICAL CON-
TACT 2 IS UNABLE RECOGNITION.
2040A100 ELECTRICAL CONTACT (UP-
to 109 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
INTERNAL ERROR OCCURRED DURING CORNER
RECOGNITION OF ELECTRICAL CONTACT 1.
2040A110 ELECTRICAL CONTACT (UP-
to 119 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
CORNER (UPPER-LEFT) OF ELECTRICAL CONTACT
1 IS UNABLE RECOGNITION.
2040A120 ELECTRICAL CONTACT (UP-
to 129 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
CORNER (LOWER-LEFT) OF ELECTRICAL CONTACT
1 IS UNABLE RECOGNITION.
2040A130 ELECTRICAL CONTACT (UP-
to 139 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
CORNER (LOWER-RIGHT) OF ELECTRICAL CON-
TACT 1 IS UNABLE RECOGNITION.
2040A170 ELECTRICAL CONTACT (UP-
to 179 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
2040A180 ELECTRICAL CONTACT (UP-
to 189 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
2040A160 ELECTRICAL CONTACT (UP-
to 169 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
2040A250 ELECTRICAL CONTACT (UP-
to 259 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
INTERNAL ERROR OCCURRED DURING EDGE
RECOGNITION OF ELECTRICAL CONTACT 2.
EDGE (LOWER-LEFT) OF ELECTRICAL CONTACT 1
IS UNABLE RECOGNITION.
Error Code Display A Display B
5. Component Recognition Error Code and List of Error Messages
2040A300 ELECTRICAL CONTACT (UP-
to 309 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
INTERNAL ERROR OCCURRED DURING CORNER
RECOGNITION OF ELECTRICAL CONTACT 3.
2040A310 ELECTRICAL CONTACT (UP-
to 319 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
CORNER (UPPER-LEFT) OF ELECTRICAL CONTACT
3 IS UNABLE RECOGNITION.
2040A260 ELECTRICAL CONTACT (UP-
to 269 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
EDGE (UPPER-LEFT) OF ELECTRICAL CONTACT 2 IS
UNABLE RECOGNITION.
2040A270 ELECTRICAL CONTACT (UP-
to 279 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
EDGE (LOWER-LEFT) OF ELECTRICAL CONTACT 2
IS UNABLE RECOGNITION.
2040A280 ELECTRICAL CONTACT (UP-
to 289 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
EDGE (LOWER-RIGHT) OF ELECTRICAL CONTACT 2
IS UNABLE RECOGNITION.
2040A290 ELECTRICAL CONTACT (UP-
to 299 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
EDGE (UPPER-RIGHT) OF ELECTRICAL CONTACT 2
IS UNABLE RECOGNITION.
Note: The second digit from the last one of the error code represents Electrical Contact 1, 2, or 3.
The third digit from the last one of the error code represents Electrical Contact Position 0,
1, 2, or 3.
0: Upper Side 1: Left Side 2: Lower Side 3: Right Side
(Cause 1) Wrong parameters (electrical contact data) are set in the component library data for the
selected component.
(Cause 2) Is there any inconsistent reflection at the electric corner or edge?
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Check the selected component and the electrical contact data in the component library data.
(2) If wrong parameters are set in the component library data, correct them.
(Reset Procedure in the case of Cause 2)
Reset Procedure
(1) In this case, change the lighting mode to “MANUAL (FRONT LIGHTING)” and perform the
recognition with much brighter light.
Error Code Display A Display B
2040A330 ELECTRICAL CONTACT (UP-
to 339 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
CORNER (LOWER-RIGHT) OF ELECTRICAL CON-
TACT 3 IS UNABLE RECOGNITION.
2040A340 ELECTRICAL CONTACT (UP-
to 349 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
CORNER (UPPER-RIGHT) OF ELECTRICAL CON-
TACT 3 IS UNABLE RECOGNITION.
2040A320 ELECTRICAL CONTACT (UP-
to 329 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
CORNER (LOWER-LEFT) OF ELECTRICAL CONTACT
3 IS UNABLE RECOGNITION.
2040A350 ELECTRICAL CONTACT (UP-
to 359 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
INTERNAL ERROR OCCURRED DURING EDGE
RECOGNITION OF ELECTRICAL CONTACT 3.
2040A360 ELECTRICAL CONTACT (UP-
to 369 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
EDGE (UPPER-LEFT) OF ELECTRICAL CONTACT 3 IS
UNABLE RECOGNITION.
2040A380 ELECTRICAL CONTACT (UP-
to 389 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
EDGE (LOWER-RIGHT) OF ELECTRICAL CONTACT 3
IS UNABLE RECOGNITION.
2040A390 ELECTRICAL CONTACT (UP-
to 399 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
EDGE (UPPER-RIGHT) OF ELECTRICAL CONTACT 3
IS UNABLE RECOGNITION.
2040A370 ELECTRICAL CONTACT (UP-
to 379 PER) RECOGNITION ERROR
Note:A represents “2” or “3”.
EDGE (LOWER-LEFT) OF ELECTRICAL CONTACT 3
IS UNABLE RECOGNITION.
5. Component Recognition Error Code and List of Error Messages
Note: The second digit from the last one of the error code represents Electrical Contact 1, 2, or 3.
The third digit from the last one of the error code represents Electrical Contact Position 0,
1, 2, or 3.
0: Upper Side 1: Left Side 2: Lower Side 3: Right Side
(Cause 1) Wrong parameters (electrical contact data) are set in the component library data for the
selected component.
(Cause 2) Is there any inconsistent reflection at the electrical contact corner or edge?
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Check the selected component and the electrical contact data in the component library data.
(2) If wrong parameters are set in the component library data, correct them.
(Reset Procedure in the case of Cause 2)
Reset Procedure
(1) In this case, change the lighting mode to “MANUAL (FRONT LIGHTING)” and perform the
recognition with much brighter light.
