06 01 05 LA2-AXIS ORIGIN ORIGIN IS NOT SET FOR THIS AXIS. ZEROING IS REQUIRED. Error Code Display A Display B 06 01 1 1 LA2-AXIS ORIGIN (Cause 1) It may run away due to noise or overcurrent. (Cause 2) The sensor may be d…

100%1 / 308
06 01 04 LA2-AXIS ORIGIN ENCODER ORIGIN WAS DETECTED AT POINT OUT
OF ORIGIN (SLIDE).
(Cause 1) Is the original position deviated?
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Re-adjust the original position.
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can’t be re-started, contact our service personnel.
06 01 01 LA2-AXIS ORIGIN ENCODER ORIGIN WAS NOT DETECTED.
06 01 02 LA2-AXIS ORIGIN ORIGIN (SLIDE) WAS NOT DETECTED.
;C(A2)-BPH121 E / R
Error Code Display A Display B
(Cause 1) Motor encoder section may be defective.
(Cause 2) Encoder cable may be broken.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Turn off the power and check for loose connections between the sections of the motor and
signal cable.
(2) Re-start.
(3) If the device can’t be reset even after the above check, contact our service personnel because
the signal cable may be broken or the motor defective.
(Cause 1) The sensor may be defective.
(Cause 2) The cable may be broken.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Press the [RESET] button to cancel the error.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel because a sensor or sensor
cable replacement might be required.
3. Trouble Shooting after Error Display
0005-002 2-37 Tg0248-PM-ER
06 01 03 LA2-AXIS ORIGIN ORIGIN (SLIDE) AND/OR LIMIT SENSOR (−) MIGHT
BE DEFECTIVE.
(Cause 1) It may run away due to noise or overcurrent
(Cause 2) The sensor may be defective.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
06 01 05 LA2-AXIS ORIGIN ORIGIN IS NOT SET FOR THIS AXIS.
ZEROING IS REQUIRED.
Error Code Display A Display B
06 01 11 LA2-AXIS ORIGIN
(Cause 1) It may run away due to noise or overcurrent.
(Cause 2) The sensor may be defective.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
0005-002 2-38 Tg0248-PM-ER
3. Trouble Shooting after Error Display
06 01 06 LA2-AXIS ORIGIN THE AXIS WAS NOT AT ORIGIN.
06 01 10 LA2-AXIS ORIGIN ZEROING NOT COMPLETED WITHIN SPECIFIED
TIME.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’tbe re-started, contact our service personnel.
LIMIT SENSOR (+)/(−) MIGHT BE DEFECTIVE.
06 03 01 LA2-AXIS DATA TARGET LOCATION VALUE IS OUT OF RANGE.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
06 05 02 LA2-AXIS SERVOMOTOR
DRIVER
OVERCURRENT WAS DETECTED.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
Error Code Display A Display B
0005-002 2-39 Tg0248-PM-ER
3. Trouble Shooting after Error Display
06 04 01 LA2-AXIS LIMIT LIMIT ERROR (+) IS DETECTED.;C(A2)-BPH122 E/NR
06 04 02 LA2-AXIS LIMIT LIMIT ERROR (−) IS DETECTED.;C(A2)-BPH123 E/NR
(Cause 1) It may run away due to noise or overcurrent.
(Cause 2) The sensor may be defective.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
06 05 01 LA2-AXIS SERVOMOTOR
DRIVER
ABNORMAL DATA SETTING WAS DETECTED.
(Cause 1) Overcurrent or overload may occur in the servo pack or the motor signal cable connec-
tion may be defective.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Check for overload.
• Turn off the power and move the XY beam manually.
If it is very heavy or will not move, it is overloaded.
Check if any component has dropped in the ball screw or linear guide and contact our
service personnel.
• Check the connections between the section of the motor and signal cable.
Turn off the power and check for loose connector by hand.
If there is any, contact our service personnel.
