Error Code Display A Display B
0005-002 2-43 Tg0248-PM-ER
3. Trouble Shooting after Error Display
(Cause 1) Is there any dust etc. on the LA2-axis level detection (1) sensor (BPH124) (E / NR
condition) which monitors that the head up / down-axis (LA2) is lifted to the specified
height when the beam A is moved using the lower path line?
If so, completely remove it.
(Cause 2) Is there a large plus figure input in the beam A head 1 up / down column at the “DE-
VICE OFFSET” display?
If it has changed or corrected, correct adjustment is required.
(Cause 3) Is the installation of the LA2-axis level detection (1) sensor (BPH124) loosened or
deviated?
(Reset Procedure in the case of Causes 1, 2, and 3)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
06 06 02 LA2-AXIS INTERLOCK P.C.B. TRANSFER LEVEL VIOLATION WAS DE-
TECTED ON BEAM A.;M(A2)-BPH124 E / NR
(Cause 1) Is there any dust etc. on the LA2-axis level detection (1) sensor (BPH125) (E / NR
condition) which monitors that the head up / down-axis (LA2) is lifted to the specified
height when the beam A is moved using the lower path line?
If so, completely remove it.
(Cause 2) Is there a large plus figure input in the beam A head 1 up / down column at the “DE-
VICE OFFSET” display?
If it has changed or corrected, correct adjustment is required.
(Cause 3) Is the installation of the LA2-axis level detection (1) sensor (BPH125) loosened or
deviated?
(Reset Procedure in the case of Causes 1, 2, and 3)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
06 06 03 LA2-AXIS INTERLOCK P.C.B. TRANSFER LEVEL VIOLATION WAS DE-
TECTED ON BEAM A.;M(A2)-BPH125 E / NR
Error Code Display A Display B
0005-002 2-44 Tg0248-PM-ER
3. Trouble Shooting after Error Display
(Cause 1) Is there any dust etc. on the LA2-axis level detection (1) sensor (BPH126) (E / NR
condition) which monitors that the head up / down-axis (LA2) is lifted to the specified
height when the beam A is moved using the lower path line?
If so, completely remove it.
(Cause 2) Is there a large plus figure input in the beam A head 1 up / down column at the “DE-
VICE OFFSET” display?
If it has changed or corrected, correct adjustment is required.
(Cause 3) Is the installation of the LA2-axis level detection (1) sensor (BPH126) loosened or
deviated?
(Reset Procedure in the case of Causes 1, 2, and 3)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
06 06 04 LA2-AXIS INTERLOCK P.C.B. TRANSFER LEVEL VIOLATION WAS DE-
TECTED ON BEAM A.;M(A2)-BPH126 E / NR
06 06 05 LA2-AXIS INTERLOCK P.C.B. TRANSFER LEVEL VIOLATION WAS DE-
TECTED ON BEAM A.;M(A2)-BPH127 E / NR
(Cause 1) Is there any dust etc. on the LA2-axis level detection (1) sensor (BPH127) (E / NR
condition) which monitors that the head up/down-axis (LA2) is lifted to the specified
height when the beam A is moved using the lower path line?
If so, completely remove it.
(Cause 2) Is there a large plus figure input in the beam A head 1 up / down column at the “DE-
VICE OFFSET” display?
If it has changed or corrected, correct adjustment is required.
(Cause 3) Is the installation of the LA2-axis level detection (1) sensor (BPH127) loosened or
deviated?
(Reset Procedure in the case of Causes 1, 2, and 3)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
07 01 01 LB1-AXIS ORIGIN ENCODER ORIGIN WAS NOT DETECTED.
Error Code Display A Display B
(Cause 1) Motor encoder section may be defective.
(Cause 2) Encoder cable may be broken.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Turn off the power and check for loose connections between the sections of the motor and
signal cable.
(2) Re-start.
(3) If the device can’t be reset even after the above check, contact our service personnel because
the signal cable may be broken or the motor defective.
3. Trouble Shooting after Error Display
0005-002 2-45 Tg0248-PM-ER
07 01 02 LB1-AXIS ORIGIN ORIGIN (SLIDE) WAS NOT DETECTED.
;C(B1)-BPH121 E / R
(Cause 1) The sensor may be defective.
(Cause 2) The cable may be broken.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Press the [RESET] button to cancel the error.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel because a sensor or sensor
cable replacement might be required.
07 01 03 LB1-AXIS ORIGIN ORIGIN SENSOR (SLIDE) AND / OR LIMIT SENSOR
(−) MIGHT BE DEFECTIVE.
(Cause 1) It may run away due to noise or overcurrent
(Cause 2) The sensor may be defective.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
(Cause 1) Is the original position deviated?
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Re-adjust the original position.
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can’t be re-started, contact our service personnel.
07 01 04 LB1-AXIS ORIGIN ENCODER ORIGIN WAS DETECTED AT POINT OUT
OF ORIGIN (SLIDE).
