Error Code Display A Display B
0005-002 2-50 Tg0248-PM-ER
3. Trouble Shooting after Error Display
(Cause 1) Is there any dust etc. on the LB1-axis level detection (1) sensor (BPH125) (E / NR
condition) which monitors that the head up/down-axis (LB1) is lifted to the specified
height when the beam B is moved using the lower path line?
If so, completely remove it.
(Cause 2) Is there a large plus figure input in the beam B head 1 up / down column at the “DE-
VICE OFFSET” display?
If it has changed or corrected, correct adjustment is required.
(Cause 3) Is the installation of the LB1-axis level detection (1) sensor (BPH125) loosened or
deviated?
(Reset Procedure in the case of Causes 1, 2, and 3)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
07 06 03 LB1-AXIS INTERLOCK P.C.B. TRANSFER LEVEL VIOLATION WAS DE-
TECTED ON BEAM B.;M(B1)-BPH125 E / NR
Error Code Display A Display B
0005-002 2-51 Tg0248-PM-ER
3. Trouble Shooting after Error Display
(Cause 1) Is there any dust etc. on the LB1-axis level detection (1) sensor (BPH126) (E / NR
condition) which monitors that the head up / down-axis (LB1) is lifted to the specified
height when the beam B is moved using the lower path line?
If so, completely remove it.
(Cause 2) Is there a large plus figure input in the beam B head 1 up / down column at the “DE-
VICE OFFSET” display?
If it has changed or corrected, correct adjustment is required.
(Cause 3) Is the installation of the LB1-axis level detection (1) sensor (BPH126) loosened or
deviated?
(Reset Procedure in the case of Causes 1, 2, and 3)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
07 06 04 LB1-AXIS INTERLOCK P.C.B. TRANSFER LEVEL VIOLATION WAS DE-
TECTED ON BEAM B.;M(B1)-BPH126 E / NR
(Cause 1) Is there any dust etc. on the LB1-axis level detection (1) sensor (BPH127) (E / NR
condition) which monitors that the head up / down-axis (LB1) is lifted to the specified
height when the beam B is moved using the lower path line?
If so, completely remove it.
(Cause 2) Is there a large plus figure input in the beam B head 1 up / down column at the “DE-
VICE OFFSET” display?
If it has changed or corrected, correct adjustment is required.
(Cause 3) Is the installation of the LB1-axis level detection (1) sensor (BPH127) loosened or
deviated?
(Reset Procedure in the case of Causes 1, 2, and 3)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
07 06 05 LB1-AXIS INTERLOCK P.C.B. TRANSFER LEVEL VIOLATION WAS DE-
TECTED ON BEAM B.;M(B1)-BPH127 E / NR
(Cause 1) Is the original position deviated?
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Re-adjust the original position.
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can’t be re-started, contact our service personnel.
Error Code Display A Display B
3. Trouble Shooting after Error Display
0005-002 2-52 Tg0248-PM-ER
08 01 04 LB2-AXIS ORIGIN ENCODER ORIGIN WAS DETECTED AT POINT OUT
OF ORIGIN (SLIDE).
08 01 02 LB2-AXIS ORIGIN ORIGIN (SLIDE) WAS NOT DETECTED.
;C(B2)-BPH121 E / R
(Cause 1) The sensor may be defective.
(Cause 2) The cable may be broken.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Press the [RESET] button to cancel the error.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel because a sensor or sensor
cable replacement might be required.
08 01 01 LB2-AXIS ORIGIN ENCODER ORIGIN WAS NOT DETECTED.
(Cause 1) Motor encoder section may be defective.
(Cause 2) Encoder cable may be broken.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Turn off the power and check for loose connections between the sections of the motor and
signal cable.
(2) Re-start.
(3) If the device can’t be reset even after the above check, contact our service personnel because
the signal cable may be broken or the motor defective.
08 01 03 LB2-AXIS ORIGIN ORIGIN SENSOR (SLIDE) AND / OR LIMIT SENSOR
(−) MIGHT BE DEFECTIVE.
(Cause 1) It may run away due to noise or overcurrent
(Cause 2) The sensor may be defective.
(Reset Procedure in the case of Causes 1 and 2)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
