■ PROBE SYST EM FOR FPD FPD Manual  Prober  for  Flat ‐ Panel  Display We  custom ‐ make  manual  probers  that  support  FPDs (flat ‐ panel  display)  ranging  from  small  to  large  glass  substrates…

HiSOLSemi‐Automatic Prober ControlSoftware

Manualoperation

BINmapping

WaferMapsetting

Seals feature

Supportedautomaticmeasurementsoftware

KEYSIGHTtechnologies

‐EasyEXPERT

‐DesktopEasyEXPERT

‐WaferProExpress

TFF/KEITHLEYinstruments

‐4200‐SCS KITE(KeithleyInteractiveTestEnvironment)

‐ACS

Proplus designsolution ‐Noisepro

OtherGP‐IBcommunication‐enabledsoftware

‐ User‐friendlymultifunctionalsemi‐automaticprobingsoftware.

‐ SupportsWindows8asitsoperatingsystem.(Windows7isalsosupported.)

‐ AlsoavailableasamanualproberwithasoftwareGUIorjoystickcontroller.

‐ ReceivingBINinformationfromahigher‐levelmeasuringinstrument,itispossibletodisplayBINmapping.

‐ Supportswafer

thermalexpansioncompensationfunctionforThermaltest.

‐ Possibletocontrolthesemi‐automaticproberusingtheGP‐IBcommandsentfromahigher‐levelmeasuring

instrument or PC.

‐ Possibletoprovidesoftwareformakingadatabaseofandextractingparametersofrawdataobtainedfromeach

measuring instrumentinordertoanalyzethedata.

(Optional)

‐ Theself‐developedsoftwareallowsuserstoincorporatecustomizedrequirements.

■ SEMI-AUTOMATIC PROBER

Semi‐AutomaticProber

■ PROBE SYSTEM FOR FPD

FPD

ManualProberforFlat‐PanelDisplay

Wecustom‐makemanualprobersthatsupportFPDs (flat‐paneldisplay)rangingfromsmalltolargeglasssubstrates.

Amicroscopeandprobingareawithawiderangeofmotionallowstableprobingacrossthepanelsurface.

Aheatingtype(upto+200°C)orthermaltype(‐40°Cto+200°C)can

beselectedfortherectanglepanelchuckand

ultralowcurrentmeasurementsonthefAlevelandC‐VmeasurementsonthesubpFlevelaresupportedforalltemperature

zones.

Thisproberalsosupportslightirradiationonthepanelsurface bythesolarsimulatororotherdeviceandlightirradiationon

the

bottom sideofpanel(backlight)bysuper‐highluminancewhiteLED.

Lightirradiationonthebottom sideofpanel

byultrahighluminosityLED

(upto40,000cd/cm2) *Sub‐stage

Lightirradiationonthepanelsurfaceby

thesolarsimulatororotherdevice

Built‐inlasercutter

(laserwavelength:1064,532,355,266nm)

Ultrahigh‐accuracymodelforstable

probingof

submicronpatterns

Function examples of systems for small to medium-sized panels

Model HMP-FPD series

Widerangeprobingareathatenableslayout

of FPDdevices.

ProbeSystemforFPD

FPD

■ PROBE SYSTEM FOR FPD

Model HSP-FPD series

Semi‐Automatic ProberforFlat‐PanelDisplay

Function examples of systems for small to medium-sized panels

Commongatepadprobing(onsub‐platen)

‐ WiderangemicroscopeX‐Ytravel

‐ Widerangeprobingarea

‐ ProgrammableX‐Y‐Zpositioner(manipulator)

Wecustom‐makeSemi‐automatic probersthatsupportFPDs (flat‐paneldisplay)rangingfromsmalltolargeglasssubstrates.
