■ ACCESSORI ES Accessories Positioners (Manipul ators) HP80 Compact  positioner General ‐ purpose  po sitio ner  designed  for  low  cost. (  HP80/L ・ R ‐ M  ) Stable  contact  on  70 μ m  or  larger  PAD …

Model

HP50/R(righthandmodel)

HP50/L(lefthandmodel)

Travelrange(X,Y,Z)

5/5/5mm

Screwresolution (X,Y,Z) 0.5mm/rev.

Featureresolution

10μm

Mounting

On/Offswitchingmagnetbase(standard)

Dimensions

W36×D85×H56mm

Weight

approx.200grams

Positioners (Manipulators)

HP50 Compactpositioner

Compactleadscrewfeedpositioner.

Thespecialguidemechanismallowsforstablecontacton50μmorlargerPAD.

Correspondence

Probestation

‐ HMP‐400/600

‐ HMP‐800/1200

‐ HMP‐FPDseries

HP65 Compacthigh‐accuracypositioner

Compactmicrometerfeedtypehigh‐accuracypositioner.

Easilyaccesses10μmorlargercircuitpattern orPADwithoutbacklash.

Model

HP65

Travelrange(X,Y,Z)

6.5/6.5/6.5mm

Screwresolution (X,Y,Z) 0.5mm/rev.

Featureresolution

3μm

Mounting

On/Offswitchingmagnetbase(standard)

Dimensions

W38×D93×H68mm

Weight

approx.320grams

Correspondence

Probestation

‐ HMP‐400/600

‐ HMP‐800/1200

‐ HMP‐FPDseries

◆ Physicaldimensions(unit:mm)

Accessories

■ ACCESSORIES

Accessories

■ ACCESSORIES

Accessories

Positioners (Manipulators)

HP80 Compactpositioner

General‐purposepositionerdesignedforlowcost. (HP80/L・R‐M)

Stablecontacton70μmorlargerPADwithminimalbacklash.

Model

HP80/R(righthandmodel)

HP80/L(lefthandmodel)

Travelrange(X,Y,Z)

12/8/12mm

Screwresolution (X,Y,Z) 0.635mm/rev.

Featureresolution

15μm

Mounting

[‐M]Rubbermagnetbase

[‐E]On/Offswitchingmagnetbase

Dimensions

[‐M]W46×D74×H55mm

[‐E]W41×D83×H69mm

Weight

[‐M]approx.160grams

[‐E] approx.240grams

Correspondence

Probestation

‐ HMP‐400/600

‐ HMP‐800/1200

‐ HMP‐FPDseries

HP80/L‐M

Rubbermagnetbasemodel

HP80/R‐E

On/Offswitchingmagnetbasemodel

HP80/L・R‐M Rubbermagnetbasemodel

HP80/L・R‐EOn/Offswitchingmagnetbasemodel

◆ Physicaldimensions(unit:mm)

Accessories

Positioners (Manipulators)

■ ACCESSORIES

HP120 High‐accuracypositioner

Model

HP120

Travelrange(X,Y,Z)

12/12/12mm

Screwresolution (X,Y,Z) 0.254mm/rev.

Featureresolution

2μm

Mounting

On/Offswitchingmagnetbase(standard)

Dimensions

W52×D107×H91mm

Weight

approx.690grams

Correspondence

Probestation

‐ HMP‐400/600

‐ HMP‐800/1200

‐ HMP‐FPDseries

‐ HSP‐100/150

‐ HSP‐200/300

‐ HSP‐FPDseries

Precisionleadscrewfeedhigh‐accuracypositioner.

Stablecontacton10μmorlargercircuitpattern orPADwithoutbacklash.

◆ Physicaldimensions(unit:mm)

HP130A High‐accuracypositioner

Fine‐pitchmicrometerfeedhigh‐accuracypositioner.

Stablecontactoninternaldevices ofseveralmicrometersandsmallPAD.

Model

HP130A/R(righthandmodel)

HP130A/L(lefthandmodel)

Travelrange(X,Y,Z)

13/13/13mm

Screwresolution (X,Y,Z) 0.25mm/rev.

Featureresolution

1μm

Correspondence

Probestation

‐ HMP‐800/1200

‐ HMP‐FPDseries

‐ HSP‐100/150

‐ HSP‐200/300

‐ HSP‐FPDseries

Mounting

[‐M]On/Offswitchingmagnetbase

[‐V]Vacuumbase

Dimensions

[‐M]W71×D159×H124mm

[‐V]W66×D159×H124mm

Weight

[‐M]approx.1230grams

[‐V]approx.1190grams

◆ Physicaldimensions(unit:mm)
