HiSOL Semi ‐ Automatic Prober Control Software Manual operation BIN mapping Wafer Map setting Seals fe ature Supported automatic meas urement softwa re KEYSIGHT technologies ‐ EasyEXPERT ‐ Desktop E…

・
Model HSP-200SC is for 8" wafers.
・
Model HSP-300SC is for 12" wafers.
8inch 12inch
■ SEMI-AUTOMATIC PROBER
Semi‐Automatic ProberforHigh/LowTemperatureTests
Applications
‐ Temperaturecharacteristicstestsinrangefrom+25°Cto+300°C
orfrom‐60°Cto+300°C
‐ UltralowsignalI‐Vmeasurements(fAlevel)
‐ VariousC‐Vmeasurements
(quasi‐staticC‐V,HF‐CV,andRF‐CV)[subpFlevel]
‐ 1/fnoiseevaluation
‐ RTN(random telegraphnoise)evaluation
‐ High‐frequencynoiseevaluation(upto800MHz)
‐ RFmeasurements(upto67GHz)/Sparameteracquisition
‐ Ultrahigh‐speedI‐Vmeasurements
Thisisasemi‐automaticprobesystemfornext‐generationsemiconductordevicesdesignedforlownoiseandlowleakage.
Inthissystem,ashieldedchamberstructurecontains
theprobeandchuckinatotallyEMIshieldedenvironment.
Thesystemsupportsin‐planeautomaticmeasurementssuchasultralowsignalI‐V/C‐Vmeasurementinthreshold
regions,1/fnoisemeasurement,Sparameteracquisition,RTN(randomtelegraphnoise)measurement,andhigh‐speedI‐V
measurementinatemperature
controlrangefrom‐65°Cto+300°C(or+400°Cwhenusingthespecialoption).
Thisprobesystemcanoptionallysupporthigh‐currentandhigh‐voltagepowerdeviceapplications.
*TheHSP‐150SCfor6” wafersisalsoavailable.
Extended applications
‐ Probecardsupport(cansupportMultisiteWLR)
‐ Activevibrationisolatorandultrahigh‐accuracyprobingthrough
image processingpatternrecognition(accuracy:±1umorfiner)
‐ Light‐receiving/emittingcharacteristicsevaluationapplicationsfor
optoelectronics(suchasLED,LD,VCSEL,andPD)
‐ Commongatepad contactsofflat‐paneldisplaydevices
‐ High‐powerdevicemeasurements
(400Apulse,±3kVtriaxial,±10kVcoaxial) *8” model
‐ Waferlevelreliabilitytests(suchasEM,TDDB,HCI,NBTI,and BT)
WaferSize
X‐Ytravel
X‐Yrepeatability
X‐Yaccuracy
Ztravel
Unitdimension(W×D×H)*
Weight*
Zrepeatability
HSP‐200SC HSP‐300SC
~φ200mm ~φ300 mm
X:205mm,Y:205mm X:310mm,Y:310mm
1350×1000×1450mm
1450×1150×1450mm
1050kg 1250kg
<±3μm
<±5μm
20mm
<±1μm
θ travel
θ repeatability
±7.5°
0.002°
*Itemswithasteriskvarydependingonsystemconfiguration.
Model HSP-200SC / HSP-300SC
Semi‐AutomaticProber
8

HiSOLSemi‐Automatic Prober ControlSoftware
Manualoperation
BINmapping
WaferMapsetting
Seals feature
Supportedautomaticmeasurementsoftware
KEYSIGHTtechnologies
‐EasyEXPERT
‐DesktopEasyEXPERT
‐WaferProExpress
TFF/KEITHLEYinstruments
‐4200‐SCS KITE(KeithleyInteractiveTestEnvironment)
‐ACS
Proplus designsolution ‐Noisepro
OtherGP‐IBcommunication‐enabledsoftware
‐ User‐friendlymultifunctionalsemi‐automaticprobingsoftware.
‐ SupportsWindows8asitsoperatingsystem.(Windows7isalsosupported.)
‐ AlsoavailableasamanualproberwithasoftwareGUIorjoystickcontroller.
‐ ReceivingBINinformationfromahigher‐levelmeasuringinstrument,itispossibletodisplayBINmapping.
‐ Supportswafer
thermalexpansioncompensationfunctionforThermaltest.
‐ Possibletocontrolthesemi‐automaticproberusingtheGP‐IBcommandsentfromahigher‐levelmeasuring
instrument or PC.
‐ Possibletoprovidesoftwareformakingadatabaseofandextractingparametersofrawdataobtainedfromeach
measuring instrumentinordertoanalyzethedata.
(Optional)
‐ Theself‐developedsoftwareallowsuserstoincorporatecustomizedrequirements.
■ SEMI-AUTOMATIC PROBER
Semi‐AutomaticProber
9

■ PROBE SYSTEM FOR FPD
FPD
ManualProberforFlat‐PanelDisplay
Wecustom‐makemanualprobersthatsupportFPDs (flat‐paneldisplay)rangingfromsmalltolargeglasssubstrates.
Amicroscopeandprobingareawithawiderangeofmotionallowstableprobingacrossthepanelsurface.
Aheatingtype(upto+200°C)orthermaltype(‐40°Cto+200°C)can
beselectedfortherectanglepanelchuckand
ultralowcurrentmeasurementsonthefAlevelandC‐VmeasurementsonthesubpFlevelaresupportedforalltemperature
zones.
Thisproberalsosupportslightirradiationonthepanelsurface bythesolarsimulatororotherdeviceandlightirradiationon
the
bottom sideofpanel(backlight)bysuper‐highluminancewhiteLED.
Lightirradiationonthebottom sideofpanel
byultrahighluminosityLED
(upto40,000cd/cm2) *Sub‐stage
Lightirradiationonthepanelsurfaceby
thesolarsimulatororotherdevice
Built‐inlasercutter
(laserwavelength:1064,532,355,266nm)
Ultrahigh‐accuracymodelforstable
probingof
submicronpatterns
Function examples of systems for small to medium-sized panels
Model HMP-FPD series
Widerangeprobingareathatenableslayout
of FPDdevices.
ProbeSystemforFPD
