Check the status.
1. Check that “Status” of the “X-Ray Source” parameters indicates “4: Over”.
2. Press the [Close] button to close the “X-ray Information” screen.
“X-ray Information” screen
Check “Status”
[Close] button
24A02-M6-00
3
Press the [Off] button and then turn off the machine main power.
To lower the temperature in the X-ray generator to 15°C or below, open the front safety door of the
machine and leave it open for about 30 minutes with the power turned off.
4
Turn on the machine main power and perform return-to-origin.
5
Start warm-up of the X-ray generator.
1. On the Setup screen, press the press the [X-ray Information] button to open the “X-ray Information”
screen.
2. From the pull-down list in the “Operation” group box, select “Warm-up” and press the [Execute]
button.
”X-ray Information” screen
Warm-up
Select “Warm-up”
[Execute] button
24A03-M6-00
S-1
INDEX
Index
A
Alarm buzzer 1-2
Axis configuration 1-7
C
CE marking i
Checking the conveyor belt tension 4-24
Connection between machines A-2
Consumable parts 4-5
Conveyor unit 1-5
D
daily operation 3-1
E
Emergency stop button 1-2
Canceling emergency stop 2-1
Error
Clearing an error 2-1
H
Handling the X-ray unit viii
Height measurement method 1-6
L
Laser height sensor 1-6
Lubrication of each unit 5-2
M
Machine main unit 1-1
Machine-to-machine connection
connectors 1-4
Main pressure regulator 1-3
Main switch 1-2,2-2
Maintenance
Air filter 4-31
Ball screws and guides 4-14,4-28,4-33
Board sensor 4-12
Camera lighting unit 4-10
Importance of periodic inspections and
cleaning 4-2
Monthly 4-13
Weekly inspection 4-10
Maintenance list 4-3
Maintenance tools 4-6
Manual contents i
Contents of each chapter iii
Page layout iv
Using this manual i
O
Operation
Daily operation flow 3-1
Ending 2-5
Pre-operation inspection 2-2
Return-to-origin 2-2
Starting 2-2
P
Power connection terminals ,1-4
Pressure regulator for shutte 1-3
Protective function for the X-ray generator
A-10
R
[READY] button 1-2
Removing the rear center panel 4-9
Required tools 4-8
S
Safety ii
Safety cover 1-2
Safety message xi
Selecting the program 3-3
Signal light (signal tower) 1-1
U
UPS
Replacing the UPS battery 4-41
UPS (uninterruptible power supply) ,1-4
USB port 1-3
W
Warming up the X-ray generator A-10
Warm-up operation 3-2
Warning labels xv
Warranty ii
X
X-ray generator 4-26,A-10
X-ray generator warm-up 2-3
X-RAY indicator 1-2
X-RAY safety key 1-2
