13 Docking Station for SIPLACE SX Changeover Tables 2 Operating Safety Operating Manual 2.2 Warning Signal and Warning and Danger Labels 2.2 Warning Signal and Warning and Danger Labels 2.2.1 Cleaning the Warning Labels …
2 Operating Safety Docking Station for SIPLACE SX Changeover Tables
2.1 Safety Information Operating Manual
12
DANGER
The docking station for SIPLACE SX changeover tables is driven by electricity. Electrical devices
inherently include parts under dangerous voltage during operation!
Prior to any activities that are not part of the normal operation of the docking station for SIPLACE
SX changeover tables, such as servicing, maintenance, and repair, be sure to switch off the
machine at the main power switch and disconnect the power cord from the power supply.
Before any service, maintenance, or repair work, the docking station for SIPLACE SX changeover
tables must be locked with a personal padlock to prevent it from being switched on again at the
main power switch and a corresponding label must be provided. The power cords must be
secured against accidental reconnecting! Afterwards, the necessary work can be performed with
caution.
Also observe the specific safety information in the respective manual when working on electrical
installations.
2.1.7 For Environmentally Safe Disposal of Materials and Machine Parts
The docking station for SIPLACE SX changeover tables uses only substances, materials and
parts that can be separated easily and disposed of in an environmentally friendly manner. Neither
the assembly, disassembly nor operation of the docking station for SIPLACE SX changeover
tables requires any hazardous substances that are harmful to the environment.
NOTE
The proper and environmentally friendly disposal of the machine, its operating materials, and any
expendable and worn-out parts lies solely in the responsibility of the operator of the equipment.
Be sure to observe the national legal regulations for waste disposal and environmental protection.
13
Docking Station for SIPLACE SX Changeover Tables 2 Operating Safety
Operating Manual 2.2 Warning Signal and Warning and Danger Labels
2.2 Warning Signal and Warning and Danger Labels
2.2.1 Cleaning the Warning Labels
WARNING
Do not use harsh detergents or solvents for cleaning the warning labels.
Be sure to replace any warning labels that are missing, damaged, or no longer readable.
Pay attention to the correct location of the warning labels.
2.2.2 Warning and Danger Labels
2.2.2.1 Warning Label W 206
Part No.: 03009345-01
Label locations: On the docking station for SIPLACE SX changeover tables
- Covers for the power supply
Number per machine: 4
Class: WARNING
Dangerous voltage!
Parts labelled with this sticker are live even when the main switch is switched
off.
Disconnect the machine from the supply system before commencing any
service work!
NAFTA Region: Risk Of Electric Shock Or Burn.
Fig. 2 - 1 Warning label W206, part no. 03009345-01
Fig. 2 - 2 Warning label W206, part no. 03009345-01 - label locations
2 Operating Safety Docking Station for SIPLACE SX Changeover Tables
2.3 ESD guidelines Operating Manual
14
2.2.2.2 Warning Label W 203
Part No.: 03009342-01
Label locations: 2x on the docking station for SIPLACE SX changeover tables
– 1x each on the left and right behind the power and data interface on
the housing.
Number per machine: 2
Class: WARNING
CRUSHING DANGER!
Reaching inside may result in injury to arms and hands.
Do not reach into the running machine!
Fig. 2 - 3 Warning label W203, part no. 03009342-01
Fig. 2 - 4 Warning label W203, part no. 03009342-01 - label locations
2.3 ESD guidelines
Please observe the information on the ESD directives as indicated in the operating manual of the
placement system.
