NPM-TT2 EJM1EE-SF-01N-05
Safety precautions 1
DANGER
Indicates an imminently hazardous situation that could
result in death, severe bodily injury or major property
damage.
WARNING
Indicates a potentially hazardous situation that could result
in death, severe bodily injury or property damage.
CAUTION
Indicates a potentially hazardous situation that could result
in minor or moderate injury and property damage.
Indicates actions that must not be carried out.
Indicates actions that must be carried out.
Indicates matters to which attention must be paid.
Indicates that you must read the manual.
1-1
1-1-1
The degree of danger or injury resulting from incorrect usage are classified and described as follows.
Precautions that must be observed in order to prevent injury to the user or other persons, and damage to
property are described below.
Precautions that must be observed are classified by the symbols shown and described below.
(The followings are examples of symbols)
NPM-TT2 EJM1EE-SF-01N-05
1-1-2
To prevent
injury or
burn…
Emergency stop switch
(Located in front and rear)
Be sure to observe the following
■For several machines connected
If you sense any danger or abnormalities,
press the emergency stop switch to stop
operation
●When you push the emergency stop switch, the
machine stops.
●Push the nearest emergency stop switch (two
locations). Either switch stops the machine.
[How to reset]
When you are ready to restart operation, turn the
emergency stop switch clockwise and pull out after
checking and clearing any danger or abnormalities.
●The machine located on the right side seen from
the machine front also stops along with the one on
which the emergency stop switch is pushed. Other
machines do not stop. (See the picture above)
(If you continue to operate the machine in a dangerous
or abnormal state, an accident will occur)
Machine
does not stop
Machine
stops
Once the emergency
stop switch has been
pushed
Front side
Confirmation
DANGER
NPM-TT2 EJM1EE-SF-01N-05
1-1-3
Do not disable safety
switches
(Risk of injury)
Replenish-section
open/close switch
●It has a function of
safety switch
●Installed under the
cover
Safety switch
(In the magazine
door)
Single tray feeder
(option)
Safety switches
(Under rear safety cover)
Safety switches
(Under front safety cover)
●When safety switches on safety convers are
activated during operation , the machine stops.
Safety precautions 2
1-1
Single tray feeder 13-slot supply
unit
Single tray feeder coupling part
Safety switch
(Single tray feeder
coupling part)
DANGER
