NPM- TT2 EJM1EE-MB-03 O-02 3-2-1 -7 Feeder pickup condition 1 Operating procedure 3-2-1 Choose either by machine or by line : By machine : By line Produc- tion informa- tion A Stop production after the produce d current …

100%1 / 512
NPM-TT2 EJM1EE-MB-03O-02
D
Even though component empty
warning is displayed, it is a
misjudgment. So, production is
continued.
E
Illuminates LED of unused feeders.
F
■By machine
H
G
I
ADR (address)
Component address.
CompName
Time
The estimated time to component
empty.
●Unit: minute
J
PCB
The number of PCBs produced before
component empty.
Length
The remaining tape length (m).
A B
D
C
HE F
G
J
I
■By line
A B
DC HE F
GA
3-2-1-6
Production
NPM-TT2 EJM1EE-MB-03O-02
3-2-1-7
Feeder pickup condition
1
Operating procedure
3-2-1
Choose either by machine or by line
: By machine
: By line
Produc-
tion
informa-
tion
A
Stop production after the produced current
PCB. (→P.3-1-2)
B
Updates to latest information.
D
Displays detailed pickup information.
C
●Displays error count of the selecting
nozzle in an hour in graph.
Returns to the
previous screen
●Pickup information of components of a feeder is displayed.
Vertical axis: error count
Horizontal axis: time
How to check the screen in
production when stationary
4
A
D
B
1
C
NPM-TT2 EJM1EE-MB-03O-02
■By machine
TBL (table)
Table to be referred.
ADR (address)
Component address.
CompName
Shows the rest of the component name
by scrolling.
PickupCnt
Err cnt
Err Rate
Displays the error rate per machine or per
line.
■By line
3-2-1-8
LeadTo
Displays increase or decrease tendency
of the error rate with arrow icons.
●
●
●
●
●
: Ultra up tendency
: Up tendency
: Constant tendency
: Ultra down tendency
: Down tendency
Production
F
G
H
I
J
K
L
M
N
E
H
JI
K
LGN
F
M
H
IN G
F
J
K
L
M
E
E
MC (Machine)
The machine numbers that are assigned
to machines organized into a line and
that start at the head of the line.
