NPM- TT2 EJM1EE-MB -03O-02 3-2-3 -2 A B C D E Choose the display type. Thick The number/rate of component thickness errors. Mount The number/rate of mounting errors. G I H Returns to the previous screen. J Down The numbe…

100%1 / 512
NPM-TT2 EJM1EE-MB-03O-02
2
3-2-3-1
C
A
B
D
E
F
G
You can check component pickup information of a feeder per feeder address.
Produc-
tion
informa-
tion
Operating procedure
3-2-3
TBL (table)
Table to be referred.
ADR (address)
Feeder address.
CompName
Component name being
picked up.
Total
Total of pickup count of all feeders and
error count, and error occurrence rate
for total pickup count.
H
E FD
A C HB
Shows the rest of the component name
by scrolling.
PickupCnt
Number of components being picked
up per feeder.
Err Cnt
Number of components resulting in
error
Err Rate
Error occurrence rate for pickup count
Feeder pickup
information 1
●Perform on both and .
1
G
I
Tape / Stick Feeder
●A/B: Tray feeder table
(Only A is available in a single tray
feeder)
● Numerical number: Tray pallet
position number
Tray feeder
I
Lane
Change the display item to “All” or
“Lane”. When you select “Lane”, also
select the lane by the lane change
button.
●Numerical number: Feeder position
number
●R/L/C: Feeder component position
(For double tape feeder, thin type
single feeder)
R(right), L(left),
(For 3-rows stick feeder)
R(right), L(left), C(center)
NPM-TT2 EJM1EE-MB-03O-02
3-2-3-2
A
B
C
D
E
Choose the display type.
Thick
The number/rate of component
thickness errors.
Mount
The number/rate of mounting errors.
G
I
H
Returns to the previous screen.
J
Down
The number/rate of component drop
errors.
F
1
(Error detailed information is displayed)
TotalErr
The number/rate of feeder errors.
Total
The total number/rate of pickup of all
feeders or the total number/rate of errors
for each feeder.
PickupCnt
The number/rate of pickup of feeder.
Pickup
The number/rate of pickup errors.
Recog.
The number/rate of recognition errors.
A C F GB D
H
JIE
Production
NPM-TT2 EJM1EE-MB-03O-02
3-2-3-3
Produc-
tion
informa-
tion
Operating procedure
3-2-3
Feeder pickup
information 2
4
Deletes the image.
Go to the previous/next image. Returns to the previous screen.
Select
5
6
Confirm the message
or
Confirm the message
●When you do not save the data
5
6
3
:Displays all images.
: Displays the image of
the feeder address
specified on the
previous screen.
(Saves error histories)
: Displays all images.
Image display during operation
ON : Display
OFF: Non-display
2
(Recognition error image information
is displayed)
Choose an image to display
●All error images in the selected table
are displayed in reverse chronological
order.
● When a superimpose image is being
displayed, the tact time gets worse
about 5%.
B
C
A
4
7
3
D
A
B
C
D
Switches between showing and hiding
the recognition result on the recognition
screen when each time you press the
button.
D
Each time you press
