NPM- TT2 EJM1EE-MB -03O-02 3-2-1 1 -2 2 (Detailed error information is displayed) A B Returns to the previous screen. C Choose the display type. Pickup information per nozzle ( → P.3-2-1 -12 ) Production A B C
NPM-TT2 EJM1EE-MB-03O-02
3-2-11-1
You can check nozzle pickup condition.
Produc-
tion
informa-
tion
Operating procedure
3-2-11
Nozzle pickup
monitor
1
Displays error count of a component
in a graph.
B
LeadTo
A
Displays increase or decrease tendency
of the error rate.
●
●
●
●
●
: Ultra up tendency
: Up tendency
: Constant tendency
: Ultra down tendency
: Down tendency
Pickup information per nozzle
(→P.3-2-1-12)
Shows the previous or next table.
C
●Error count of the selecting head
per hour is displayed on the graph.
Vertical axis: Error count
Horizontal axis: Time
●Choosing the total error or an error
item can change the display of the
graph
D
Total error and error item
(→ P.3-2-5-2)
D
1
2B
A
C
NPM-TT2 EJM1EE-MB-03O-02
3-2-11-2
2
(Detailed error information is displayed)
A
B
Returns to the previous screen.
C
Choose the display type.
Pickup information per nozzle
(→P.3-2-1-12)
Production
A B C
NPM-TT2 EJM1EE-MB-03O-02
3-2-12-1
Describes how to handle the PCB warpage detection error.
1
●There are five types for error;
A:PCB warpage range over, B:PCB warpage possible range error, C:PCB warpage result grade error, D:PCB
warpage measurement error, E:PCB warpage correction disabled
●If PCB warpage detection error occurs, the following four types of handling methods are available.
(1)Re-measuring the PCB warpage shape
Return to the main menu and start the production again
(2)Removing the error PCB
Perform the following flow
+
2
(Return to the Home screen)
Handling method Error type
(1) Re-measuring the PCB warpage shape A, B, C
(2) Removing the error PCB A, B, C
(3) Changing the PCB warpage grade
tolerance
C
(4) Teaching PCB warpage measurement A, B, C, D, E
Produc-
tion
informa-
tion
Operating procedure
3-2-12
PCB warpage
detection error 1
2
1
