NPM-TT2 EJM1EE-MB-04O-03
Data
editing
Checking and editing
the arrangement list
4-1-6-1
Intelligent feeder
Explains how to check and edit the arrangement of the feeders on the feeder table or pallets,
on the tray, or stock condition.
Edit the data of the desired
field on the screen
●Touching the screen opens the input
window.
1
A
Reel of lead/Pallets
The total number of reels or pallets
registered in the selected table.
B
Skip reel
The total number of reels or pallets
specified to be skipped in .
C
ADR (address)
D
STK (stock)
ID number of stock component.
(Only when there is stock)
K
E
CompName
Shows the rest of the component name
by scrolling.
F
FP/FW
G
H
Choose a tape type.
RK
●FP: Tape feed pitch.
●FW: Tape feed width.
Operating procedure
4-1-6
Address of a feeder.
(→P.3-2-3
-1)
C
D E
A
H
F
G
B I
J
K
L
NPM-TT2 EJM1EE-MB-04O-03
I
Style
J
ANG (angle)
K
The data on the cursor lines are skipped.
(Become disabled and no mount is
carried out)
Tray feeder
C
D E
A
F M
B
I
J
L
Choose a component supply angle.
Component pickup angle.
L
Shows the previous or next table.
Tray name
M
1
1
2
Edit the data of the desired
field on the screen
●Touching the screen opens the input
window.
4-1-6-2
Ｓｅｔｔｉｎｇ
change
K
N
N
The tray origin window is displayed.
(When several trays are placed on a
pallet, the tray origin window is
displayed)
NPM-TT2 EJM1EE-MB-04O-03
Data
editing
You can check and edit the substitute components data which is substituted with originally used master
components registered by DGS in advance.
1
1
Choose a component name
2
3
3
2
Choose a substitute
component
●Substitution component refill (→P.3-3-1)
Substitution
component setting
(intelligent feeder)
■When you do not set
Operating procedure
4-1-7
4-1-7-1
●Choose the component (master
component) registering substitution
component.
●The screen for substitution component
selection is displayed.
(The component supply destination
changes from master to sub
component.)
