NPM-TT2 EJM1EE-MB-04O-03
Data
editing
Describes how to check and edit the component data in the feeder or tray.
You can browse and change a part of data in the machine. Detailed data edit is performed on DGS.
E
G
F
H
B
C
D
A B C
H F
E
2
G
D
CompName
Shape
Shows the previous or next
component information.
2: Right electrode width.
4: Left electrode width.
1: Upper electrode length.
2: Right electrode length.
3: Lower electrode length.
4: Left electrode length.
Max. size
Parts size
Square chip component 1
4-1-8-1
Component shape data
edit 1
3
A
ADR (Address)
●Displays when it is set.
Electrode length
Electrode width
Edit the data of the desired
field on the screen
●Touching the screen opens the input
window.
1
or
Operating procedure
4-1-8
Address of a feeder.
(→P.3-2-3
-1)
NPM-TT2 EJM1EE-MB-04O-03
A
Limit
Recog height
Pickup pos.
B
D
C
E
Press
+
－
+
－
●+ L: Tolerance of a component length
in + direction.
●- L: Tolerance of a component length in
- direction.
●+ W: Tolerance of a component width
in + direction.
●- W: Tolerance of a component width in
- direction.
4-1-8-2
2
F
Returns to the previous screen.
Enter the recognition height..
Eject height
Enter the eject height.
Ｓｅｔｔｉｎｇ
change
A
CD E
B
F
●Mount:
The mount gap [mm]
●Pickup:
The pickup gap [mm]
(*Editable only for 3-nozzle head)
Confirm and edit the detailed data.
NPM-TT2 EJM1EE-MB-04O-03
4-1-8-3
Data
editing
Component shape data
edit 2
Square chip component 2
Operating procedure
4-1-8
4
Choose the desired item to
confirm
Confirm and edit the recognition option
data.
54
●Choose the Mnt pos. offset to
display the related data.
●Choose the trend range check to
display the related data.
●Choose the center range check to
display the related data.
●Choose the luminosity check to
display the related data.
●Choose the 2D clipping level to
display the related data.
3
