NPM-TT2 EJM1EE-MB-04O-03
4-1-8-7
AB
F
E
D G
C
C
A
B
CompName
Reel of lead
Side
The number of leads of each side.
Choose a side to check a component.
4
D
Lead information
Lead existence of each component.
F
G
H
H
Returns to the previous screen.
Data
editing
Component shape data
edit 4
Component with leads 2
E
Displays the screen to set “Missing
lead” position.
Displays the screen to set “Noise”
position.
Displays the screen to set “Lead
existence” position.
Lead
information
Symbol Setting button
Lead
existed
○
Lead
absence
×
Noise N
Operating procedure
4-1-8
1 2 3 4 ･･･
Top side
1
2
3
4
･
･
･
･･･ 4 3 2 1
Right
side
Bottom side
1
2
3
4
･
･
･
Left
side
The lead order is clockwise direction as a
reference.
Confirm and edit the missing lead
information.
NPM-TT2 EJM1EE-MB-04O-03
●Set this even though it is judged to
lead absence, it is actually lead
existed.
Set a start position of
missing lead and lead count
I
J
K
JK I
Returns to the screen in .
4
It is reflected as [X] in lead
information .
D
Set a start position of lead
noise and lead count
L
M
It is reflected as [N] in lead
information .
D
Set a start position of lead
existence and lead count
N
O
It is reflected as [○] in lead
Information .
D
■Missing lead setting screen
■Noise position setting screen
■Lead existence setting screen
MK L
OK N
Ｓｅｔｔｉｎｇ
change
4-1-8-8
NPM-TT2 EJM1EE-MB-04O-03
BGA １
B
A
D2
X: The number of balls on side 1 and side 3.
Y: The number of balls on side 2 and side 4.
●Unit: piece.
3
A
CompName
(→P.4-1-8-1)
Ball number
4
C
B
C
X: Ball pitch on side 1 and side 3.
Y: Ball pitch on side 2 and side 4.
●Unit: mm.
Ball pitch
D
●Unit: mm.
Ball diameter
Edit the data of the desired
field on the screen
●Touching the screen opens the input
window.
1
4-1-8-9
BGA 1
Data
editing
Component shape data
edit 5
Operating procedure
4-1-8
