NPM-TT2 EJM1EE-MB-04O-03
4-1-13-1
Explains about the screen to check and edit the production data.
D
E
F
A C
Production data information
(→P.4-1-13-2)
B
E
A
SkipPoints
B
MntPoints
C
Data
editing
Production data edit 1
The total number of placement points to
be specified as skip.
The total number of placement point.
G
H
GF
H
(Scrolls the table to the right.)
●This button becomes enabled when
there is recognition data of placement
points.
Shows the previous or next table.
Searches the placement point by
sequence number, coordinate or
comment.
Selecting placement point is
select/deselect to be skipped.
Screen explanation 1
Operating procedure
4-1-13
D
NPM-TT2 EJM1EE-MB-04O-03
N
M
K
4-1-13-2
I
J
OHL/OHR
OHL: Length jutting out from left edge of
a PCB.
OHR: Length jutting out from right edge
of a PCB.
●Input range: 0 to 9 mm.
■The table of production data information
E
K
J
I
OL
M
N
Fixed column
Horizontal scrolling with or
O
C
SEQ.
Placement point sequence No.
X[mm],Y[mm] , A[deg]
Coordinates and angle of a placement
point.
P
Priority of a placement point.
Symbol Priority
Blank Standard
H Higher priority.
L Lower priority.
Choose the display type.
Location Symbol Name
Upper
field
CompName Component name
Lower
field
FA Feeder address
PN Pattern No
No Sequence No
Comment Comment
Shows the rest of component name if it is
too long to show the whole name.
L
CompName/FA, PN, No, Comment
Displays the information of the
selected display type.
Ｓｅｔｔｉｎｇ
change
NPM-TT2 EJM1EE-MB-04O-03
4-1-13-3
Explains about the screen to check and edit placement points of the production data.
Data
editing
Production data edit 2
Operating procedure
4-1-13
1
●This button becomes enabled when
there is recognition data of placement
points.
1
Screen explanation 2
