NPM-TT2 EJM1EE-MB-04O-03
Component recognition teach 1
1
You can enter and edit the mount
condition. (→P.4-1-9)
CA
B
You can enter and edit the component
shape data.(→P.4-1-8)
You can confirm all recognition
processes. (→P.5-2-10 to 5-2-13)
4-2-4-3
Produc-
tion data
teaching
Component
recognition teach 2
The screen for choosing a component to
recognize is displayed.
Operating procedure
4-2-4
1
CA B
NPM-TT2 EJM1EE-MB-04O-03
4-2-4-4
Ｓｅｔｔｉｎｇ
change
3
3
(The setting screen of pickup condition is
displayed)
Choose a component to
recognize
2
■To cancel
2
●An item in the “ADR” field shown in
green color means a component
which requires part recognition teach.
NPM-TT2 EJM1EE-MB-04O-03
E
ThickMeas
This button is not used for NPM-TT2.
F
Teach
Teaching target
G
Shape
Four shape patterns of teaching component.
4
4
5
5
Choose a pickup condition
AB
C F G
ED
Complete the setting
C
A
B
NozzlePos
Nozzle position to pick up.
Scan speed
Four speed patterns during recognition.
Scan direct.
Recognition direction
: From left to right
: From right to left
D
Pickup
■To automatically pickup a
component
■To manually pickup a component
Produc-
tion data
teaching
Component
recognition teach 3
4-2-4-5
Component recognition teach 2
■To recognize a component by
the line camera
■To change the brightness of a
recognition image
●Shape: Chip
●Shape: Lead
●Shape: BGA
●Shape: Odd type
Operating procedure
4-2-4
