NPM- TT2 EJM1EE-MB -04O-03 E ThickMeas This button is not used for NPM-TT2. F T each Teaching target G Shape Four shape patterns of teaching component. 4 4 5 5 Choose a pickup condition A B C F G E D Complete the setting…

100%1 / 512
NPM-TT2 EJM1EE-MB-04O-03
4-2-4-4
Ｓｅｔｔｉｎｇ
change
3
3
(The setting screen of pickup condition is
displayed)
Choose a component to
recognize
2
■To cancel
2
●An item in the “ADR” field shown in
green color means a component
which requires part recognition teach.
NPM-TT2 EJM1EE-MB-04O-03
E
ThickMeas
This button is not used for NPM-TT2.
F
Teach
Teaching target
G
Shape
Four shape patterns of teaching component.
4
4
5
5
Choose a pickup condition
AB
C F G
ED
Complete the setting
C
A
B
NozzlePos
Nozzle position to pick up.
Scan speed
Four speed patterns during recognition.
Scan direct.
Recognition direction
: From left to right
: From right to left
D
Pickup
■To automatically pickup a
component
■To manually pickup a component
Produc-
tion data
teaching
Component
recognition teach 3
4-2-4-5
Component recognition teach 2
■To recognize a component by
the line camera
■To change the brightness of a
recognition image
●Shape: Chip
●Shape: Lead
●Shape: BGA
●Shape: Odd type
Operating procedure
4-2-4
NPM-TT2 EJM1EE-MB-04O-03
6
7
8
+
+
+
(A component is picked up)
Only if you transcript a
component
(The recognition screen appears in large
form and teach is started)
(A component transcription is carried out)
●It is available only if the transcription
function is enabled.
4-2-4-6
Ｓｅｔｔｉｎｇ
change
6
7
8
9
10
9
+
(Suitable lamp value is decided)
10
●Adjust the brightness to see the
bad mark.
(→P.4-2-1 ‘How to adjust the lamp
value’)
