NPM- TT2 EJM1EE-MB-04 O-03 Produc- tion data teaching 4-2-6 -3 Operating procedure 4-2-6 P ar t vacuum of fset teac hing 2 6 6 7 7 5 5 Specify the parts center using inching. Specify the actual pickup position using the …
NPM-TT2 EJM1EE-MB-04O-03
4-2-6-2
Ｓｅｔｔｉｎｇ
change
1
1
Choose a component
(Display the <Part selection> screen)
2
3
●An item in the “ADR” field shown in
green color means a component which
requires part recognition teach.
(Returns to the <Part pickup offset> screen)
4
+
(Load a component image (composite))
2 3
4
NPM-TT2 EJM1EE-MB-04O-03
Produc-
tion data
teaching
4-2-6-3
Operating procedure
4-2-6
Part vacuum offset
teaching 2
6
6
7
7
5
5
Specify the parts center using inching.
Specify the actual pickup position using the
scale move button.
Scale move button
NPM-TT2 EJM1EE-MB-04O-03
4-2-6-4
Ｓｅｔｔｉｎｇ
change
8
8
9
9
Confirm the message
■When you do not save the teach result
